Image preview - the first page of the document
![Panel_SAMSUNG_LTI550HN01_2_[DS]](/pics/5eb05da78b8c4.gif)
>> Download Panel_SAMSUNG_LTI550HN01_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Product Information
DATE : July. 01,2011
SAMSUNG TFT-LCD
MODEL : LTI550HN01
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Jeong-Min Heo Jul.01,2011 Chang-Hee Hong Jul.01,2011
Application Engineering Part, LCD Division
Samsung Electronics Co . , LTD.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for DID (Digital Information Display) ---------------------------------- (7)
3. Optical Characteristics --------------------------------------------------------------------------------- (8)
4. Electrical Characteristics ----------------------------------------------------------------------------- (11)
4.1 TFT LCD Module
4.2 Back Light Unit
4.3 LED DC DC converter
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (14)
5.1 LVDS Connector
5.2 LED Input and Output Pin Configuration
5.3 LED drive DC-DC converter Power sequence
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (19)
6.1 Timing Parameters (DE mode)
6.2 Timing Diagrams of interface Signal (DE mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (22)
8. Packing --------------------------------------------------------------------------------------------------- (24)
9. Marking & Others --------------------------------------------------------------------------------------- (26)
10. General Precaution ----------------------------------------------------------------------------------- (27)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
* Revision History
Rev.
Date Page Summary
No
Nov
02, 000 all First issued
2010
