Image preview - the first page of the document
![Panel_SAMSUNG_LTA400HM01_0_[DS]](/pics/5eb010dcb4901.gif)
>> Download Panel_SAMSUNG_LTA400HM01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Information
Customer : G/A DATE : 16 Mar. 2010
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL : OWD733KP34
MODEL : LTY400HM01
LTY400HM01
The information Described in this Specification is Preliminary and can be charged
without prior notice
NOTE :
SL Development Team, LCD Business
Samsung Electronics Co . , LTD.
MODEL OWD733KP34
LTY400HM01 Doc. No 05-000-G-100316 Page 1 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ------------------------------------------------------------------------------------------- (11)
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
5.1 Input Signal & Power
5.2 Inverter Input Pin Configuration
5.3 Inverter Input Power Sequence & Specification
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (19)
7.1 Timing Parameters (DE only mode)
7.2 Timing Diagrams of interface Signal (DE only mode)
7.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (22)
8. Packing ------------------------------------------------------------------------------------------------- (24)
9. Marking & Others ------------------------------------------------------------------------------------- (25)
10. General Precaution ---------------------------------------------------------------------------------- (26)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 2 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History
Rev.
Date Page Summary
No
Mar.
16, 000 - First Issued
2010
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 3 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
Description
OWD733KP34 is a color active matrix liquid crystal display (LCD) that uses amorphous
LTY400HM01
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit. The resolution of a 40.0" is 1920 x
1080 and this model can display up to 16.7million colors with wide viewing angle of 89 or
higher in all directions. This panel is intended to support applications to provide a excellent
performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV, Display
terminals for AV application products, and High Definition TV (HDTV).
Features
RoHS compliance (Pb-free)
High contrast ratio, high aperture ratio, fast response time
SPVA (Super Patterned Vertical Align) mode
Wide viewing angle ( 89 )
Full HD (1920 x 1080 pixels) resolution (16:9)
Low Power consumption
10 CCFTs (Cold Cathode Fluorescent Tube)
LVDS (Low Voltage Differential Signaling) interface
General Information
Items Specification Unit Note
952(HTYP) x 551(VTYP) 1.0mm
Module Size mm
60.9(DMAX)
Weight 9000(Max) g
Pixel Pitch 0.15375(H) * 3 x 0.46125(V) mm
Active Display Area 885.6(H) x 498.15(V) mm
Surface Treatment Haze 7%, Hard-coating (3H)
Display Colors 8 bit- 16.7M colors
Number of Pixels 1920 x 1080 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 450 cd/m2 Typ.
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 4 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 13 V (1)
Storage temperature TSTG -20 65 (2)
Operating Temperature TOPR 0 50 (2)
Panel surface temperature TSUR 0 65 (3)
Shock ( non - operating ) SNOP - 50 G (4)
Vibration ( non - operating ) VNOP - 1.5 G (5)
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 93.8 % RH Max. (Ta 40 C)
b. Maximum wet-bulb temperature at 40 C or less. (Ta 40 C)
c. No condensation
(3) Polarizer will not be damaged in this range, even though abnormal visual problems occur
in TSUR range.
(4) 11ms, sine wave, one time for X, Y, Z axis
(5) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis
(40, 93.8)
(50, 50.4)
(65, 27.7)
Fig. Temperature and Relative humidity range
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 5 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. Optical Characteristics
The optical characteristics should be measured in a dark room or equivalent.
Measuring equipment : TOPCON BM-7,SPECTRORADIOMETER SR-3
(Ta = 25 2 C, VDD=12V, fv= 60Hz, fDCLK=148.5MHz, Dim = 100%)
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast Ratio (3)
C/R *2500 5000 -
(Center of screen) SR-3
Rising Tr - 12 70
Response Falling Tf - 8 18 (5)
msec
Time BM-7
G-to-G
Tg - 8 -
[AVE]
Luminance of White Normal (6)
YL 380 450 - cd/m2
(Center of screen) TL,R=0 SR-3
TU,D=0
Rx 0.639
Red
Ry Viewing 0.329
Angle
Gx 0.286
Green
Color Gy 0.605
TYP. TYP. (7),(8)
Chromaticity
Bx -0.03 0.148 +0.03 SR-3
(CIE 1931)
Blue
By 0.061
Wx 0.280
White
Wy 0.285
(7)
Color Gamut - - 72 - %
SR-3
Color Temperature - - 10000 - K (7)
Gamma - 2.2 - SR-3
TL 79 89 -
Hor.
Viewing TR 79 89 - (8)
C/R 10 Degree
Angle TU 79 89 - SR-3
Ver.
TD 79 89 -
Brightness Uniformity (4)
Buni - - 30 %
(9 Points) SR-3
* marked Items Value does not Specification above when "White stain" occurs at Center Point [Point of Note 2.]
Note (1) Test Equipment Setup
The measurement should be executed in a stable, windless and dark room between
40min and 60min after lighting the back light at the given temperature for stabilization
of the back light. This should be measured in the center of screen.
Single lamp current @ Vdim = 100%
Environment condition : Ta = 25 2 C
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 6 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Photo detector
Photo detector Field
SR-3 1
BM-7 2 Field
SR-3 : 50
BM-7 : 50
TFT - LCD Module
LCD Panel
The center of the screen
Note (2) Definition of test point
320 960 1600
180 Active Area
Test Point
540
900
Note (3) Definition of Contrast Ratio (C/R)
: Ratio of gray max (Gmax) & gray min (Gmin) at the center point of the panel
G max
C/R
G min
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 7 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Note (4) Definition of 9 points brightness uniformity
( B max B min)
Buni 100
B max
Bmax : Maximum brightness
Bmin : Minimum brightness
Note (5) Definition of Response time : Sum of Tr, Tf
Display data Black (data off) White (data on) White (data off)
TR TF
Optical Instruments
100%
Response
90%
10%
0%
TIME
Note (6) Definition of Luminance of White : Luminance of white at center point
Note (7) Definition of Color Chromaticity (CIE 1931)
Color coordinate of Red, Green, Blue & White at center point
Note (8) Definition of Viewing Angle
: Viewing angle range (C/R 10)
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 8 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3. Electrical Characteristics
3.1 TFT LCD Module
The connector for display data & timing signal should be connected.
Ta = 25 C 2 C
Item Symbol Min. Typ. Max. Unit Note
Voltage of Power Supply VDD 11 12 13 V (1)
(a) Black - 500 -
Current (b) White - 750 950
of Power IDD mA (2),(3)
Supply (c) Mosaic - 750 -
(4) Max Pattern - 800 1000
Vsync Frequency fV 47 60 62 Hz
Hsync Frequency fH 50 67.5 73 kHz
Main Frequency fDCLK 130 148.5 155 MHz
Rush Current IRUSH - - 5 A (4)
Note (1) The ripple voltage should be controlled under 10% of VDD.
(2) fV=60Hz, fDCLK = 148.5MHz, VDD = 12.0V, DC Current.
(3) Power dissipation check pattern (LCD Module only)
a) Black Pattern b) White Pattern c) Mosaic d)Max. Pattern
(4) Measurement Conditions
VDD
100%
90%
10%
GND
TRUSH=1ms
Rush Current IRUSH can be measured when TRUSH. is1ms
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 9 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3.2 Back Light Unit
The back light unit contains 10 CCFTs ( Cold Cathode Fluorescent Tube ).
The characteristics of lamps are shown in the following tables.
Ta=25 2C
Item Symbol Min. Typ. Max. Unit Note
Operating Life Time Hr 50,000 - - Hour (1)
Lamp Current Lc 6.0 - 15.0 mA -
Note (1) It is defined as the time to take until the brightness reduces to 50% of its original value.
[Operating condition : Ta = 25 2 , IL = 14 mArms(typ.), For single lamp only. ]
Socket
HOT 1
HOT 2
LCD
Inverter
Module
HOT 9
HOT 10
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 10 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. Block Diagram
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 11 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
5. Input Terminal Pin Assignment
5.1. Input Signal & Power Connector : IS050-C51B-C38(UJU)
Compatible with FI-RE51S-HF(JAE)
PIN No. Signal Description PIN No. Signal Description
1 Power VDD 26 LVE[0]P Even LVDS Signal +
2 Power VDD 27 LVE[1]N Even LVDS Signal -
3 Power VDD 28 LVE[1]P Even LVDS Signal +
4 Power VDD 29 LVE[2]N Even LVDS Signal -
5 Power VDD 30 LVE[2]P Even LVDS Signal +
6 GND GND 31 GND GND
7 GND GND 32 LVECLK- Even LVDS Clock-
8 GND GND 33 LVECLK+ Even LVDS Clock+
9 GND GND 34 GND GND
10 LVO[0]N Odd LVDS Signal - 35 LVE[3]N Even LVDS Signal -
11 LVO[0]P Odd LVDS Signal + 36 LVE[3]P Even LVDS Signal +
12 LVO[1]N Odd LVDS Signal - 37 N.C. No Connection
13 LVO[1]P Odd LVDS Signal + 38 N.C. No Connection
14 LVO[2]N Odd LVDS Signal - 39 GND GND
15 LVO[2]P Odd LVDS Signal + 40 SCL I2C SCL
16 GND GND 41 SDA I2C SDA
17 LVOCLK- Odd LVDS CLK - 42 VSYNC *V Sync Signal
18 LVOCLK+ Odd LVDS CLK + 43 B-INT Bus Release
19 GND GND 44 N.C. No Connection
20 LVO[3]N Odd LVDS Signal - 45 N.C. No Connection
21 LVO[3]P Odd LVDS Signal + 46 LUT SEL0 DCC LUT Select 0
22 N.C. No Connection 47 LUT SEL1 DCC LUT Select1
23 N.C. No Connection 48 LUT SEL2 DCC LUT Select2
24 GND GND 49 HSYNC H Sync Signal
25 LVE[0]N Even LVDS Signal - 50 TCON_RDY T-Con Ready
51 SEL1 SEC Internal Use Only
MODEL LTA400HM01
LTY400HM01 Doc. No 05-000-G-100316 Page 12 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
B-INT : I2C BUS RELEASE
Operation Description
SDA/SCL LINE BECOME HI-Z
HIGH USER CAN ACCESS EEPROM
DCC Look Up Table Selection
Description ( Based on DCC On)
Pin N.O. 48 47 46
LUT %(For Interpolate)
0 0 0 For 60Hz 100%
0 0 1 For 60Hz 100%X1.25
0 1 0 For 60Hz @ Low Temp. 100%X1.25
Select 0 1 1 For 60Hz @ Low Temp. (100%X1.25) X 1.25
bit 1 0 0 For 50Hz 100%
1 0 1 For 50Hz 100%X1.25
1 1 0
0%
1 1 1
TCON Ready
Operation Description
Low ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
