Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTA460H2-L02_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center           www.panelook.com


                                                                         Product Information




             Date :: Oct. 25, 2004
              ate Oct. 25, 2004

                SAMSUNG TFT-LCD

                MODEL NO. : LTA460H2-L02



            Note :




            Any Modification of Spec is not allowed without SEC's permission.




                 Senior Engineer :


            PREPARED BY : AMLCD TECHNICAL CUSTOMER SERVICE TEAM
               Samsung Electronics Co . , LTD.




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



                                                                          Product Information
        Contents



        General Description                                            --------------------------    (3)
        1. Absolute Maximum Ratings                                    --------------------------    (4)
            1.1 Absolute Ratings Of Environment
            1.2 Electrical Absolute Ratings
        2. Optical Characteristics                                     --------------------------    (6)
        3. Electrical Characteristics                                  -------------------------- (10)
             3.1 TFT LCD Module
             3.2 Back-light Unit
        4. Block Diagram                                               -------------------------- (13)
            4.1 TFT LCD Module
            4.2 Back-light Unit
        5. Input   Terminal Pin Assignment                       -------------------------- (14)
             5.1   Input Signal & Power
             5.2   Inverter Control Connector
             5.2   LVDS Interface
             5.3   Inverter Unit
             5.5   Inverter Specification
             5.6   Input Signals, Basic Display Colors and Gray Scale of Each Color
        6. Interface Timing                                   -------------------------- (18)
             6.1 Timing Parameters (DE only mode)
             6.2 Timing Diagrams of interface Signal (DE only mode)
             6.3 Power ON/OFF Sequence
             6.4 Inverter Power Sequence
        7. Outline Dimension                                  -------------------------- (21)
        8. Packing                                                     --------------------------- (23)
        9. Marking & Others                                            --------------------------- (24)
        10. General Precautions                                        --------------------------- (26)




     Doc. No.         LTA460H2-L02           Rev. No.        0.0-041025           Page              1 / 27

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



                                                                            Product Information
      General Description

       * Description

       LTA460H2-L02 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
      (LCD) that uses amorphous silicon TFTs as a switching devices. This model is composed of a
      TFT LCD panel, a driver circuit and a back-light system. The resolution of a 46.0" contains
      1920 x 1080 pixels and can display up to 16.7 million colors with wide viewing angle of 85

◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
