Image preview - the first page of the document
![Panel_SAMSUNG_LTA400HM13_3_[DS]](/pics/5eb011eb88211.gif)
>> Download Panel_SAMSUNG_LTA400HM13_3_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Product Information
Customer : General DATE : 23. May. 2011
SAMSUNG TFT-LCD
TFT-
MODEL : LTA400HM13
The Information Described in this Specification is Preliminary and can be changed without
prior notice
LCD Business
Samsung Electronics Co . , LTD.
S El t i C LTD
MODEL LTA400HM13 Doc. No 06-000-G-20110523 Page 1 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3.
3 Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Converter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
4.1 Input Signal & Power
4.2
4 2 Converter Input Pin Configuration
4.3 Converter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (18)
5.1 Timing Parameters (DE only mode)
5.2 LVDS Input data Characteristics
5.3 Timing Diagrams of interface Signal (DE only mode)
5.4 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (21)
7. Packing --------------------------------------------------------------------------------------------------- (23)
8. Marking & Others --------------------------------------------------------------------------------------- (24)
9. General Precaution ----------------------------------------------------------------------------------- (25)
9.1 Handling
9.2 Storage
9.3 Operation
9.4 Operation Condition Guide
9.5 Others
MODEL LTA400HM13 Doc. No 06-000-G-20110523 Page 2 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Revision History
Date Rev. No Page Summary
Oct. 25.
000 all First issued
2010
Jan.12.
001 all TBD Items updated
2011
Jan.27.
002 4 Module size revised
2011
Feb. 22.
003 7 Color gamut modified (72% to 70%)
2011
7 Response time revised
Feb. 24.
004
2011
18 Input data position revised
MODEL LTA400HM13 Doc. No 06-000-G-20110523 Page 3 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
General Description
Description
LTA400HM13 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit
panel unit.
The resolution of a 40.0" is 1920 x 1080 and this model can display up to16.7 Million
colors with wide viewing angle of 89 or higher in all directions. This panel is intended to
support applications to provide a excellent performance for Flat Panel Display such as
Home-alone Multimedia TFT-LCD TV and High Definition TV.
Features
R HS compliance (Pb f )
RoHS li (Pb-free)
High contrast ratio & aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response
FHD resolution (16:9)
Low Power consumption
Edge Type LED (Light Emitted Diode) BLU
DE (Data Enable) mode
2ch LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
General Information
Items Specification
p Unit Note
921.7 (HTYP) x 536.3 (VTYP) 1.0mm
Module Size mm
31.7 (Max.)
Weight 8.9 (Max.) kg
Pixel Pitch 0.46125(H) x 0.15375(W) mm
Active Display Area 885.6 x 498.15 mm
Surface Treatment Anti-glare -
Display Colors 8bit ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
