Image preview - the first page of the document
![Panel_SAMSUNG_LTA550HF03_0_[DS]](/pics/5eb018c337cf2.gif)
>> Download Panel_SAMSUNG_LTA550HF03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product information
Customer : Gen_Kor ISSUED DATE : Jul. 31, 2009
SAMSUNG TFT-LCD
SAMSUNG TFT-
TFT-LCD
MODEL : LTA550HF03
MODEL : LTA550HF03
Any Modification of Specification is not allowed without SEC's Permission.
NOTE :
hwwyv}hlkGi DATE
Customer s Approval Jul.31.2009
zpnuh{|yl DATE wylwhylkGi DATE
Jul.31.2009
LCD Business
Samsung Electronics Co . , LTD.
MODEL LTA550HF03 Doc. No 06-000-G-090701 Page 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Revision History --------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
1.1 Back Light Unit Absolute Maximum Ratings
1.2 LED Unit Absolute Maximum Ratings
2. Optical Characteristics --------------------------------------------------------------------------------- (7)
3. Electrical Characteristics ----------------------------------------------------------------------------- (10)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 LED LIPS Condition & Specification
4. Block Diagram ------------------------------------------------------------------------------------------- (13)
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (14)
5.1 Input Signal & Power
5.2 LED LIPS AC Input Pin Configuration
5.3 LED LIPS Input & Output Pin Configuration
5.4 LED LIPS Power ON/OFF Sequence
5.5 LVDS Interface
5.6 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (21)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
7. Outline Dimension -------------------------------------------------------------------------------------- (23)
8. Reliability Test ------------------------------------------------------------------------------------------- (25)
9. Packing --------------------------------------------------------------------------------------------------- (26)
10. Marking & Others ------------------------------------------------------------------------------------- (27)
11. General Precaution ----------------------------------------------------------------------------------- (28)
11.1 Handling
11.2 Storage
11.3 Operation
11.4 Operation Condition Guide
11.5 Others
MODEL LTA550HF03 Doc. No 06-000-G-090701 Page 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History
Rev.
Date Page Summary
No
Jul
01, 000 all First issued
2009
MODEL LTA550HF03 Doc. No 06-000-G-090701 Page 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
Description
LTA550HF03 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit.
The resolution of a 55.0" is 1920 x 1080 and this model can display up to1.06 Billion
colors with wide viewing angle of 89◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
