Image preview - the first page of the document
![Panel_QDI_QD12TL02_Rev-01_0_[DS]](/pics/5eb002e8958ea.gif)
>> Download Panel_QDI_QD12TL02_Rev-01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
4XDQWD 'LVSOD\ ,QF/! 3&6. 2CIG
Doc No. QD12TL0201
Doc. REV.: 01
Preliminary Issue Date: 8/29/2005
With RoHS
Quanta Display Inc.
Compliant
SPECIFICATION
Specification for TFT LCD Module
Model No.
QD12TL02 Rev.:01
Approved By
Quanta Display Inc.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4XDQWD 'LVSOD\ ,QF/! 3&6. 2CIG
These specification sheets are the proprietary product of Quanta Display Inc. ("QDI") and
include materials protected under copyright of QDI. Do not reproduce or cause any third
party to reproduce them in any form or by any means, electronic or mechanical, for any
purpose, in whole or in part, without the express written permission of QDI.
The device listed in these technical literature sheets was designed and manufactured for use
in OA equipment.
In case of using the device for applications such as control and safety equipment for
transportation (aircraft, trains, automobiles, etc.), rescue and security equipment and various
safety related equipment which require higher reliability and safety, take into consideration
that appropriate measures such as fail-safe functions and redundant system design should
be taken.
Do not use the device for equipment that requires an extreme level of reliability, such as
aerospace applications, telecommunication equipment (trunk lines), nuclear power control
equipment and medical or other equipment for life support.
QDI assumes no responsibility for any damage resulting from the use of the device, which
does not comply with the instructions, and the precautions specified in these technical
literature sheets.
Contact and consult with a QDI sales representative for any questions about this device.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4XDQWD 'LVSOD\ ,QF/! 3&6. 2CIG
Revision History
REV. Date ECN NO. Change Content
0 5/20/2005 N/A Preliminary Specification Initiation
1 8/29/2005 NA Updated Current Dissipation
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4XDQWD 'LVSOD\ ,QF/! 3&6. 2CIG
1. Application
This specification applies to a color TFT-LCD module, QD12TL0201.
2. Overview
This module is a color active matrix LCD module incorporating amorphous silicon TFT
(Thin Film Transistor). It is composed of a color TFT-LCD panel, driver ICs, control circuit,
power supply circuit and a backlight unit. Graphics and texts can be displayed on a 1280 3
800 dots panel with 262,144 colors by using LVDS (Low Voltage Differential Signaling) to
interface and supplying +3.3V DC supply voltage for TFT-LCD panel driving and supply
voltage for backlight.
The TFT-LCD panel used for this module has very high aperture ratio. A low-reflection
and higher-color-saturation type color filter is also used for this panel. Therefore, high-
brightness and high-contrast image, which is suitable for the multimedia use, can be
obtained by using this module.
Optimum viewing direction is 6 o'clock.
[Features]
1) High aperture ratio, high-brightness.
2) Brilliant and high contrast image.
3) Small footprint and thin shape.
4) WXGA resolution (800 vertical by 1280 horizontal pixel array).
5) LVDS interface.
6) Low power consumption.
7) RoHS compliant
3. General Specifications
Parameter Specifications Unit
Display size 12.1" Diagonal in
