Image preview - the first page of the document
![Panel_SAMSUNG_LTA230HT10_0_[DS]](/pics/5eb00a1bebfbc.gif)
>> Download Panel_SAMSUNG_LTA230HT10_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Technical Notification
h i l ifi i
< LTA230HT10 Design Information>
Customer : General
Date : 2011. 03. 02
Application Engineering Group
LCD Business
SEC Confidential
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
LTA230HT10 Design information
1.
1 General information
Items Specification Unit Note
533.2 (H) x 312.0 (V) mm
Module size
10.3 (Dmax) mm
Weight 1750 g LCD module only
Pixel Pitch 0.2655(H) x 0.2655(W) mm
Active Display Area 509.76(H) x 286.74(V) mm
Surface Treatment Haze 25% Hard-coating(3H)
25%, Hard coating(3H) Anti
Anti- Glare
Display Colors 16.7M (Hi-FRC ) colors
Number of Pixels 1,920 x 1,080 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally White
Luminance of White 250(Typ.) cd/m2
SEC Confidential
www.panelook.com Global LCD Panel Exchange Center
www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
LTA230HT10 Design information
2.
2 Optical Characteristics
Item Symbol Min. Typ. Max. Unit Note
Contrast Ratio Test equipment
C/R 600 1000 -
(Center of screen)
( ) SR-3
Color Gamut - - 72 - %
Color Temperature - - 6500 - K
Brightness Uniformity Test equipment
Buni - - 25 %
(9 Points) SR-3
3.
SEC Confidential
www.panelook.com Global LCD Panel Exchange Center
