Image preview - the first page of the document
![Panel_SAMSUNG_LTA480HN01_0_[DS]](/pics/5eb017dcc4307.gif)
>> Download Panel_SAMSUNG_LTA480HN01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Approval Spec
Customer : Hisense DATE : 08. Aug. 2011
SAMSUNG TFT-LCD
MODEL : LTA480HN01
Any Modification of Specification is not allowed without SEC's Permission.
NOTE :
DATE
08.Aug. 2011
DATE
08.Aug. 2011
LCD Business
Samsung Electronics Co . , LTD.
MODEL LTA480HN01 Doc. No 06-001-G-20110808 Page 1 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Converter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
4.1 Input Signal & Power
4.2 Converter Input Pin Configuration
4.3 Converter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (18)
5.1 Timing Parameters (DE only mode)
5.2 LVDS Input data Characteristics
5.3 Timing Diagrams of interface Signal (DE only mode)
5.4 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (21)
7. Reliability Test -------------------------------------------------------------------------------------------- (23)
8. Packing --------------------------------------------------------------------------------------------------- (24)
9. Marking & Others --------------------------------------------------------------------------------------- (25)
10. General Precaution ----------------------------------------------------------------------------------- (26)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
MODEL LTA480HN01 Doc. No 06-001-G-20110808 Page 2 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
Revision History
Date Rev. No Page Summary
29.July.
000 all First issued
2011
08.Aug.
001 4 Depth dimension changed
2011
MODEL LTA480HN01 Doc. No 06-001-G-20110808 Page 3 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
SAMSUNG SECRET
General Description
Description
LTA480HN01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit.
The resolution of a 48.0" is 1920 x 1080 and this model can display up to16.7 Million
colors with wide viewing angle of 89 or higher in all directions. This panel is intended to
support applications to provide a excellent performance for Flat Panel Display such as
Home-alone Multimedia TFT-LCD TV and High Definition TV.
Features
RoHS compliance (Pb-free)
High contrast ratio & aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response
FHD resolution (16:9)
Low Power consumption
Edge Type LED (Light Emitted Diode) BLU
DE (Data Enable) mode
2ch LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
General Information
Items Specification Unit Note
1078.6 (H) x 626.0 (V) 1.0mm
Module Size mm
32.4 (Dmax) Cover-converter
Weight 13.2 (max) kg
Pixel Pitch 0.5490(H) x 0.5490(W) mm
Active Display Area 1054.08 (H) x 592.92 (V) mm
Surface Treatment Anti-glare -
Display Colors 8bit ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
