Image preview - the first page of the document
![Panel_QDI_QD15XL13_Rev-01_0_[DS]](/pics/5eb0039a67a8a.gif)
>> Download Panel_QDI_QD15XL13_Rev-01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Quanta Display Inc. QD15XL1301 Page 1/21
Doc No. QD15XL1301
Doc. REV.: 01
Issue Date:05/12/2005
RoHS compliant
Quanta Display Inc.
SPECIFICATION
Specification for TFT LCD Module
Model No.
QD15XL13 Rev.:01
Approved By
Quanta Display Inc.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Quanta Display Inc. QD15XL1301 Page 2/21
These specification sheets are the proprietary product of Quanta Display Inc. ("QDI")
and include materials protected under copyright of QDI. Do not reproduce or cause any third
party to reproduce them in any form or by any means, electronic or mechanical, for any
purpose, in whole or in part, without the express written permission of QDI.
The device listed in these technical literature sheets was designed and manufactured for
use in OA equipment.
In case of using the device for applications such as control and safety equipment for
transportation (aircraft, trains, automobiles, etc. ), rescue and security equipment and
various safety related equipment which require higher reliability and safety, take into
consideration that appropriate measures such as fail-safe functions and redundant system
design should be taken.
Do not use the device for equipment that requires an extreme level of reliability, such as
aerospace applications, telecommunication equipment (trunk lines), nuclear power control
equipment and medical or other equipment for life support.
QDI assumes no responsibility for any damage resulting from the use of the device which
does not comply with the instructions and the precautions specified in these technical
literature sheets.
Contact and consult with a QDI sales representative for any questions about this device.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Quanta Display Inc. QD15XL1301 Page 3/21
Revision History
REV. Date ECN NO. Change Content
00 04/22/2005 N/A Specification Initiate
01 05/12/2005 N/A P.21 drawing revise
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Quanta Display Inc. QD15XL1301 Page 4/21
1. Application
This specification applies to a color TFT-LCD module, QD15XL13.
2. Overview
This module is a color active matrix LCD module incorporating amorphous silicon TFT
(Thin Film Transistor). It is composed of a color TFT-LCD panel, driver ICs, control circuit
and power supply circuit and a backlight unit. Graphics and texts can be displayed on a
1024 3 768 dots panel with 16.2M colors by using LVDS (Low Voltage Differential
Signaling) to interface and supplying +3.3V DC supply voltage for TFT-LCD panel driving
and supply voltage for backlight.
The TFT-LCD panel used for this module has very high aperture ratio. A low-reflection and
higher-color-saturation type color filter is also used for this panel. Therefore, high-
brightness and high-contrast image, which is suitable for the multimedia use, can be
obtained by using this module.
Optimum viewing direction is 6 o'clock.
[Features]
1) High aperture panel; high-brightness or low power consumption.
2) Brilliant and high contrast image.
3) Small footprint and thin shape.
4) Light weight.
5) Interface 6bit + FRC
6) RoHS compliant
3. Mechanical Specifications
Parameter Specifications Unit
Display size 15" Diagonal inch
Active area 304.1X228.1 mm
Pixel format 1024 (H) 768 (V) Pixel
(1 pixel = R+G+B dots)
Pixel pitch 0.297 (H) 0.297 (V) mm
Pixel configuration R,G,B vertical stripe
Display mode Normally white
Unit outline dimensions (typ.)*1 326.5(W) 253.5 (H) 11(D) mm
Mass Max. 950 g
Surface treatment Anti-glare and hard-coating 3H
*1.Note : excluding backlight cables. Outline dimensions is shown in this specification
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Quanta Display Inc. QD15XL1301 Page 5/21
4. Input Terminals
4-1. TFT-LCD panel driving
CN1 ( 1 channel, LVDS signals ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
