Image preview - the first page of the document
![Panel_SAMSUNG_LTI460AP01_0_[DS]](/pics/5eb01f8a49dff.gif)
>> Download Panel_SAMSUNG_LTI460AP01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Information
DATE : 26. April.2011
SAMSUNG TFT-LCD
MODEL : LTI460AP01
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Kwang-Soo Lee 26.April.2011 Dong-Hyun Kim 26.April.2011
Application Engineering Part, LCD Division
Samsung Electronics Co . , LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for DID (Digital Information Display) ---------------------------------- (6)
3. Optical Characteristics --------------------------------------------------------------------------------- (7)
4. Electrical Characteristics ----------------------------------------------------------------------------- (10)
4.1 TFT LCD Module
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (11)
5.1 Input Signal & Power : LVDS & 12V DC
5.2 LVDS Interface
5.3 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (15)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (18)
8. Packing --------------------------------------------------------------------------------------------------- (20)
9. Marking & Others ------------------------------------------------------------------------------------- (22)
10. General Precaution ----------------------------------------------------------------------------------- (23)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History
Rev.
Date Page Summary
No
April,
26, 000 all First issued
2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
Description
LTI460AP01 is a active matrix liquid crystal display (LCD) that uses amorphous silicon
TFT(Thin Film Transistor) as switching components. This model is composed of a TFT
LCD panel, a driver circuit. The resolution of a 46.0" is 1366 x 768 and this model can
display up to 16.7M colors with wide viewing angle of 89 or higher in all directions. This
panel is intended to support applications to provide a excellent performance for Flat Panel
Display such as Transparent Display Monitor, Show window, Kiosk etc.
Features
RoHS compliance (Pb-free)
High Transmittance
PVA mode
Wide viewing angle ( 178 )
High speed response
WXGA (1366 x 768 pixels) resolution (16:9)
Low power consumption
DE(Data Enable) mode
