Image preview - the first page of the document
Panel_SAMSUNG_LTI400HA07_0_[DS]


>> Download Panel_SAMSUNG_LTI400HA07_0_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center           www.panelook.com




                                                                        Product Information




                                                                 DATE :29. Nov .2011

             SAMSUNG TFT-LCD

             MODEL : LTI400HA07

         The Information Described in this Specification is Preliminary and can be changed without
         prior notice




                                          DATE                                              DATE
                                      29. Nov.2011                                      29. Nov.2011



                 Application Engineering Group, LCD Division

                           Samsung Electronics Co . , LTD.




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com



                                                      Contents

   Revision History -------------------------------------------------------------------------------------------- (3)

   General Description --------------------------------------------------------------------------------------- (4)

   General Information --------------------------------------------------------------------------------------- (4)

   1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)

   2. Application information for DID (Digital Information Display) ---------------------------------- (6)

   3. Optical Characteristics --------------------------------------------------------------------------------- (7)

   4. Electrical Characteristics ----------------------------------------------------------------------------- (10)
      4.1 TFT LCD Module
      4.2 Back Light Unit
      4.3 Inverter Input & Specification

   5. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
      5.1 Input Signal & Power
      5.2 Inverter Input Pin Configuration
      5.3 Inverter Input Power Sequence
      5.4 LVDS Interface
      5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color

   6. Interface Timing ---------------------------------------------------------------------------------------- (18)
      6.1 Timing Parameters (DE only mode)
      6.2 Timing Diagrams of interface Signal (DE only mode)
      6.3 Power ON/OFF Sequence

   7. Outline Dimension -------------------------------------------------------------------------------------- (21)

   8. Packing --------------------------------------------------------------------------------------------------- (23)

   9. Marking & Others --------------------------------------------------------------------------------------- (24)

   10. General Precaution ----------------------------------------------------------------------------------- (25)
     10.1 Handling
     10.2 Storage
     10.3 Operation
     10.4 Operation Condition Guide
     10.5 Others




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com



   * Revision History

               Rev.
     Date               Page     Summary
                No
      29,
     Nov,       000       all    First issued
     2011




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



   General Description
    Description
    LTI400HA07 is a color active matrix liquid crystal display (LCD) that uses amorphous
    silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
    TFT LCD panel, a driver circuit and a back light unit. The resolution of a 40.0" is
    1920 x 1080 and this model can display up to 16.7 million colors with wide viewing angle
    of 89 or higher in all directions. This panel is intended to support applications to provide a
    excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV,
    Display terminals for AV application products, and Digital Information Display (DID).

   Features
       RoHS compliance (Pb-free)
       High contrast ratio, High aperture ratio
       SPVA(Super Patterned Vertical Align) mode
       Wide viewing angle ( 178 )
       High speed response
       Landscape / Portrait type compatible
       Wide UXGA (1920 x 1080 pixels) resolution (16:9)
       Low power consumption
       Direct Type 12 CCFTs(Cold Cathode Fluorescent Tube)
       DE(Data Enable) mode
       LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)

   General Information

              Items                           Specification                 Unit            Note
                                       952.0(WTYP) x 551.0(HTYP)                            1.0mm
           Module Size                                                       mm
                                               56.6(DMAX)
              Weight                          10,000(Max.)                    g
            Pixel Pitch                 0.46125(H) x 0.46125(V)              mm
       Active Display Area                885.6(H) x 498.15(V)               mm
        Surface Treatment             Haze 44% , Hard-coating (3H)
          Display Colors                      8 bit - 16.7M                colors
        Number of Pixels                      1920 x 1080                   pixel
        Pixel Arrangement                  RGB vertical stripe
          Display Mode                       Normally Black
       Luminance of White                      450 (Typ.)                   cd/m2




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




   1. Absolute Maximum Ratings
       If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
       damage to the device.

                      Item                      Symbol          Min.        Max.       Unit      Note

            Power Supply Voltage                  VDD         GND-0.3       13.2        V         (1)

             Storage temperature                  TSTG           -20         65                   (2)
       Glass surface
       temperature              Center          TCENTER           0          50                 (2),(5)
        (Operation)
           Shock ( non - operating )              Snop            -          50         G         (3)

         Vibration ( non - operating )            Vnop            -          1.5        G         (4)

     Note (1) Ta= 25 2 C
          (2) Temperature and relative humidity range are shown in the figure below.
              a. 90 % RH Max. (Ta  39 C)
              b. Relative Humidity is 90% or less. (Ta > 39 C)
              c. No condensation
          (3) 11ms, sine wave, one time for X, Y, Z axis
          (4) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis




                        Fig. Temperature and Relative humidity range




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



          (5) Definition of test point
                                    5mm

                            5mm



                                                     5

                                         LCD Module (Active)



                   TCENTER : Temperature of the center of the glass surface (Test point 5)




   2. Application information for DID (Digital Information Display)
    A long-term display like DID application may cause uneven display including image retention.
    To optimize module's lifetime and function, several operating usages are required.

    1. Normal operating condition
     - Temperature: 20 15
     - Humidity: 65 20 %
     - Display pattern: moving picture or regular switchover display
    Note) Long-term static information image may cause uneven display.

    2. Operating usages under abnormal operating condition. Note (1)
     a. Ambient condition
      - Well-ventilated place is recommended to set up DID system.
     b. Power off and screen saver
      - Periodical power-off or screen saver is needed after long-term static display. Note (2)

    3. Operating usages to protect uneven display due to long-term static information display
     a. Suitable operating time for B-DID : under 12 hours a day.
     b. Periodical display contents change from static image to moving picture.
      - Liquid crystal refresh time is required.
     c. Periodical background color and character (image) color change
      - Use different colors for background and character (image), respectively.
      - Change colors periodically.
     d. Avoid combination of background and character with large different luminance.

    Note (1) Abnormal condition means every operating condition except normal operating condition.
    Note (2) Moving picture or black pattern is strongly recommended for screen saver.

    4. Lifetime in this spec is guaranteed only when DID is used under right operating usages.




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com


  3. Optical Characteristics

     The optical characteristics should be measured in a dark room or equivalent.
     Measuring equipment : TOPCON BM-7,SPECTRORADIOMETER SR-3

                                (Ta = 25     2 C, VDD = 12V, fv = 60Hz, fDCLK = 148.5MHz, IL = 14mArms)
              Item            Symbol       Condition    Min.      Typ.      Max.      Unit       Note
         Contrast Ratio                                                                           (3)
                               C/R                      2000     3000        -
       (Center of screen)                                                                        SR-3
      Response                                                                                    (5)
                     G-to-G     Tg                        -        8         -       msec
        Time                                                                                     BM-7
      Luminance of White                                                                          (6)
                                YL                      350       450        -       cd/m2
       (Center of screen)                                                                        SR-3
                                            Normal
                                Rx         TL,R=0                0.637
                      Red                  TU,D=0
                                Ry                               0.331
                                Gx         Viewing               0.292
                     Green                  Angle
        Color                   Gy                               0.605
                                                        TYP.               TYP.                 (7),(8)
     Chromaticity
                                Bx                      -0.03    0.148     +0.03                 SR-3
     (CIE 1931)
                      Blue
                                By                               0.061
                                Wx                               0.280
                     White
                                Wy                               0.290
                                                                                                  (7)
          Color Gamut            -                        -        72        -         %
                                                                                                 SR-3
                                                                                                  (7)
       Color Temperature         -                        -     10,000       -         K
                                                                                                 SR-3
                                TL                       79        89        -
                      Hor.
       Viewing                  TR                       79        89        -                    (8)
                                           C/R10                                    Degree
        Angle                   TU                       79        89        -                    EZ
                      Ver.
                                TD                       79        89        -
      Brightness Uniformity                                                                       (4)
                                Buni                      -        -         25        %
            (9 Points)                                                                           SR-3



      Note (1) Test Equipment Setup

            The measurement should be executed in a stable, windless and dark room between
            40min and 60min after lighting the backlight at the given temperature for stabilization
            of the backlight. This should be measured in the center of screen.

            Single lamp current : 14mA
            Environment condition : Ta = 25       2 C




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center              www.panelook.com




                                           Photo detector
            Photo detector         Field

                SR-3                1

                BM-7                2                Field


                                                                                       SR-3 : 50
                                                                                       BM-7 : 50


                    TFT - LCD Module
                                                                                           LCD Panel




                                                            The center of the screen




       Note (2) Definition of test point
                             320              960                1600

                   180                                                           Active Area

                                                                                 Test Point
                   540


                   900




       Note (3) Definition of Contrast Ratio (C/R)
                : Ratio of gray max (Gmax) & gray min (Gmin) at the center point              of the panel

                       G max
              C/R
                       G min
                       Gmax : Luminance with all pixels white
                       Gmin : Luminance with all pixels black




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center            www.panelook.com




       Note (4) Definition of 9 points brightness uniformity

                             ( B max B min)
                 Buni 100
                                  B max
                     Bmax : Maximum brightness
                     Bmin : Minimum brightness

       Note (5) Definition of Response time : Sum of Tr, Tf

                  Display data       Black (data off)     White (data on)       White (data off)


                                                   TR                            TF
       Optical Instruments
                          100%
           Response
                           90%




                             10%
                              0%
                                                                                               TIME

        Note (6) Definition of Luminance of White : Luminance of white at center point

        Note (7) Definition of Color Chromaticity (CIE 1931)
                 Color coordinate of Red, Green, Blue & White at center point

        Note (8) Definition of Viewing Angle
                 : Viewing angle range (C/R  10)




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



    4. Electrical Characteristics

     4.1 TFT LCD Module
         The connector for display data & timing signal should be connected.
                                                                            Ta = 25 C              2 C
                    Item                   Symbol       Min.      Typ.      Max.       Unit      Note
     Voltage of Power Supply                 VDD       10.8       12.0      13.2        V         (1)
                  (a) Black                              -        720         -        mA
     Current
     of Power     (b) White                  IDD         -        1350        -        mA       (2),(3)
     Supply
                  (c) N-Pattern                          -        1290        -        mA
     Vsync Frequency                          fV       48.0       60.0      62.0        Hz
     Hsync Frequency                          fH       50.0       67.5      75.0       kHz
     Main Frequency                         fDCLK      130.0     148.5      155.0      MHz
     Rush Current                           IRUSH        -          -         3         A         (4)

     Note (1) The ripple voltage should be controlled under 10% of VDD.
          (2) fV = 60Hz, fDCLK = 148.5MHz, VDD = 12.0V, DC Current.
          (3) Power dissipation check pattern (LCD Module only)
         a) Black Pattern      b) White Pattern        c) N-Pattern




          (4) Measurement Conditions

                                                                                       VDD
                  100%
                   90%


                    10%
                    GND


                                                     TRUSH=470
                    Rush Current IRUSH can be measured when TRUSH. is 470 .




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com




    4.2 Back Light Unit

     The back light unit contains 12 direct-lighting type CCFTs (Cold Cathode Fluorescent
     Tube). The characteristics of lamps are shown in the following tables.
                                                                               Ta=25 2 C
                 Item                  Symbol           Min.      Typ.      Max.          Unit         Note
             Lamp Current                 IL            8.0       14.0      16.0         mArms
             Lamp Voltage                VL             825       855        955          Vrms
          Operating Life Time            Hr         50,000         -          -           Hour         (1)


    Note (1) It is defined as the time to take until the brightness reduces to 50% of its original value.
             [Operating condition : Ta = 25 2 , IL = 14.0mArms, For single lamp only]




                                               HOT 1                       COLD 1


              Inverter                         HOT 2                       COLD 2                GND


                                                                LCD
                                                               Module


                                               HOT 11                     COLD 11


                                               HOT 12                     COLD 12




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




   4.3 Inverter Input Condition & Specification

                                                          Specifications
      Items        Symbol        Conditions                                        Unit        Note
                                                   Min.       Typ.         Max.
      Input
                     Vin              -             22         24          26       V      Ta=25
     Voltage
      Input                      Vin=24.0V
                      Iin                            -        5.32         5.68     A
     Current                     Vdim=3.3V
      Lamp                                                                                  After 1 hour
                    IO,MAX       Vdim=3.3V         13.3       14.0         14.7   mArms
     Current                                                                                 Warm-up
                                 Vin=24.0V
   Frequency        FLAMP                           46         48          50      kHz
                                 Vdim=3.3V

    Backlight        ON                            2.4          -          5.25
                                 Vin=24.0V                                          V            -
     On/Off          OFF                            0           -          0.8

    Internal
                       -         Vin=24.0V          0           -          3.3      V
    Dimming


      Note (1) Power Consumption is measured at 450[cd/m2] of luminance condition which is
                the typical luminance value. Lamp Current is measured at the point before Lamp.




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com




    5. Input Terminal Pin Assignment

     5.1 Input Signal & Power                                      Connector : FI-RE51S-HF (JAE)
            PIN No.                  Description                 PIN No.                Description

               1                      Vdd (12V)                    26                              RE[0]P

               2                      Vdd (12V)                    27                              RE[1]N

               3                      Vdd (12V)                    28                              RE[1]P

               4                      Vdd (12V)                    29                              RE[2]N
               5                      Vdd (12V)                    30                              RE[2]P
                                                                                    Even
               6                   No Connection                   31               LVDS            GND
                                                                                    Signal
               7                         GND                       32                              RECLK-

               8                         GND                       33                              RECLK+

               9                         GND                       34                               GND

               10                              RO[0]N              35                              RE[3]N

               11                              RO[0]P              36                              RE[3]P

               12                              RO[1]N              37                  No Connection

               13                              RO[1]P              38                  No Connection

               14                              RO[2]N              39                        GND

               15                Odd           RO[2]P              40                  No Connection
                                LVDS
               16               Signal            GND              41                  No Connection

               17                              ROCLK-              42                  No Connection

               18                              ROCLK+              43                  No Connection

               19                                 GND              44                  No Connection

               20                              RO[3]N              45                  LVDS Option
               21                              RO[3]P              46                  No Connection

               22                  No Connection                   47                  No Connection
               23                  No Connection                   48                  No Connection

               24                        GND                       49                  No Connection

               25             Even LVDS        RE[0]N              50                  No Connection

                                                                   51                  No Connection

      Note(1) No Connection :These pins are only used for SAMSUNG internal purpose.
          (2) LVDS Option : High (3.3 V)  Normal LVDS format
                          : Low (GND) or Open (N.C)  JEIDA LVDS format
              Sequence :On = VDD(T1)  LVDS Option  Interface Signal(T2)
                        Off = Interface Signal(T3)  LVDS Option  VDD




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com




      Note (3) LVDS Connector




                                                 PCB


                                          Pin No. 1   Pin No. 51




                                     #1                               #51




                                      #1                            #51




                                          Fig. Connector diagram

              a. All GND pins should be connected together and also be connected to the LCD's
                 metal chassis.
              b. All power input pins should be connected together.
              c. All N.C pins should be separated from other signal or power.




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center             www.panelook.com




       5.2 Inverter Input Pin Configuration
                                                             Connector : YEON HO, 20022WR-14B1

            Pin No.                              Pin Configuration(FUNCTION)

               1                                           Vin (24V)
               2                                           Vin (24V)
               3                                           Vin (24V)
               4                                           Vin (24V)
               5                                           Vin (24V)
               6                                              GND
               7                                              GND
               8                                              GND
               9                                              GND
               10                                             GND
               11                                        No connection
               12                     Backlight On /Off [On: 2.4 ~ 5.25V, Off: 0 ~ 0.8V]
               13                INT DIM :INTERNAL DIMMING SIGNAL (0V: Min 3.3V: Max)
               14                                        No connection

      Note (5) LVDS Connector

      5.3 Inverter Input Power Sequence

                                                                                  1.1sec [Min]
                                      0.9 Vin
                    20msec [Min]
        Vin (24V)
                                    0.1 Vin


        Dimming Control


                       0.5sec [Min]
                                                                                   0.5sec [Min]

        Back Light On/Off                        2.4 V




                                      0.5sec [Min]                 0.1sec [Min]




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com



     5.4 LVDS Interface
       - LVDS Receiver : Tcon (merged)
       - Data Format (JEIDA & Normal)                               Default LVDS Option : JEIDA




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                           www.panelook.com



  5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color

                                                                          DATA SIGNAL
                                                                                                                                            GRAY
           DISPLAY
   COLOR                              RED                                   GREEN                                  BLUE                     SCALE
             (8bit)
                                                                                                                                            LEVEL
                      R0   R1   R2   R3   R4   R5   R6   R7   G0 G1 G2 G3 G4 G5 G6 G7               B0   B1   B2   B3   B4   B5   B6   B7

            BLACK     0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

            BLUE      0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   1    1    1    1    1    1    1    1

           GREEN      0    0    0    0    0    0    0    0    1   1   1      1   1   1      1   1   0    0    0    0    0    0    0    0

   BASIC    CYAN      0    0    0    0    0    0    0    0    1   1   1      1   1   1      1   1   1    1    1    1    1    1    1    1
   COLOR     RED      1    1    1    1    1    1    1    1    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

           MAGENTA    1    1    1    1    1    1    1    1    0   0   0      0   0   0      0   0   1    1    1    1    1    1    1    1

           YELLOW     1    1    1    1    1    1    1    1    1   1   1      1   1   1      1   1   0    0    0    0    0    0    0    0

            WHITE     1    1    1    1    1    1    1    1    1   1   1      1   1   1      1   1   1    1    1    1    1    1    1    1

            BLACK     0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

                      1    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

            DARK      0    1    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0
   GRAY
   SCALE              :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
     OF               :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
    RED
            LIGHT     1    0    1    1    1    1    1    1    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

                      0    1    1    1    1    1    1    1    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

             RED      1    1    1    1    1    1    1    1    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

            BLACK     0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

                      0    0    0    0    0    0    0    0    1   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

            DARK      0    0    0    0    0    0    0    0    0   1   0      0   0   0      0   0   0    0    0    0    0    0    0    0
   GRAY
   SCALE              :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
    OF                :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
   GREEN
            LIGHT     0    0    0    0    0    0    0    0    1   0   1      1   1   1      1   1   0    0    0    0    0    0    0    0

                      0    0    0    0    0    0    0    0    0   1   1      1   1   1      1   1   0    0    0    0    0    0    0    0

           GREEN      0    0    0    0    0    0    0    0    1   1   1      1   1   1      1   1   0    0    0    0    0    0    0    0

            BLACK     0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    0    0    0    0    0    0    0

                      0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   1    0    0    0    0    0    0    0

            DARK      0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    1    0    0    0    0    0    0
   GRAY
   SCALE              :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
     OF               :    :    :    :    :    :              :   :   :      :   :      :           :    :    :    :    :    :
    BLUE
            LIGHT     0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   1    0    1    1    1    1    1    1

                      0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   0    1    1    1    1    1    1    1

            BLUE      0    0    0    0    0    0    0    0    0   0   0      0   0   0      0   0   1    1    1    1    1    1    1    1



     Note) Definition of Gray :
         Rn : Red Gray, Gn : Green Gray, Bn : Blue Gray (n = Gray level)
         Input Signal : 0 = Low level voltage, 1 = High level voltage




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




     6. Interface Timing

       6.1 Timing Parameters (DE only mode)

          Signal             Item          Symbol        Min.      Typ.     Max.       Unit      Note

           Clock                             1/TC       130.0     148.5     155.0      MHz         -
          Hsync           Frequency           FH         50.0      67.5      75.0      KHz         -
           Vsync                              FV          48        60       62         Hz         -
                           Active
                           Display           TVD           -      1080        -       Lines        -
          Vertical         Period
       Display Term
                           Vertical
                                              TV         1100     1125      1158      Lines        -
                            Total
                           Active
                           Display           THD           -      1920        -       Clocks       -
        Horizontal         Period
       Display Term
                          Horizontal
                                              TH         2090     2200      2350      Clocks       -
                            Total


       Note) Note) Requirement: ODD channel



◦ Jabse Service Manual Search 2026 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
