Image preview - the first page of the document
![Panel_SAMSUNG_LTA550HJ03_0_[DS]](/pics/5eb019152a614.gif)
>> Download Panel_SAMSUNG_LTA550HJ03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Product Information
DATE : 09. Sep. 2010
SAMSUNG TFT-LCD
MODEL : LTI550HJ03
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Je-Hwan Oh 09.Sep.2010 Dong-Hyun Kim 09.Sep.2010
Application Engineering Part 3, LCD Division
Samsung Electronics Co . , LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Inverter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
4.1 Input Signal & Power
4.2 Inverter Input Pin Configuration
4.3 Inverter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (18)
5.1 Timing Parameters (DE only mode)
5.2 Timing Diagrams of interface Signal (DE only mode)
5.3 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (21)
7. Packing --------------------------------------------------------------------------------------------------- (24)
8. Marking & Others --------------------------------------------------------------------------------------- (25)
9. General Precaution ----------------------------------------------------------------------------------- (26)
9.1 Handling
9.2 Storage
9.3 Operation
9.4 Operation Condition Guide
9.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Revision History
Date Rev. No Page Summary
Sep. 09.
000 all First issued
2010
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Samsung Secret
Description
LTI550HJ03 is a color active matrix liquid crystal display (LCD) that uses amorphous silicon
TFT(Thin Film Transistor) as switching components. This model is composed of a TFT LCD panel,
a driver circuit and a back light unit. The resolution of a 55.0" is 1920 x 1080 and this model can
display up to 1.07 Billion colors with wide viewing angle of 89 or higher in all directions. This
panel is intended to support applications to provide a excellent performance for Flat Panel Display
such as Home-alone Multimedia TFT-LCD TV and High Definition TV
Features
RoHS compliance (Pb-free)
High contrast ratio & aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response ( & Natural Motion (DFR: Double Frame Rate) )
FHD resolution (16:9)
Low Power consumption
Direct Type 16 CCFLs(Cold Cathode Fluorescent Lamp)
DE(Data Enable) mode
4ch LVDS (Low Voltage Differential Signaling) interface (4pixel/clock)
General Information
Items Specification Unit Note
1,286 (H) X 745 (V)
Module Size mm 1.0mm
62.5
Weight 18,000 (Max) g
Pixel Pitch 0.630(H) x 0.630(W) mm
Active Display Area 1209.6(H) X 680.4(V) mm
Surface Treatment Antiglare, Hard-coating(3H)
Display Colors 1.07 Billion colors
Number of Pixels 1920 x 1080 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 450 (Typ.) cd/m2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 13.2 V
(1)
Dimming Control Max. Lum - 5 V
Storage temperature TSTG -20 60
(2)
Operating temperature TOPR 0 50
Surface temperature TSUR 0 60 (3)
Shock ( non - operating ) X,Y,Z 30 G (4)
Vibration ( non - operating ) VNOP - 1.5 G (5)
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b. Relative Humidity is 90% or less. (Ta 39 C)
c. No condensation
(3) Although abnormal visual problems can be occurred in TSUR range, the polarizer
is not damaged in this range.
(4) 11ms, sine wave, one time for X, Y, Z axis
(5) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis
Fig. Temperature and Relative humidity range
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. Optical Characteristics Samsung Secret
The optical characteristics should be measured in a dark room or equivalent.
Measuring equipment : TOPCON RD-80S, TOPCON SR-3, ELDIM EZ-Contrast
(Ta = 25 2 C, VDD=12V, fv= 120Hz, fDCLK = 297.0MHz, Lamp current = 11.5mA)
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast Ratio (1)
C/R 3,500 5,000 -
(Center of screen) SR-3
Response (3)
G-to-G Tg - 6 - msec
Time RD-80S
Luminance of White (4)
YL 400 450 - cd/m2
(Center of screen) SR-3
Rx Normal 0.637
Red qL,R =0
Ry 0.326
qU,D =0
Gx 0.287
Green
Color Gy Viewing 0.607
TYP. TYP. (5),(6)
Chromaticity Angle
Bx -0.03 0.150 +0.03 SR-3
(CIE 1931)
Blue
By 0.055
Wx 0.280
White
Wy 0.290
Color Gamut - - 72 - % (5)
SR-3
Color Temperature - - 10,000 - K
qL 75 89 -
Hor.
Viewing qR 75 89 - (6)
C/R10 Degree
Angle qU 75 89 - EZ-Contrast
Ver.
qD 75 89 -
White Brightness
(2)
Uniformity Buni - - 25 %
SR-3
(9 Points)
- Test Equipment Setup
The measurement should be executed in a stable, windless and dark room between
40min and 60min after lighting the back light at the given temperature for stabilization
of the back light. This should be measured in the center of screen.
Environment condition : Ta = 25 2 C
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Photo detector
Photo detector Field
SR-3 2
RD-80S 1 Field
SR-3 : 50
RD-80S : 50
TFT - LCD Module
LCD Panel
The center of the screen
- Definition of test point
320 960 1600
180 Active Area
Test Point
540
900
Note (1) Definition of Contrast Ratio (C/R)
: Ratio of gray max (Gmax) & gray min (Gmin) at the center point of the panel
G max
C/R
G min
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Note (2) Definition of 9 points brightness uniformity (Test pattern : Full White )
( B max B min)
Buni 100
B max
Bmax : Maximum brightness
Bmin : Minimum brightness
Note (3) Definition of Response time : Sum of Tr, Tf
Display data Black (data off) White (data on) Black (data off)
TR TF
Optical Instruments
100%
Response
90%
10%
0%
TIME
Note (4) Definition of Luminance of White : Luminance of white at center point
Note (5) Definition of Color Chromaticity (CIE 1931)
Color coordinate of Red, Green, Blue & White at center point
Note (6) Definition of Viewing Angle
: Viewing angle range (C/R 10)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
3. Electrical Characteristics
3.1 TFT LCD Module
The connector for display data & timing signal should be connected.
Ta = 25 C 2 C
Item Symbol Min. Typ. Max. Unit Note
Voltage of Power Supply VDD 10.8 12.0 13.2 V (1)
(a) Black - 700 1000 mA
Current of
Power (b) White IDD - 700 1000 mA (2),(3)
Supply
(c) H-STRIPE - 1200 1500 mA
Power Consumption (Control) Pc - 14.4 18 Watt
Vsync Frequency fV 90 120.0 125 Hz
Hsync Frequency fH 100 135.0 140 kHz
Main Frequency fDCLK 240 297.0 310 MHz
Rush Current IRUSH - - 7 A (4)
Note (1) The ripple voltage should be controlled under 10% of VDD.
(2) fV=120Hz, fDCLK = 297.0MHz, VDD = 12.0V, DC Current.
(3) Power dissipation check pattern (LCD Module only)
a) Black Pattern b) White Pattern c) H-STRIPE
(4) Measurement Conditions
VDD
100%
90%
10%
GND
TRUSH=470
Rush Current IRUSH can be measured when TRUSH. is 470 .
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
3.2 Back Light Unit
The back light unit contains 16 direct-lighting type CCFLs ( Cold Cathode Fluorescent
Lamp )
Ta=25 2 C
Socket
HOT 1
HOT 2
LCD
Inverter
Module
HOT 15
HOT 16
Item Symbol Min. Typ. Max. Unit Note
Operating Life Time Hr 50,000 - - Hour (1)
Note (1) It is defined as the time to take until the brightness reduces to 50% of its original
value.
[Operating condition : Ta = 25 2 , For single lamp only. ]
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
3.3 Inverter Input Condition & Specification
Specifications
Items Symbol Conditions Unit Note
Min. Typ. Max.
Input Ta=25
Vin - 22 24 26 V
Voltage
Input Vin=24.0V
IRUSH - - 10.72 A
Current Vdim =3.3V
(1)
Lamp
IO,MAX Vdim =3.3 V 10.4 11 11.6 mArms
Current
Shut-down Vin = 24V
T_SD 1.0 1.5 2.0 Sec -
Time Vdim =0~3.3V
Backlight ON Vin=24.0 V 2.4 - 5.25
V (2)
On/Off OFF Vin=24.0 V 0 - 0.8
Dimming Max Lum 3.3 - -
VDIM V (2)
Control Min. Lum - - 0
PWM Duty Duty Vin=24.0 V 20 - 100 % (3)
Note) Power Consumption is measured when 450 [cd/m ] of luminance which is the typical
luminance.
Lamp Current is measured at the point before Lamp.
(1) Max Value of the Power Consumption is measured after 60 min warm-up.
(2) The ripple voltage should be controlled under 10% of Input Signal
- Additional Appendix for Supply Current & Power consumption
Items Symbol Conditions Min. Typ. Max. Unit
Vin = 24V, Dim=3.3V
Iin _ overshoot - 8.3 8.85 A
Input (Within 1hr at BLU on)
Current Vin = 24V, Dim=3.3V
Iin _ saturation - 8.06 8.59 A
(After 1hr Aging)
Vin = 24V, Dim=3.3V
Power P _ overshoot - 199.2 212.4 Watt
(Within 1hr at BLU on)
Consumption
(Back light) Vin = 24V, Dim=3.3V
P _ saturation - 193.4 206.2 Watt
(After 1hr Aging)
* Initial turn-on time : From 0sec to 60min after turn-on
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. Input Terminal Pin Assignment Samsung Secret
4.1.1 Input Signal & Power Connector : FI-RE41S-HF (JAE/UJU)
Pin Description Pin Symbol Description
1 Vdd(12V) 21 Rx1[3]P
2 Vdd(12V) 22 Rx1[4]N
3 Vdd(12V) 23 Rx1[4]P
4 Vdd(12V) 24 GND
5 Vdd(12V) 25 Rx3[0]N
6 No Connection 26 Rx3[0]P
7 GND 27 Rx3[1]N
8 GND 28 Rx3[1]P
9 GND 29 Rx3[2]N
ODD LVDS
SIGNAL
10 Rx1[0]N 30 Rx3[2]P
11 Rx1[0]P 31 GND
12 Rx1[1]N 32 Rx3CLK-
13 Rx1[1]P 33 Rx3CLK+
14 Rx1[2]N 34 GND
ODD LVDS
15 Rx1[2]P 35 Rx3[3]N
SIGNAL
16 GND 36 Rx3[3]P
17 Rx1CLK- 37 Rx3[4]N
18 Rx1CLK+ 38 Rx3[4]P
19 GND 39 GND
20 Rx1[3]N 40 No Connection
41 No Connection
Note) No Connection: This PINS are only used for SAMSUNG internal using.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
4.1.2 Input Signal & Power Connector : FI-RE51S-HF (JAE/UJU)
Pin Description Pin Description
1 Vdd(12V) 26 Rx4[0]P
2 Vdd(12V) 27 Rx4[1]N
3 Vdd(12V) 28 Rx4[1]P
4 Vdd(12V) 29 Rx4[2]N
5 Vdd(12V) 30 Rx4[2]P
6 No Connection 31 GND
EVEN
7 GND 32 LVDS Rx4CLK-
SIGNAL
8 GND 33 Rx4CLK+
9 GND 34 GND
10 Rx2[0]N 35 Rx4[3]N
11 Rx2[0]P 36 Rx4[3]P
12 Rx2[1]N 37 Rx4[4]N
13 Rx2[1]P 38 Rx4[4]P
14 Rx2[2]N 39 GND
15 Rx2[2]P 40 No Connection
16 GND 41 No Connection
17 EVEN Rx2CLK- 42 No Connection
LVDS
18 SIGNAL Rx2CLK+ 43 No Connection
19 GND 44 No Connection
20 Rx2[3]N 45 LVDS Option * Note(1)
21 Rx2[3]P 46 No Connection
22 Rx2[4]N 47 No Connection
23 Rx2[4]P 48 No Connection
24 GND 49 No Connection
25 Rx4[0]N 50 No Connection
51 No Connection
NOTE) No connection : This Pins are only used for SAMSUNG internal using
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Secret
Note) Pin number starts from Right side
PCB
Pin No. 1 Pin No. 41 Pin No. 1 Pin No. 51
#1 #41 #1 #51
#1 #41 #1 #51
Fig. Connector diagram
a. All GND pins should be connected together and also be connected to the LCD's
metal chassis.
b. All power input pins should be connected together.
c. All NC pins should be separated from other signal or power.
Note(1) LVDS OPTION : If this PIN HIGH ( 3.3V ) Normal LVDS format
LOW ( GND ) JEIDA LVDS format
SEQUENCE : On = VDD(T1) LVDS Option Interface Signal(T2)
OFF = Interface Signal(T3) LVDS Option VDD
Vin T2 T3
LVDS
Option
LVDS
Signal
LVDS Option Sequence
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4.2. Inverter Input Pin Configuration Samsung Secret
Connector : 20022WR-14B1 (Yeon-ho)
Pin Configuration(FUNCTION)
Pin No.
Master
1 24 V
2 24 V
3 24 V
4 24 V
5 24 V
6 GND
7 GND
8 GND
9 GND
10 GND
11 Error Out
12 Backlight On /Off [ON:2.4 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
