Image preview - the first page of the document
![Panel_SAMSUNG_LTI400HA08-V_1_[DS]](/pics/5eb01ea9be16f.gif)
>> Download Panel_SAMSUNG_LTI400HA08-V_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Product Information
DATE : Nov. 29, 2011
SAMSUNG TFT-LCD
MODEL : LTI400HA08
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Nov.29,2011 Nov.29,2011
Application Engineering Part, LCD Division
Samsung Electronics Co . , LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for DID (Digital Information Display) ---------------------------------- (6)
3. Optical Characteristics --------------------------------------------------------------------------------- (7)
4. Electrical Characteristics ----------------------------------------------------------------------------- (10)
4.1 TFT LCD Module
4.2 Back Light Unit
4.3 Inverter Input & Specification
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
5.1 LVDS Connector
5.2 Inverter Input Pin Configuration
5.3 Inverter Input Power Sequence
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (18)
6.1 Timing Parameters (DE mode)
6.2 Timing Diagrams of interface Signal (DE mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (21)
8. Packing --------------------------------------------------------------------------------------------------- (23)
9. Marking & Others --------------------------------------------------------------------------------------- (25)
10. General Precaution ----------------------------------------------------------------------------------- (26)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
* Revision History
Rev.
Date Page Summary
No
Nov.
29, 000 all First issued
2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Samsung Confidential
Description
LTI400HA08 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 40" is
1920 x 1,080 and this model can display up to 16.7M colors with wide viewing angle of 89
or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV,
Display terminals for AV application products, and Digital Information Display (DID).
Features
RoHS compliance (Pb-free)
High contrast ratio, High aperture structure, High luminance Landscape / Portrait
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
Landscape / Portrait type compatible
Screen
Screen
FHD (1920 x 1080 pixels) resolution (16:9)
Low power consumption
Direct type 12 CCFLs(Cold Cathode Fluorescent Lamp) Landscape
DE(Data Enable) mode Portrait
2ch LVDS (Low Voltage Differential Signaling) interface
High Tni (85 ) Liquid crystal
General Information
Items Specification Unit Note
911.7(WTYP) x 524.2(HTYP)
Module Size mm 1.0mm
61.6(Dmax)
Weight 13,000(Max) g
Pixel Pitch 0.46125(H) x 0.46125(V) mm
Active Display Area 885.6(H) x 498.15(V) mm
Surface Treatment Haze 44%, Hard-coating(3H)
Display Colors 8 bit - 16.7M colors
Number of Pixels 1920 x 1,080 pixel 16 : 9
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 700 (Typ.) cd/m2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD 10.8 13.2 V (1)
Storage temperature TSTG -20 65 (2)
Glass surface TCENTER 0 50
temperature Center (2),(5)
(Operation) TSUR 0 65
Shock ( non - operating ) Snop x,y,z - 50 G (3)
Vibration ( non - operating ) Vnop - 1.5 G (4)
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b. Relative Humidity is 90% or less. (Ta > 39 C)
c. No condensation
(3) 20ms, sine wave, one time for X, Y, Z axis
(4) 10-300 Hz, Sweep rate 11min, 30min for X,Y,Z axis
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
(5) Definition of test point
5mm
5mm
5
LCD Module (Active)
TCENTER : Temperature of the center of the glass surface (Test point 5)
2. Application information for DID (Digital Information Display)
A long-term display like DID application may cause uneven display including image retention.
To optimize module's lifetime and function, several operating usages are required.
1. Normal operating condition
a. Temperature: 20 15
b. Humidity: 55 20 %
c. Display pattern: moving picture or regular switchover display
Note) Long-term static information image may cause uneven display.
2. Operating usages under abnormal operating condition. Note (1)
a. Ambient condition
- Well-ventilated place is recommended to set up DID system.
b. Power off and screen saver
- Periodical power-off or screen saver is needed after long-term static display. Note (2)
3. Operating usages to protect uneven display due to long-term static information display
a. Suitable operating time for P-DID : under 20 hours a day.
b. Periodical display contents change from static image to moving picture.
- Liquid crystal refresh time is required.
c. Periodical background color and character (image) color change
- Use different colors for background and character (image), respectively.
- Change colors periodically.
d. Avoid combination of background and character with large different luminance.
Note (1) Abnormal condition means every operating condition except normal operating condition.
Note (2) Moving picture or black pattern is strongly recommended for screen saver.
4. Lifetime in this spec is guaranteed only when DID is used under right operating usages.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
3. Optical Characteristics
The optical characteristics should be measured in a dark room or equivalent.
Measuring equipment : TOPCON BM-5A, BM-7, SR-3, RD-80S
(Ta = 25 2 C, VDD = 12V, fV = 60Hz, fDCLK = 148.5 MHz, IL=14mArms)
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast Ratio (3)
C/R 2000 3000 -
(Center of screen) SR-3
Response (5)
G-to-G Tg - 8 16 msec
Time BM-7
Luminance of White (6)
YL 600 700 - cd/m2
(Center of screen) SR-3
Normal
Rx TL,R=0 0.637
Red TU,D=0
Ry 0.331
Gx Viewing 0.292
Green Angle
Color Gy 0.605
TYP. TYP. (7),(8)
Chromaticity
Bx -0.03 0.148 +0.03 SR-3
(CIE 1931)
Blue
By 0.061
Wx 0.280
White
Wy 0.290
(7)
Color Gamut - 69 72 - %
SR-3
(7)
Color Temperature - 7000 10000 13000 K
SR-3
TL 75 89 -
Hor.
Viewing TR 75 89 - (8)
C/R10 Degree
Angle TU 75 89 - EZ
Ver.
TD 75 89 -
Brightness Uniformity (4)
Buni - - 25 %
(9 Points) SR-3
Note (1) Test Equipment Setup
The measurement should be executed in a stable, windless and dark room between
40min and 60min after lighting the backlight at the given temperature for stabilization
of the backlight. This should be measured in the center of screen.
Single lamp current : 14mA
Environment condition : Ta = 25 2 C
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Photo detector Field Photo
detector
BM-5A 2
BM-7 2 Field
PR-650 1
SR-3 1
50
TFT - LCD Module
LCD Panel
The center of the screen
Note (2) Definition of test point
320 960 1600
Active Area
180
540 Test Point
900
Note (3) Definition of Contrast Ratio (C/R)
: Ratio of gray max (Gmax) & gray min (Gmin) at the center point of the panel
G max
C/R
G min
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black
Note (4) Definition of 9 points brightness uniformity
( B max B min)
Buni 100
B max
Bmax : Maximum brightness
Bmin : Minimum brightness
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Note (5) Definition of Response time : Average response time of all Gray to Gray
Display data Low Gray High Gray Low Gray
TR TF
100%
90%
Optical Instruments
Response
10%
0%
Time
Gray to Gray Response Time
End
Gray
0 31 63 95 127 159 191 223 255
0 Tr(0-31) Tr(0-63) Tr(0-95) Tr(0-127) Tr(0-159) Tr(0-191) Tr(0-223) Tr(0-255)
31 Tf(31-0) Tr(31-63) Tr(31-95) Tr(31-127) Tr(31-159) Tr(31-191) Tr(31-223) Tr(31-255)
63 Tf(63-0) Tf(63-31) Tr(63-95) Tr(63-127) Tr(63-159) Tr(63-191) Tr(63-223) Tr(63-255)
95 Tf(95-0) Tf(95-31) Tf(95-63) Tr(95-127) Tr(95-159) Tr(95-191) Tr(95-223) Tr(95-255) Ton
Start 127 Tf(127-0) Tf(127-31) Tf(127-63) Tf(127-95) Tr(127-159) Tr(127-191) Tr(127-223) Tr(127-255)
159 Tf(159-0) Tf(159-31) Tf(159-63) Tf(159-95) Tf(159-127) Tr(159-) Tr(159-223) Tr(159-255)
191 Tf(191-0) Tf(191-31) Tf(191-63) Tf(191-95) Tf(191-127) Tf(191-159) Tr(191-) Tr(191-255)
223 Tf(223-0) Tf(223-31) Tf(223-63) Tf(223-95) Tf(223-127) Tf(223-159) Tf(223-191) Tr(233-255)
255 Tf(255-0) Tf(255-31) Tf(255-63) Tf(255-95) Tf(255-127) Tf(255-159) Tf(255-191) Tf(255-223)
Toff
T*(X-Y) : Response time from level of gray(X) to level of gray(Y)
Response time Definition = [T*(X-Y)] / 72
Note (6) Definition of Luminance of White : Luminance of white at center point
Note (7) Definition of Color Chromaticity (CIE 1931)
Color coordinate of Red, Green, Blue & White at center point
Note (8) Definition of Viewing Angle
: Viewing angle range (C/R 10)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
4. Electrical Characteristics
4.1 TFT LCD Module
The connector for display data & timing signal should be connected.
Ta = 25 C 2 C , None synchronization with the Inverter
Item Symbol Min. Typ. Max. Unit Note
Voltage of Power Supply VDD 10.8 12.0 13.2 V (1)
(a) Black - 800 - mA
Current
of Power (b) White IDD - 1350 - mA (2),(3)
Supply
(c) N-Pattern - 1400 - mA
Vsync Frequency fV - 60 - Hz
Hsync Frequency fH 50 67.5 75 kHz
Main Frequency fDCLK 130 148.5 155 MHz
Rush Current IRUSH - - 3 A (4)
Note (1) The ripple voltage should be controlled under 10% of VDD.
(2) fV = 60Hz, fDCLK =148.5MHz, VDD = 12.0V, DC Current.
(3) Power dissipation check pattern (LCD Module only).
a) Black Pattern b) White Pattern c) N-pattern
(4) Measurement Conditions
VDD
100%
90%
10%
GND
TRUSH=470
Rush Current IRUSH can be measured when TRUSH. is 470 .
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
4.2 Back Light Unit
The backlight unit contains 12 direct-lighting type CCFLs (Cold Cathode Fluorescent Lamp).
The characteristics of lamps are shown in the following tables.
Ta=25 2C
Item Symbol Min. Typ. Max. Unit Note
Lamp Current IL 8 14 16 mArms
Lamp Voltage VL 825 855 995 Vrms
Operating Life Time Hr 50,000 - - Hour (1)
Note (1) It is defined as the time to take until the brightness reduces to 50% of its original value.
[Operating condition : Ta = 25 2 , IL = 14.0 mArms, For single lamp only. ]
Inverter
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
4.3 Inverter Input condition & Specification
Specifications
Items Symbol Conditions Unit Note
Min. Typ. Max.
Input
Vin - 22 24 26 V Ta=25
Voltage
Input Vin = 24V After 1hour
Iin - 5.32 5.68 A
Current Vdim = 3.3V Warm-up
Output Vin = 24V After 1 hour
IO,MAX 13.3 14 14.7 mArms
Current Vdim = 3.3V Warm-up
Frequency FLAMP Vin = 24V 41 43 45 kHz
ON Vin = 24.0V 2.4 - 5.25
Backlight
V
On/Off
OFF Vin = 24.0V 0 - 0.8
High-Duty 30 - 100 %
External High (ON) 3.0 - 5.25 V
Dimming - (2)
Control Low (OFF) 0 - 0.4 V
Fpwm 140 150 160 Hz
Note (1) Power Consumption is measured at 700[cd/m2] of luminance condition which is
the typical luminance value. Lamp Current is measured at the point before Lamp.
Note (2) High-duty = On/(On+Off) * 100
On Off
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
5. Input Terminal Pin Assignment
5.1 Input Signal & Power
Connector : FI-RE51S-HF (JAE/UJU)
PIN No. Description PIN No. Description
1 Vdd (12V) 26 RE[0]P
2 Vdd (12V) 27 RE[1]N
3 Vdd (12V) 28 RE[1]P
4 Vdd (12V) 29 RE[2]N
5 Vdd (12V) 30 RE[2]P
6 No Connection(1) 31 GND
Even
7 GND 32 LVDS RECLK-
Signal
8 GND 33 RECLK+
9 GND 34 GND
10 RO[0]N 35 RE[3]N
11 RO[0]P 36 RE[3]P
12 RO[1]N 37 No Connection(1)
13 RO[1]P 38 No Connection(1)
14 RO[2]N 39 GND
15 RO[2]P 40 No Connection (1)
16 Odd GND 41 No Connection(1)
LVDS
17 Signal ROCLK- 42 No Connection (1)
18 ROCLK+ 43 No Connection(1)
19 GND 44 No Connection (1)
20 RO[3]N 45 LVDS_SEL (2)
21 RO[3]P 46 No Connection(1)
22 No Connection(1) 47 No Connection(1)
23 No Connection(1) 48 No Connection(1)
24 GND 49 No Connection (1)
25 Even LVDS RE[0]N 50 No Connection(1)
51 No Connection (1)
Note (1) No Connection : These pins are only used for SAMSUNG internal purpose.
Note (2) LVDS OPTION : IF THIS PIN : HIGH (3.3 V) NORMAL NS LVDS FORMAT
OTHERWISE : LOW (GND) OR OPEN(NC) JEIDA LVDS FORMAT
Sequence : On = VDD(T1) LVDS Option Interface Signal(T2)
OFF = Interface Signal(T3) LVDS Option VDD
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Note (3) LVDS Connector
PCB
Pin No. 1 Pin No. 51
#1 #51
#1 #51
Fig. Connector diagram
a. All GND pins should be connected together and also be connected to the LCD's
metal chassis.
b. All power input pins should be connected together.
c. All N.C pins should be separated from other signal or power.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
5.2 Inverter Input Pin Configuration
Connector : JST, S14B-PHA-SM3-TB
Pin No. Pin Configuration(FUNCTION)
1 Vin (24V)
2 Vin (24V)
3 Vin (24V)
4 Vin (24V)
5 Vin (24V)
6 GND
7 GND
8 GND
9 GND
10 GND
11 Error out (Normal: GND , Abnormal: Open Collector output)
ENA (Converter on/off Control signal)
12
DC 0 to 0.8V off, DC 2.4 to 5.25V On
13 No connection
14 External PWM Dimming [30%: Min, 100%: Max]
Note) Pin 13 Must be disconnected from signal (No connection)
5.3 Inverter Input Power Sequence
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
5.4 LVDS Interface
- LVDS Receiver : Tcon (merged)
- Data Format (JEIDA & Normal)
Default LVDS Option : JEIDA
LVDS pin JEIDA -DATA VESA -DATA
TxIN/RxOUT0 R2 R0
TxIN/RxOUT1 R3 R1
TxIN/RxOUT2 R4 R2
TxOUT/RxIN0 TxIN/RxOUT3 R5 R3
TxIN/RxOUT4 R6 R4
TxIN/RxOUT6 R7 R5
TxIN/RxOUT7 G2 G0
TxIN/RxOUT8 G3 G1
TxIN/RxOUT9 G4 G2
TxIN/RxOUT12 G5 G3
TxOUT/RxIN1 TxIN/RxOUT13 G6 G4
TxIN/RxOUT14 G7 G5
TxIN/RxOUT15 B2 B0
TxIN/RxOUT18 B3 B1
TxIN/RxOUT19 B4 B2
TxIN/RxOUT20 B5 B3
TxIN/RxOUT21 B6 B4
TxOUT/RxIN2 TxIN/RxOUT22 B7 B5
TxIN/RxOUT24 HSYNC HSYNC
TxIN/RxOUT25 VSYNC VSYNC
TxIN/RxOUT26 DEN DEN
TxIN/RxOUT27 R0 R6
TxIN/RxOUT5 R1 R7
TxIN/RxOUT10 G0 G6
TxOUT/RxIN3 TxIN/RxOUT11 G1 G7
TxIN/RxOUT16 B0 B6
TxIN/RxOUT17 B1 B7
TxIN/RxOUT23 RESERVED RESERVED
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
DATA SIGNAL
DISPLA GRAY
COLOR Y RED GREEN BLUE SCALE
(8bit) LEVEL
R0 R1 R2 R3 R4 R5 R6 R7 G0 G1 G2 G3 G4 G5 G6 G7 B0 B1 B2 B3 B4 B5 B6 B7
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -
BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 -
GREEN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 -
CYAN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -
BASIC
COLOR RED 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -
MAGEN
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 -
TA
YELLOW 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 -
WHITE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R0
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1
DARK 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R2
GRAY
: : : : : : : : : : : : : : : : : :
SCALE R3~
OF R252
: : : : : : : : : : : : : : : : : :
RED
LIGHT 1 0 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R253
0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R254
RED 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R255
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G0
0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G1
DARK 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G2
GRAY
: : : : : : : : : : : : : : : : : :
SCALE G3~
OF G252
: : : : : : : : : : : : : : : : : :
GREEN
LIGHT 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G253
0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G254
GREEN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G255
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 B0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 B1
DARK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 B2
GRAY : : : : : : : : : : : : : : : : : :
B3~
SCALE
B252
OF BLUE : : : : : : : : : : : : : : : : : :
LIGHT 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 B253
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 B254
BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 B255
Note) Definition of Gray :
Rn : Red Gray, Gn : Green Gray, Bn : Blue Gray (n = Gray level)
Input Signal : 0 = Low level voltage, 1 = High level voltage
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
6. Interface Timing
6.1 Timing Parameters (DE mode)
Signal Item Symbol Min. Typ. Max. Unit Note
Clock 1/TC 130 148.5 155 MHz 2Pix/clk
Hsync Frequency FH 50 67.5 75 KHz -
Vsync FV 48 60 62 Hz -
Active
Display TVD - 1080 - Lines -
Vertical Period
Display Term
Vertical
TV 1100 1125 1158 Lines -
Total
Active
Display THD - 1920 - Clocks -
Horizontal Period
Display Term
Horizontal
TH 2090 2200 2350 Clocks -
Total
Note) Vsync signal should be input to LVDS ODD channel for operation
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
6.2 Timing diagrams of interface signal (DE mode)
TV
TVD TVB
DE
TH
THD
DE
DCLK
TC
DATA
SIGNALS
TC
TCH TCL
DCLK 0.5
VCC
TDS TDH
DISPLAY
0.5
DATA
VCC
TES
DE 0.5
VCC
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
6.3 Power ON/OFF Sequence
To prevent a latch-up or DC operation of the LCD Module, the power on/off sequence should
be as the diagram below.
0.9VDD 0.9VDD
Power Supply VDD 0.1VDD 0.1VDD
0V
T1
0
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
