Image preview - the first page of the document
![Panel_SAMSUNG_LTA460HQ08_0_[DS]](/pics/5eb016898dbed.gif)
>> Download Panel_SAMSUNG_LTA460HQ08_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Approval specification
Customer : HISENSE DATE : Aug. 31. 2010
SAMSUNG TFT-LCD
TFT-
MODEL : LTA460HQ08
Any modification of the specification is not allowed without the permission of Samsung.
NOTE :
DATE
Customer's Approval Aug. 31, 2010
SIGNATURE DATE DATE
Aug. 31, 2010
LCD Business
Samsung Electronics Co . , LTD.
S El t i C LTD
1 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
p ( )
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Converter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
4.1 Input Signal & Power
4.2 Converter Input Pin Configuration
4.3 Converter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (17)
5.1 Timing Parameters (DE only mode)
5.2
5 2 LVDS I Input data Characteristics
t d t Ch t i ti
5.3 Timing Diagrams of interface Signal (DE only mode)
5.4 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (20)
7. Reliability test -------------------------------------------------------------------------------------------- (22)
8. Packing --------------------------------------------------------------------------------------------------- (23)
9. Marking & Others --------------------------------------------------------------------------------------- (24)
10. General Precaution ----------------------------------------------------------------------------------- (25)
10.1 Handling
10.2
10 2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
2 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Revision History
Date Rev. No Page Summary
Aug. 24.
000 all First issued
2010
3 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Samsung Secret
Description
LTA460HQ08 is a color active matrix liquid crystal display (LCD) that uses amorphous silicon
TFT(Thin Film Transistor) as switching components This model is composed of a TFT LCD panel
components. panel,
a driver circuit and a back light unit. The resolution of a 46.0" is 1920 x 1080 and this model can
display up to 1.07 Billion colors with wide viewing angle of 89 or higher in all directions. This panel
is intended to support applications to provide a excellent performance for Flat Panel Display such
as Home-alone Multimedia TFT-LCD TV and High Definition TV
Features
RoHS compliance (Pb free)
(Pb-free)
High contrast ratio & aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response ( & Natural Motion (DFR: Double Frame Rate) )
FHD resolution (16:9)
Low Power consumption
Edge Type LED (Light Emitted Diode) BLU
DE (Data Enable) mode
2ch LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
General Information
Items Specification Unit Note
1076.5 (H) X 634.7 (V) 1.0mm
Module Size mm
23.9 (max)
Weight 11500 (Max) g
Pixel Pitch 0.53025(H) x 0.53025(W) mm
Active Display Area 1018.08 (H) X 572.67 (V) mm
Surface Treatment Antiglare, Hard-coating (3H)
Display Colors 10 bit ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
