Image preview - the first page of the document
![Panel_SAMSUNG_LTA400HM07_0_[DS]](/pics/5eb0112345f76.gif)
>> Download Panel_SAMSUNG_LTA400HM07_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Product information
Customer :HAIER DATE : 12.Aug.2010
SAMSUNG TFT-LCD
TFT-
MODEL : LTA400HM07
The Information Described in this Specification is Preliminary and can be changed without
prior notice
LCD Business
Samsung Electronics Co . , LTD
LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (7)
3. Electrical Characteristics ----------------------------------------------------------------------------- (10)
3 El t i l Ch t i ti
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Inverter Input & specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
4.1 Input Signal & Power
4.2
4 2 Inverter Input Pin Configuration
4.3 Inverter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (18)
5.1 Timing Parameters (DE only mode)
5.2
5 2 LVDS Input data Characteristics
5.3 Timing Diagrams of interface Signal (DE only mode)
5.4 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (21)
7. Packing --------------------------------------------------------------------------------------------------- (23)
8. Marking & Others --------------------------------------------------------------------------------------- (24)
9. General Precaution ------------------------------------------------------------------------------------- (25)
9.1 Handling
9.2 Storage
9.3 Operation
9.4 Operation Condition Guide
p
9.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
* Revision History
Date Rev. No Page Summary
Aug
12,
12 000 all First issued
2010
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Samsung Secret
Description
LTA400HM07 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit The resolution of a 40 0" is
panel unit. 40.0
1920 x 1080 and this model can display up to 16.7 Million colors with wide viewing angle
of 89 or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD
TV and High Definition TV.
Features
RoHS compliance (Pb-free)
High contrast & aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response
FHD resolution (16:9)
Low Power consumption
Direct Type 12 CCFLs (Cold Cathode Fluorescent Lamp)
DE(Data Enable) mode
2Ch-LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
General Information
Items Specification Unit Note
952.0(HTYP) x 551.0(VTYP) 1.0mm
Module Size mm
56.6(DMAX)
Weight 10,000 (Max.) g
Pixel Pitch 0.46125(H) x 0.46125(W) mm
Active Display Area 885.6(H) X 498.15 (V) mm
Surface Treatment Anti Glare, Hard coating (3H) -
Display Colors 8bit ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
