Image preview - the first page of the document
![Panel_SAMSUNG_LTM185AT05_0_[DS]](/pics/5eb063a253a3f.gif)
>> Download Panel_SAMSUNG_LTM185AT05_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Customer : General DATE : 1 / Aug / 2011
SAMSUNG TFT-LCD
TFT-
MODEL : LTM185AT05-M
LTM185AT05-
Any Modification of Specification is not allowed without SEC's Permission.
SEC s Permission
NOTE :
PREPARED BY DATE
Customer's A
C t ' Approval
l 1/Aug /'11
SIGNATURE DATE APPROVAED BY DATE
1/Aug/'11
Application Engineering Group
LCD Business, Samsung Electronics Co . , LTD.
, g
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 1/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Configuration Approval Sheet Approval Specification
Description
Items Content
Date of Approval
Customer
Product Name LTM185AT05-M
Project Name
Customer System Configuration
Items Content
System Name
Purpose
Scaler
IC
Inverter
Power
Input Interface
OS
Graphic card
p
Notice : SEC product approval spec guarantee a above customer system.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 2/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents Approval Specification
Revision History -------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings ------------------------------------------------------------------- (5)
2. Optical Characteristics -------------------------------------------------------------------------- (7)
3. Electrical Characteristics ------------------------------------------------------------------------(12)
3.1
3 1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ----------------------------------------------------------------------------------- (16)
4.1 TFT LCD Module
4.2 Back Light Unit
5.
5 Input Terminal Pin Assignment -------------------------------------------------------------- (17)
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 LVDS Interface(2)
5.4 Back light Unit
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6 Interface Timing --------------------------------------------------------------------------------- (26)
6.
6.1 Timing Parameters (DE only mode)
6.2Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
6.4 VDD Power Dip Sequence
7. Outline Dimension --------------------------------------------------------------------------------(30)
8. Reliability Test ------------------------------------------------------------------------------------ -(32)
9. Packing -------------------------------------------------------------------------------------------- (33)
9.1 CARTON
10. Marking & Others ------------------------------------------------------------------------------- (34)
11. General Precaution ----------------------------------------------------------------------------- (36)
11.1 Handling
11.2 Storage
11.3 Operation
11.4 Operation Condition Guide
11.5 Others
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 3/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History Approval Specification
Rev.
Date Page Summary
No
Aug. 1 000 All Approval specification of LTM185AT05 model was issued first.
2011
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 4/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Approval Specification
Description
LTM185AT05 product is a color active matrix liquid crystal display (LCD) that uses
amorphous silicon TFT (Thin Film Transistor) as switching components This model is
components.
composed of a TFT LCD panel, a driver circuit and a back light unit. The resolution of a
18.5" is 1366 X 768 and this model can display up to 16.7 millions colors.
Features
High contrast ratio, high aperture structure
TN (Twisted Nematic) mode
Wide Viewing Angle
HD (1366 x 768 pixels) resolution
Low power consumption
White LED Edge slim Backlight (1-side)
DE (Data Enable) only mode
LVDS (Low Voltage Differential Signaling) interface (1pixel/clock)
CCompact Si D i
t Size Design
RoHS compliance
TCO5.0 compliance
( Except for 2.2 response time; this product does not have over driving function.
It is recommended to support in system level )
Halogen Free
Applications
A li ti
Workstation & desktop monitors
Display terminals for AV application products
Monitors for industrial machine
* If the module is used to other applications besides the above, please contact SEC
in advance.
General Information
Items Specification Unit Note
Pixel Pitch 0.300(H) x 0.300(W) mm
Active Display Area 409.8(H) x 230.4V) mm
Surface Treatment Haze 25%, Hard coating (3H)
Display Colors 16.7M (Hi-FRC) colors
Number of Pixels 1,366 x 768 pixel
Pixel Arrangement RGB vertical stripe
Display Mode
Di l M d Normally Whit
N ll White
Luminance of White 250(Typ.) cd/
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 5/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Mechanical Information
Item Min.
Min T p
Typ. Max.
Ma Unit Note
Horizontal (H) 492.87 430.37 430.87 mm
Module
Vertical (V) 254.1 254.6 255.1 mm
size
Depth (D) - - 10.7 mm
Weight - - 1 00
1,500 g LCD module only
C
Note (1) Mechanical tolerance is 0.5mm unless there is a special comment.
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Item Symbol Min. Max. Unit Note
Power Supply Voltage VDD GND-0.5 6.5 V (1)
Storage temperature TSTG -25 60 (2)
Center of Glass surface temperature
TOPR 0 50 (2)
(Operation)
Shock ( non - operating ) Snop - 50 G (3), (5)
Vibration ( non - operating ) Vnop - 1.5 G (4), (5)
Note (1) Ta= 25 2 C
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 6/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta 39 C)
b.
b Maximum wet-bulb temperature at 39 C or less. (Ta 39 C)
less
c. No condensation
(3) 11ms, sine wave, one time for X, Y, Z axis
(4) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis
(5) At vibration and shock test, the fixture which holds the module to be tested has to be
hard and rigid enough so that the module would not be twisted or bent by the fixture.
(39,90)
(50,50.4)
(60,27.7)
(-25,5)
Fig. Temperature and Relative humidity range
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 7/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. Optical Characteristics Approval Specification
The optical characteristics should be measured in a dark room or equivalent.
Measuring equipment : SR 3 RD 80S (TOPCON), EZ-Contrast (Eldim)
SR-3, RD-80S (TOPCON) EZ Contrast
(Ta = 25 2 C, VDD=5V, fv= 60Hz, fDCLK=72.33MHz, IF = 120mA
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast Ratio (3)
C/R 600 1000 -
(Center of screen) SR-3
Response (5)
On/Off Tr+ Tf - 5 10 msec
Time RD-850S
Luminance of White (6)
YL 200 250 - cd/m2
(Center of screen) SR-3
Rx 0.639
Red
Ry 0.340
Gx 0.324
Green
Color Gy 0.622
Chromaticity -0.030
-0 030 +0.030
+0 030
(CIE 1931) Bx 0.155
Blue
By 0.042
Wx 0.313
White Normal
Wy 0.329
L,R=0 (7),(8)
U,D=0
0 SR-3
SR 3
Ru' 0.441
Red
Rv' Viewing 0.527
Angle
Gu' 0.132
Color Green
Chromaticity Gv' 0.570
- -
(CIE 1976) Bu' 0.194
Blue
Bv' 0.118
Wu' 0.198
White
Wv' 0.468
CGL
C.G.L White
Whi u'v''
' - - 0 02
0.02 (9)
* C.G.L : Color Grayscale Linearity (continue to the next page)
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 8/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Item Symbol Condition Min. Typ. Max. Unit Note
Color Gamut - - 72 - %
Color Temperature - - 6500 - K
L 70 85 -
Hor.
70 85 - (8)
Viewing R
CR10,(5) Degrees EZ-
Angle 70 80 -
U Contrast
Ver.
D 70 80 -
Brightness Uniformity (4)
Buni - - 25 %
(9 Points) SR-3
Note (1) Test Equipment Setup
The measurement should be executed in a stable, windless and dark room between
30min after lighting the back light at the given temperature for stabilization
of the back light. This should be measured in the center of screen.
LED current : 360mA (DC) Environment condition : Ta = 25 2 C
Photodetector
Photodetector Field
SR-3 2 Field
SR-3 : 50
RD-80S : 50
TFT - LCD Module
LCD Panel
The center of the screen
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 9/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Note (2) Definition of test point
192 960 1728
Active Area
9 8 7 108
6 5 4 540
3 2 1
972
: Test Point
Note (3) Definition of Contrast Ratio (C/R)
: Ratio of gray max (Gmax) & gray min (Gmin) at the center point of the panel
G max
CR
G min
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black
Note (4) Definition of 9 points brightness uniformity
( B max B min)
Buni 100 u
B max
Bmax : Maximum brightness with all pixels white
Bmin : Minimum brightness with all pixels white
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 10/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Note (5) Definition of Response time
a.
a On/Off response time : Sum of Tr Tf
Tr,
Display Data Black (TFT OFF) White (TFT ON) Black (TFT OFF)
TR TF
100%
90%
Optical
Response
10%
0%
Time
Note (6) Definition of Luminance of White : Luminance of white at center point
Note (7) Definition of Color Chromaticity (CIE 1931, CIE1976)
Color coordinate of Red, Green, Blue & White at center point
Note (8) Definition of Viewing Angle
: Viewing angle range ( CR 10 )
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 11/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Note (9) Color Grayscale Linearity
a. Test image : 100% full white pattern with a test pattern as below
b. Test pattern : Squares, 40mm by 40mm in size, filled with 255, 225, 195, 165, 135 and
105 grays steps should be arranged at the center of the screen.
c. Test method
-1st gray step : move a square of 255 gray level should be moved into the center of the
screen and measure luminance and u' and v' coordinates.
- Next gray step : Move a 225 gray square into the center and measure both
luminance and coordinates, too.
d. Test evaluation
'u' v' = (u' A - u' B) 2 + (v' A - v' B) 2
Where A, B : 2 gray levels found to have the largest color differences between them
i.e. get the largest u' and v' of each 6 pair of u' and v' and calculate the u'v'.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 12/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
3. Electrical Characteristics Approval Specification
3.1 TFT LCD Module
The connector for display data & timing signal should be connected.
Ta
T = 25 C
Item Symbol Min. Typ. Max. Unit Note
Voltage of Power Supply VDD 4.5 5.0 5.5 V (1)
Differential Input g
High - - +100 mV ( )
(2)
Voltage for LVDS
Receiver Threshold Low -100 - - mV
LVDS skew tSKEW -300 300 (3)
LVDS
Input Differential input
|VID| 200 600 mV (4)
Characteri voltage
stics
Input voltage range
VIN 0 2.4 V (4)
(single-ended)
Common mode 0+ 2.4-
VCM 1.2 V (4)
voltage |VID|/2 |VID|/2
(a) Black - 500 - mA
Current of
Power (b) White IDD - 500 - mA (5),(6)
Supply
(c) Dot - 700 1,000 mA
Vsync Frequency fV 47 60 59.25 Hz
Hsync Frequency fH 37.13 47.40 59.25 kHz
Main Frequency fDCLK 56.66 72.33 90.42 MHz
Rush Current IRUSH - - 3.0 A (7)
Note (1) The ripple voltage should be controlled under 10% of VDD.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 13/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
(2) Differential receiver voltage definitions and propagation delay and transition time test circuit
a. All input pulses have frequency = 10MHz, tR or tF=1ns
b. CL includes all probe and fixture capacitance
Note a.
Note b.
(3) LVDS Receiver DC parameters are measured under static and steady conditions
which may not be reflective of its performance in the end application.
T
LVDS Clk VDIFF= 0V VDIFF= 0V Differential
LVDS Data Differential
RX +/-
tSKEW
where tskew : skew between LVDS clock & LVDS data,
T : 1 period time of LVDS clock
cf) (-/+) of 300psec means LVDS data goes before or after LVDS clock.
(4) Definition of VID and VCM using single-end signals
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 14/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
(5) fV=60Hz, fDCLK = 72.33MHz, VDD = 5.0V, DC Current.
(6) Power dissipation check pattern (LCD Module only)
a) White Pattern b) Black Pattern c) Dot Pattern
(7) Measurement Condition
VDD
100%
90%
10%
GND
TRUSH=470
Rush Current IRUSH can be measured when TRUSH. is 470 .
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 15/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
3.2 Back Light Unit
3.2.1 The characteristics of LED bar
The back light unit is composed of WLED.
Ta=25 2C
Item Symbol Min. Typ. Max. Unit Note
(1)
LED Forward Current IF - 120 - mA
/ch
/ h
LED Array Voltage VP - 22.4 24.36 V -
Operating Life Time Hr 30,000 - Hour (2)
Note (1) The above specification is not for the converter output, but for the LED bar.
The LED bar consists of 21 LED packages ; 3 parallel X 7 serial
(2) Life time (Hr) is defined as the time when brightness of a LED package itself
becomes 50% or less than its original value at the condition of Ta=25 2 C
and IF =120mA
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 16/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
4. BLOCK DIAGRAM Approval Specification
4.1 TFT LCD Module
RSDS
Control signal Source Driver ICs
LVDS S1 S1366
pair #1 Control signal
RSDS(Tx)
LVDS (Rx
Column Driver Circuit
LVDS
pair #2
x)
CN1
(30pin) TFT-LCD
(1366 x RGB x 768 pixels)
Timing Controller
+5.0V
VDD Power
Circuit
4.2 Back Light Unit
g
Connector: Molex 104086-0410 or equivalent
(mating CNT : Molex 104085-0400, 104085-0410)
LED bar
LED Return
n
LED Power
r
signal
LED Power
4-pin connector
LED Return
signal
For detail connector information, please refer to page 25.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 17/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5. Input Terminal Pin Assignment
5.1. Input Signal & Power (Connector : UJU IS100-L30B-C23 or equivalent )
PIN NO SYMBOL FUNCTION
1 NC No Connection
2 CE * CE (For LCD internal use only. Do not connect)
3 CTL * CTL (For LCD internal use only. Do not connect)
4 GND Power Ground
5 RXIN0-
RXIN0 N
Negative LVDS Diff
ti Differential D t I
ti l Data Input (0)
t
6 RXIN0+ Positive LVDS Differential Data Input (0)
7 GND Power Ground
8 RXIN1- Negative LVDS Differential Data Input (1)
9 RXIN1+ Positive LVDS Differential Data Input (1)
10 GND Power Ground
11 RXIN2- Negative LVDS Differential Data Input (2)
12 RXIN2+ Positive LVDS Differential Data Input (2)
13 GND Power Ground
14 RXCLKIN- Negative LVDS Differential Clock Input (Clock)
15 RXCLKIN
RXCLKIN+ Positive LVDS Differential Clock Input (Clock)
16 GND Power Ground
17 RXIN3- Negative LVDS Differential Data Input (3)
18 RXIN3+ Positive LVDS Differential Data Input (3)
19 GND Power Ground
20 NC No Connection
21 NC No Connection
22 NC No Connection
23 GND Power Ground
24 GND Power Ground
25 GND Power Ground
26 VCC
27 VCC
28 VCC Power Supply : +5V
29 VCC
30 VCC
* If the system already uses the 2, 3pins, it should keep under GND level
The voltage applied to those pins should not exceed -200mV.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 18/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Note) Pin number starts from left side
PCB
Pin No. 1 Pin No. 30
#1 #30
#1 #30
Fig. Connector diagram
a. All GND pins should be connected together and also be connected to the
LCD's metal chassis.
b. All power input pins should be connected together.
c. All NC pins should be separated from other signal or power.
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 19/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.2 LVDS Interface
5.2.1 Odd Pixel Data (1st pixel data)
Transmitter ( DS90C383 DS90C385 ) Si
1 LVDS T
1st i DS90C383, Signal I
l Interface
f
To LTM185AT05
Device Input Pin Device Input Signal Output Interface ( CN1 )
Signal
No Symbol Symbol Function Terminal Symbol
51 TXIN0 RO0 Red Odd Pixel Data (LSB)
52 TXIN1 RO1 Red
R d Odd Pi l D
Pixel Data
TXOUT0- No. 1 RXO0-
54 TXIN2 RO2 Red Odd Pixel Data
TXOUT0+ No. 2 RXO0+
55 TXIN3 RO3 Red Odd Pixel Data
56 TXIN4 RO4 Red Odd Pixel Data
TXOUT3- No. 10 RXO3-
2 TXIN5 RO7 Red Odd Pixel Data (MSB)
TXOUT3+
TXOUT3 No.
N 11 RXO3+
RXO3
3 TXIN6 RO5 Red Odd Pixel Data TXOUT0- No. 1 RXO0-
4 TXIN7 GO0 Green Odd Pixel Data (LSB) TXOUT0+ No. 2 RXO0+
6 TXIN8 GO1 Green Odd Pixel Data TXOUT1- No. 3 RXO1-
7 TXIN9 GO2 Green Odd Pixel Data TXOUT1+ No. 4 RXO1+
8 TXIN10 GO6 Green Odd Pixel Data TXOUT3- No. 10 RXO3-
10 TXIN11 GO7 Green Odd Pixel Data (MSB) TXOUT3+ No. 11 RXO3+
11 TXIN12 GO3 Green Odd Pixel Data
12 TXIN13 GO4 Green Odd Pixel Data TXOUT1- No. 3 RXO1-
14 TXIN14 GO5 Green Odd Pixel Data TXOUT1+ No. 4 RXO1+
15 TXIN15 BO0 Blue Odd Pixel Data (LSB)
16 TXIN16 BO6 Blue Odd Pixel Data TXOUT3- No. 10 RXO3-
18 TXIN17 BO7 Blue Odd Pixel Data (MSB) TXOUT3+ No. 11 RXO3+
TXOUT1- No. 3 RXO1-
19 TXIN18 BO1 Blue Odd Pixel Data
TXOUT1+ No.
No 4 RXO1+
20 TXIN19 BO2 Blue Odd Pixel Data
22 TXIN20 BO3 Blue Odd Pixel Data TXOUT2- No. 5 RXO2-
23 TXIN21 BO4 Blue Odd Pixel Data TXOUT2+ No. 6 RXO2+
24 TXIN22 BO5 Blue Odd Pixel Data
TXOUT3- No. 10 RXO3-
50 TXIN27 RO6 Red Odd Pixel Data
TXOUT3+ No. 11 RXO3+
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 20/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.2.2 Even Pixel Data (2nd pixel data)
2nd LVDS Transmitter ( DS90C383/385, DS90C386 Pair ) Signal Interface
To
T LTM185AT05
Device Input Pin Device Input Signal Output Interface ( CN1 )
Signal
No Symbol Symbol Function Terminal Symbol
51 TXIN0 RE0 Red Even Pixel Data (LSB)
52 TXIN1 RE1 Red Even Pixel Data
TXOUT0-
TXOUT0 No.
No 12 RXE0-
RXE0
54 TXIN2 RE2 Red Even Pixel Data
TXOUT0+ No. 13 RXE0+
55 TXIN3 RE3 Red Even Pixel Data
56 TXIN4 RE4 Red Even Pixel Data
TXOUT3- No. 22 RXE3-
2 TXIN5 RE7 Red Even Pixel Data (MSB)
TXOUT3+ No. 23 RXE3+
3 TXIN6 RE5 Red Even Pixel Data TXOUT0- No. 12 RXE0-
4 TXIN7 GE0 Green Even Pixel Data (LSB) TXOUT0+ No. 13 RXE0+
6 TXIN8 GE1 Green Even Pixel Data TXOUT1- No. 15 RXE1-
7 TXIN9 GE2 Green Even Pixel Data TXOUT1+ No. 16 RXE1+
8 TXIN10 GE6 G E
Green Even Pixel Data
Pi l D t TXOUT3- No. 22 RXE3-
10 TXIN11 GE7 Green Even Pixel Data (MSB) TXOUT3+ No. 23 RXE3+
11 TXIN12 GE3 Green Even Pixel Data
12 TXIN13 GE4 Green Even Pixel Data TXOUT1- No. 15 RXE1-
14 TXIN14 GE5 Green Even Pixel Data TXOUT1+ No. 16 RXE1+
15 TXIN15 BE0 Blue Even Pixel Data (LSB)
16 TXIN16 BE6 Blue Even Pixel Data TXOUT3- No. 22 RXE3-
18 TXIN17 BE7 Blue Even Pixel Data (MSB) TXOUT3+ No. 23 RXE3+
TXOUT1- No. 15 RXE1-
19 TXIN18 BE1 Blue Even Pixel Data
TXOUT1
TXOUT1+ No. 16 RXE1
RXE1+
20 TXIN19 BE2 Blue Even Pixel Data
22 TXIN20 BE3 Blue Even Pixel Data TXOUT2- No. 18 RXE2-
23 TXIN21 BE4 Blue Even Pixel Data TXOUT2+ No. 19 RXE2+
24 TXIN22 BE5 Blue Even Pixel Data
TXOUT3- No. 22 RXE3-
50 TXIN27 RE6 Red Even Pixel Data
TXOUT3+ No. 23 RXE3+
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 21/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.3 LVDS Interface(2)
5.3.1 Odd Pixel Data (1st pixel data)
LVDS Transmitter ( DS90C383/DS90C385 ) Signal Interface
To LTM185AT05
Device Input Pin Device Input Signal Output Interface ( CN1 )
Signal
No Symbol Symbol Function Terminal Symbol
10 R10 RO0 Red Odd Pixel Data (LSB)
9 R11 RO1 Red Odd Pixel Data
A0M No. 1 RXO0-
8 R12 RO2 Red Odd Pixel Data
A0P No. 2 RXO0+
7 R13 RO3 Red Odd Pixel Data
6 R14 RO4 Red Odd Pixel Data
A3M No. 10 RXO3-
3 R17 RO7 Red Odd Pixel Data (MSB)
A3P No.
No 11 RXO3+
5 R15 RO5 Red Odd Pixel Data A0M No. 1 RXO0-
2 G10 GO0 Green Odd Pixel Data (LSB) A0P No. 2 RXO0+
1 G11 GO1 Green Odd Pixel Data A1M No. 3 RXO1-
100 G12 GO2 Green Odd Pixel Data A1P No. 4 RXO1+
94 G16 GO6 Green Odd Pixel Data A3M No. 10 RXO3-
93 G17 GO7 Green Odd Pixel Data (MSB) A3P No. 11 RXO3+
99 G13 GO3 Green Odd Pixel Data
96 G14 GO4 Green Odd Pixel Data A1M No. 3 RXO1-
95 G15 GO5 Green Odd Pixel Data A1P No. 4 RXO1+
92 B10 BO0 Blue Odd Pixel Data (LSB)
86 B16 BO6 Blue Odd Pixel Data A3M No. 10 RXO3-
85 B17 BO7 Blue Odd Pixel Data (MSB) A3P No. 11 RXO3+
A1M No. 3 RXO1-
91 B11 BO1 Blue Odd Pixel Data
A1P No. 4 RXO1+
90 B12 BO2 Blue Odd Pixel Data
89 B13 BO3 Blue Odd Pixel Data A2M No. 5 RXO2-
88 B14 BO4 Blue Odd Pixel Data A2P No. 6 RXO2+
87 B15 BO5 Blue Odd Pixel Data
A3M No.
No 10 RXO3
RXO3-
4 R16 RO6 Red Odd Pixel Data
A3P No. 11 RXO3+
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 22/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.3.2 Even Pixel Data (2nd pixel data)
LVDS Transmitter ( DS90C383/DS90C385 ) Signal Interface
S a s e S90C383/ S90C385 S g a e ace
To LTM185AT05
Device Input Pin Device Input Signal Output Interface ( CN1 )
Signal
No Symbol Symbol Function Terminal Symbol
84 R20 RE0 Red Even Pixel Data (LSB)
81 R21 RE1 Red Even Pixel Data
A4M No. 12 RXE0-
80 R22 RE2 Red Even Pixel Data
A4P No. 13 RXE0+
79 R23 RE3 Red Even Pixel Data
78 R24 RE4 Red Even Pixel Data
A7M No. 22 RXE3-
75 R27 RE7 Red Even Pixel Data (MSB)
A7P No.
No 23 RXE3+
77 R25 RE5 Red Even Pixel Data A4M No. 12 RXE0-
74 G20 GE0 Green Even Pixel Data (LSB) A4P No. 13 RXE0+
73 G21 GE1 Green Even Pixel Data A5M No. 15 RXE1-
72 G22 GE2 Green Even Pixel Data A5P No. 16 RXE1+
66 G26 GE6 Green Even Pixel Data A7M No. 22 RXE3-
65 G27 GE7 Green Even Pixel Data (MSB) A7P No. 23 RXE3+
71 G23 GE3 Green Even Pixel Data
70 G24 GE4 Green Even Pixel Data A5M No. 15 RXE1-
69 G25 GE5 Green Even Pixel Data A5P No. 16 RXE1+
64 B20 BE0 Blue Even Pixel Data (LSB)
58 B26 BE6 Blue Even Pixel Data A7M No. 22 RXE3-
57 B27 BE7 Blue Even Pixel Data (MSB) A7P No. 23 RXE3+
A5M No. 15 RXE1-
63 B21 BE1 Blue Even Pixel Data
A5P No. 16 RXE1+
62 B22 BE2 Blue Even Pixel Data
61 B23 BE3 Blue Even Pixel Data A6M No. 18 RXE2-
60 B24 BE4 Blue Even Pixel Data A6P No. 19 RXE2+
59 B25 BE5 Blue Even Pixel Data
A7M No. 22 RXE3
RXE3-
76 R26 RE6 Red Even Pi l D t
R dE Pixel Data
A7P No. 23 RXE3+
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 23/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.3.3 Timing Diagrams of LVDS For Transmitting
LVDS Receiver : Integrated T-CON
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 24/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.4 Back Light Unit
LED Bar input connector : Molex 104086-0410 or equivalent
p q
(mating CNT : Molex 104085-0400, 104085-0410)
Pin No. Pin description Function
1 Vin LED power input
2 RTN 1 Channel 1 LED return
3 RTN 2 Channel 2 LED return
4 RTN 3 Channel 3 LED return
Note ) Pin number starts from Left side
Rear view of panel
#4 #1
Connector
Fig. Connector diagram
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 25/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
DATA SIGNAL
GRAY
COLO DISPLAY RED GREEN BLUE
SCALE
R (8bit)
G G G G G LEVEL
R0 R1 R2 R3 R4 R5 R6 R7 G0 G3 G6 B0 B1 B2 B3 B4 B5 B6 B7
1 2 4 5 7
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -
BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 -
GREEN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 -
CYAN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -
BASIC
COLO RED 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -
R
MAGENT
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 -
A
YELLOW 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 -
WHITE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R0
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1
DARK 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R2
GRAY
SCALE : : : : : : : : : : : : : : : : : : R3~
OF : : : : : : : : : : : : : : : : : : R252
RED
LIGHT 1 0 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R253
0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R254
RED 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R255
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G0
0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G1
DARK 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G2
GRAY
SCALE : : : : : : : : : : : : : : : : : : G3~
OF
: : : : : : : : : : : : : : : : : : G252
GREE
N
LIGHT 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G253
0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G254
GREEN 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 G255
BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 B0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 B1
DARK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 B2
GRAY
SCALE : : : : : : : : : : : : : : : : : : B3~
OF : : : : : : : : : : : : : : : : : : B252
BLUE
LIGHT 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 B253
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 B254
BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 B255
Note (1) Definition of Gray :
Rn : Red Gray, Gn : Green Gray, Bn : Blue Gray (n = Gray level)
Input Signal : 0 = Low level voltage, 1 = High level voltage
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 26/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
6. Interface Timing
6.1 Timing Parameters ( DE only mode )
SIGNAL ITEM SYMBOL MIN. TYP. MAX. Unit NOTE
Clock 1/TC 56.66 72.33 90.42 MHz -
Hsync Frequency FH 37.13 47.4 59.25 KHz -
Vsync FV 47 60 75 Hz -
Active
Display TVD 768 768 768 Lines -
Vertical Period
Display Term
Vertical
TVB 776 790 948 lines -
Total
Active
Display THD 1366 1366 1366 Clocks -
Horizontal Period
Display Term
Horizontal
TH 1430 1526 1830 Clocks -
Total
Note (1) This product is DE only mode. The input of Hsync & Vsync signal does
not have an effect on normal operation.
(2) Test Point : TTL control signal and CLK at LVDS Tx input terminal in system
(3) Internal Vcc = 5.0V
(4) Best operation clock frequency is 72.33MHz(60Hz)
(5) Clock frequency = Frame frequency x TV(Typ) x TH(Typ)
(6) Max, Min variation range is at main clock Typ value (72.33MHz).
MODEL LTM185AT05 Doc. No 05-000-G-110801 Page 27/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
6.2 Timing diagrams of interface signal ( DE only mode )
TV
TVD TVB
DE
TH
THD
DE
DCLK
TC
DATA
SIGNALS
TC
TCH TCL
DCLK 0.5
VCC
TDS TDH
DISPLAY 0.5
05
DATA
VCC
TES
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
