Image preview - the first page of the document
![Panel_SAMSUNG_LTI460AA03-001_0_[DS]](/pics/5eb01ed95e238.gif)
>> Download Panel_SAMSUNG_LTI460AA03-001_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Information
DATE : 02.Apr.2008
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL : LTI460AA03-001
MODEL : LTI460AA03-001
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Nam-Heon Kim 02.Apr.2008 Yu-Geun Lee 02.Apr.2008
Development Group 3, LCD Business
Samsung Electronics Co . , LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for I.D. (Information Display) ------------------------------------------- (6)
3. Optical Characteristics --------------------------------------------------------------------------------- (7)
4. Electrical Characteristics ----------------------------------------------------------------------------- (10)
4.1 TFT LCD Module
4.2 Back Light Unit
4.3 Inverter Input & Specification
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
5.1 LVDS Connector
5.2 Inverter Input Pin Configuration
5.3 Inverter Input Power Sequence
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (19)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (22)
8. Packing --------------------------------------------------------------------------------------------------- (24)
9. Marking & Others --------------------------------------------------------------------------------------- (25)
10. General Precaution ----------------------------------------------------------------------------------- (26)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History
Rev.
Date Page Summary
No
Dec
20, 000 all First issued
2007
5 Note(3) is added
Min : 2500 3000
Contrast Ratio
Typ : 3000 3500
Rising time Max : 13ms 18ms
Response Time
G to G Max : 10ms 16ms
Apr Luminance of White Min : 1350cd/m2 1200cd/m2
02, 001 7
2008 Rx : 0.643 0.582
Ry : 0.328 0.329
Gx : 0.271 0.295
Color Chromaticity
Gy : 0.599 0.555
Bx : 0.143 0.154
By : 0.060 0.103
Lamp Current Typ : 6.5mA 6.0mA
11
Lamp Voltage Range : 1350V ~ 1550V 1380V ~ 1440V
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
Description
LTI460AA03-001 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 46.0" is
1366 x 768 and this model can display up to 16.7 million colors with wide viewing angle of
89 or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD
TV, Display terminals for AV application products, and Digital Information Display (DID).
Features
RoHS compliance (Pb-free)
High contrast ratio, High luminance
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response
Narrow bezel, Black top chassis
Landscape / Portrait type compatible
WXGA (1366 x 768 pixels) resolution (16:9)
Low Power consumption
Direct Type 36 CCFTs(Cold Cathode Fluorescent Tube)
DE(Data Enable) mode
LVDS (Low Voltage Differential Signaling) interface (1pixel/clock)
General Information
Items Specification Unit Note
1047.4(WTYP) x 600.6(HTYP) 1.0mm
Module Size mm
63.8(DMAX)
Weight 17,000(Max) g
Pixel Pitch 0.7455(H) x 0.7455(V) mm
Active Display Area 1018.353(H) x 572.544(V) mm
Surface Treatment Haze 0% , Hard-coating (3H) HCLR
Display Colors 8 bit - 16.7M colors
Number of Pixels 1366 x 768 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 1500 (Typ.) cd/m2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 13.2 V (1)
Storage temperature TSTG -20 60 (2)
Glass surface Center TCENTER 0 50
temperature (2),(6)
(Operation) T. Uniformity T - 10
x,y - 40
Shock ( non - operating ) Snop G (4)
z - 30
Vibration ( non - operating ) Vnop - 1.5 G (5)
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b. Relative Humidity is 90% or less. (Ta > 39 C)
c. No condensation
(3) Surface temperature of bottom chassis should not exceed 50 C. (center)
Active cooling system is required for indoor application as well as outdoor application.
(4) 11ms, sine wave, one time for X, Y, Z axis
(5) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis
Fig. Temperature and Relative humidity range
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
(6) Definition of test point
5mm
5mm
1 2
5
LCD Module (Active)
3 4
T should be less than 10 ( T = |TCENTER ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
