Image preview - the first page of the document
![Panel_SAMSUNG_LTM170E8-L01_0_[DS]](/pics/5e9447f0551aa.gif)
>> Download Panel_SAMSUNG_LTM170E8-L01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Information
ISSUED DATE : 2010-04-28
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL : LTM170E8-L01
MODEL : LTM170E8-L01
Any Modification of Specification is not allowed without SEC's Permission.
Note : This is Product Information is subject to change after 3 months of issuing date.
Application Engineering Part 3, TCS Team
LCD Business, Samsung Electronics Co . , LTD.
MODEL LTM170E8-L01 Page 1/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents Product Information
General Description --------------------------------------------------------------------------------- (3)
1. Absolute Maximum Ratings ------------------------------------------------------------------- (4)
2. Optical Characteristics -------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------(11)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ----------------------------------------------------------------------------------- (16)
4.1 TFT LCD Module
4.2 Back Light Unit
5. Input Terminal Pin Assignment -------------------------------------------------------------- (17)
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Back Light Unit
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing --------------------------------------------------------------------------------- (26)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
6.4 VDD Power Dip Condition
7. Outline Dimension ------------------------------------------------------------------------------- (30)
8. General Precaution ---------------------------------------------------------------------------- (32)
10.1 Handling
10.2 Storage
10.3 Operation
10.4 Others
MODEL LTM170E8-L01 Page 2/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Product Information
Description
LTM170E8-L01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of
a TFT LCD panel, a driver circuit and a back light unit. The resolution of a19" is 1280 x
1024 and this model can display up to 16.7 millions colors.
Features
High contrast ratio, high aperture structure
PVA (Patterned Vertical Alignment) mode
Wide viewing angle
High speed response
SXGA (1280 x 1024 pixels) resolution
Low power consumption
2 dual CCFTs (Cold Cathod Fluorescent Tube)
DE (Data Enable) mode
LVDS (Low Voltage differential Signaling) interface (2pixel/clock)
RoHS compliance
Pb-free compliance
Applications
Workstation & desktop monitors
Display terminals for AV application products
Monitors for industrial machine
* If the module is used to other applications besides the above, please contact SEC
in advance.
General Information
Items Specification Unit Note
Pixel Pitch 0.264(H) x 0.264(W) mm
Active Display Area 337.92(H) x 270.336(V) mm
Surface Treatment Haze 44% , Hard-coating (3H)
Display Colors 16.7M colors
Number of Pixels 1280 x 1024 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally Black
Luminance of White 280(Typ.) cd/
MODEL LTM170E8-L01 Page 3/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Information
Mechanical Information
Item Min. Typ. Max. Unit Note
Horizontal (H) 354.4 354.9 355.4 mm
Module w/o inverter ass'y
Vertical (V) 289.8 290.3 290.8 mm
size
Depth (D) - - 13.3 mm
- - 1,700 g LCD module only
Weight
- - - g w/ Inverter assembly
