Image preview - the first page of the document
![Panel_SAMSUNG_LTA550HJ06_0_[DS]](/pics/5eb0194c5559a.gif)
>> Download Panel_SAMSUNG_LTA550HJ06_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
Customer : GA DATE : 07.Apr.2010
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL : LTA550HJ06-W01
MODEL : LTA550HJ06-W01
Any Modification of Specification is not allowed without SEC's Permission.
NOTE :
DATE
Customer's Approval 07.Apr.2010
DATE DATE
07.Apr.2010
SUNOK.SONG
LCD Business
Samsung Electronics Co . , LTD.
1/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (7)
3. Electrical Characteristics ------------------------------------------------------------------------------ (10)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Inverter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
4.1 Input Signal & Power
4.2 Balance Board
4.3 LVDS Interface
4.4 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (19)
6.1 Timing Parameters (DE only mode)
6.2 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (22)
7. Reliability Test --------------------------------------------------------------------------------------------(24)
8. Packing --------------------------------------------------------------------------------------------------- (25)
9. Marking & Others ------------------------------------------------------------------------------------- (26)
10. General Precaution ----------------------------------------------------------------------------------- (27)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
2/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Revision History
Rev.
Date Page Summary
No
07.Mar
000 all First issued
.2010.
3/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
Description
LTA550HJ06 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit. The resolution of a 55.0" is
1920 x 1080 and this model can display up to 1.07 Billion colors with wide viewing angle of
89 or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD
TV and High Definition TV.
Features
RoHS compliance (Pb-free)
High contrast & ratio aperture ratio with wide color gamut
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response & Natural Motion (DFR: Double Frame Rate)
FHD resolution (16:9)
Low Power consumption
16 Normal CCFL (Cold Cathode Fluorescent Lamp)
DE(Data Enable) mode
LVDS (Low Voltage Differential Signaling) interface (4pixel/clock)
General Information
Items Specification Unit Note
(HTYP) x (VTYP) 1.5mm
Module Size mm
(Dtyp) 1.2mm
Weight 16500 g
Pixel Pitch mm
Active Display Area 1209.6(H) X 680.4(V) mm
Surface Treatment Haze 0%, Refection ratio 1% - Hard ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
