Image preview - the first page of the document
![Panel_SAMSUNG_LTI460HN01_2_[DS]](/pics/5eb0203a9a712.gif)
>> Download Panel_SAMSUNG_LTI460HN01_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
www.DataSheet.co.kr
Samsung Confidential
Product Information
DATE : 21, July, 2011
SAMSUNG TFT-LCD
MODEL : LTI460HN01
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Jeong-Min Heo 21, Jul,2011 Chang-Hee Hong 21,Jul,2011
Application Engineering Part, LCD Division
Samsung Electronics Co . , LTD.
Datasheet df http://www.DataSheet4U.net/
D t h t pdf - htt // D t Sh t4U t/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
www.DataSheet.co.kr
Samsung Confidential
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for DID (Digital Information Display) ---------------------------------- (7)
3. Optical Characteristics --------------------------------------------------------------------------------- (8)
4. Electrical Characteristics ----------------------------------------------------------------------------- (11)
4.1 TFT LCD Module
4.2 Back Light Unit
4.3 Inverter Input & Specification
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (14)
5.1 LVDS Connector
5.2 Inverter Input Pin Configuration
5.3 Inverter Input Power Sequence
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (19)
6.1 Timing Parameters (DE mode)
6.2 Timing Diagrams of interface Signal (DE mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (22)
8. Packing --------------------------------------------------------------------------------------------------- (24)
9. Marking & Others --------------------------------------------------------------------------------------- (26)
10. General Precaution ----------------------------------------------------------------------------------- (27)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
Datasheet df http://www.DataSheet4U.net/
D t h t pdf - htt // D t Sh t4U t/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
www.DataSheet.co.kr
Samsung Confidential
Product Information
DATE : 21, July, 2011
SAMSUNG TFT-LCD
MODEL : LTI460HN01
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Jeong-Min Heo 21, Jul,2011 Chang-Hee Hong 21,Jul,2011
Application Engineering Part, LCD Division
Samsung Electronics Co . , LTD.
Datasheet df http://www.DataSheet4U.net/
D t h t pdf - htt // D t Sh t4U t/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
www.DataSheet.co.kr
General Description Samsung Confidential
Description
LTI460HN01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 46" is
1920 x 1,080 and this model can display up to 16.7M colors with wide viewing angle of 89
or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV,
Display terminals for AV application products, and Digital Information Display (DID).
Features
RoHS compliance (Pb-free)
High contrast ratio, High luminance
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
Landscape
FHD (1920 x 1080 pixels) resolution (16:9)
Low power consumption
Direct LED Backlight (640ea)
DE(Data Enable) mode
2ch LVDS (Low Voltage Differential Signaling) interface
High Tni (85 ) Liquid crystal
Super Narrow Bezel
General Information
Items Specification Unit Note
1023.78(WTYP) x 578.37(HTYP) 1.0mm
Module Size mm
63.8(DMAX)
Weight 15,000(Max) g
Pixel Pitch 0.53025(H) x 0.53025(V) mm
Active Display Area 1018.08(H) x 572.67(V) mm
Surface Treatment Haze 44% , Anti-Glare
Display Colors 8 bit - 16.7M colors
Number of Pixels 1920 x 1,080 pixel 16 : 9
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 700 (Typ.) cd/m2
Datasheet df http://www.DataSheet4U.net/
D t h t pdf - htt // D t Sh t4U t/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
www.DataSheet.co.kr
Samsung Confidential
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
1.1 Environmental absolute Maximum Ratings
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 13.2 V (1)
Storage temperature TSTG -20 65 (2)
Glass surface Center TCENTER 0 50
temperature (2),(3)
(Operation) T. Uniformity T - 10
1.2 LED Unit absolute Maximum Ratings
Item Symbol Max. Unit Note
Operating Temperature
Top -30 ~ 85 -
Range
Storage Temperature
TSTG -40 ~ 100 -
Range
Junction Temperature Tj 125 -
If TBD mA @LED Module
Forward Current ( LEDs)
Ifp TBD mA 10% Duty
@LED Module
Forward Voltage Vf TBD V
( LEDs) 25
Thermal Resistance,
Rth,JS TBD K/W Junction to solder
Junction to PCB
Datasheet df http://www.DataSheet4U.net/
D t h t pdf - htt // D t Sh t4U t/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b. Relative Humidity is 90% or less. (Ta > 39 C)
c. No condensation
(3) Definition of test point
5mm
5mm
1 2
5
LCD Module (Active)
3 4
T should be less than 10 ( T = |TCENTER ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
