Image preview - the first page of the document
![Panel_SAMSUNG_LTI700HD03_0_[DS]](/pics/5eb0607da79fb.gif)
>> Download Panel_SAMSUNG_LTI700HD03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Product Information
DATE : Aug. 10, 2010
SAMSUNG TFT-LCD
TFT-
MODEL : LTI700HD03
The Information Described in this Specification is Preliminary and can be changed without
prior notice
DATE DATE
Je-Hwan Oh Aug.10,2010 Young-Do Choi Aug.10,2010
Application Engineering Part 3, LCD Division
Samsung Electronics Co . , LTD.
S El t i C LTD
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Application information for DID (Digital Information Display) ---------------------------------- (6)
3. Optical Characteristics --------------------------------------------------------------------------------- (7)
p ( )
4. Electrical Characteristics ----------------------------------------------------------------------------- (10)
4.1 TFT LCD Module
4.2 Back Light Unit
4.3 Inverter Input & Specification
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (13)
5.1 LVDS Connector
5.2 Inverter Input Pin Configuration
5.3 Inverter Input Power Sequence
5.4 LVDS Interface
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (18)
6.1 Timing Parameters (DE only mode)
6 1 Ti i P t l d )
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (21)
8. Packing --------------------------------------------------------------------------------------------------- (23)
9. Marking & Others --------------------------------------------------------------------------------------- (24)
10. General Precaution ----------------------------------------------------------------------------------- (25)
10.1 Handling
10.2 Storage
10.3 Operation
10.4
10 4 Operation Condition Guide
10.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
* Revision History
Rev.
Date Page Summary
No
Aug
10, 000 all First issued
2010
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Samsung Confidential
Description
LTI700HD03 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit The resolution of a 70 0" is
panel unit. 70.0
1920 x 1080 and this model can display up to 16.7 million colors with wide viewing angle
of 89 or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV,
Display terminals for AV application products, and Digital Information Display (DID).
Features
RoHS compliance (Pb-free)
High contrast ratio, High aperture ratio, High luminance
SPVA(Super Patterned Vertical Align) mode
Wide viewing angle ( 178 )
High speed response
Portrait / Landscape type compatible
Wide UXGA (1920 x 1080 pixels) resolution (16:9)
Low power consumption
Direct Type 64 CCFTs(Cold Cathode Fluorescent Tube)
DE(Data Enable) mode
LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
General Information
Items Specification Unit Note
1630.0(WTYP) x 952.0(HTYP) 1.0mm
Module Size mm
83.6(DMAX)
Weight TBD g Max
Pixel Pitch 0.807(H) x 0.807(V) mm
Active Display Area 1549.44(H) x 871.56(V) mm
Surface Treatment Haze 6.7%, Hard-coating (3H)
Display Colors 8 bit - 16.7M colors
Number of Pixels 1920 x 1080 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 450 (Typ.) cd/m2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung Confidential
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 13.2 V (1)
Storage temperature TSTG -20 60 (2)
Glass surface Center TCENTER 0 50
temperature (2),(3)
(Operation) T. Uniformity T - 10
Note (1) Ta= 25 2 C
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b. Relative Humidity is 90% or less. (Ta > 39 C)
c. No condensation
Fig. Temperature and Relative humidity range
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
(5) Definition of test point Samsung Confidential
T should be less than 10 ( T = |TCENTER ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
