Image preview - the first page of the document
![Panel_SAMSUNG_LTM215HT03_0_[DS]](/pics/5eb066658e7a0.gif)
>> Download Panel_SAMSUNG_LTM215HT03_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Customer : Dell / Qisda DATE : 15 / July / 2010
SAMSUNG TFT-LCD PRODUCT INFORMATION
SAMSUNG TFT-LCD PRODUCT INFORMATION
MODEL : LTM215HT03
MODEL : LTM215HT03
Any Modification of Specification is not allowed without SEC's Permission.
NOTE : Spec for E2211H
PREPARED BY DATE
Customer's Approval 15/July/'10
SIGNATURE DATE APPROVAED BY DATE
15/July/'10
Application Engineering Part 3, TCS team
LCD Division, Samsung Electronics Co. , LTD.
MODEL LTM215HT03 Doc. No 05-000-S-100715 Page 1/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Approval Specification
Product Configuration Approval Sheet ---------------------------------------------------------- (3)
Revision History --------------------------------------------------------------------------------------- (4)
General Description -------------------------------------------------------------------------------- (5)
1. Absolute Maximum Ratings ------------------------------------------------------------------- (6)
2. Optical Characteristics -------------------------------------------------------------------------- (8)
3. Electrical Characteristics ------------------------------------------------------------------------(13)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ----------------------------------------------------------------------------------- (17)
4.1 TFT LCD Module
4.2 Back Light Unit
5. Input Terminal Pin Assignment -------------------------------------------------------------- (18)
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Back Light Unit
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing --------------------------------------------------------------------------------- (27)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
6.4 VDD Power Dip Condition
7. Outline Dimension ------------------------------------------------------------------------------- (31)
8. Reliability Test ------------------------------------------------------------------------------------ (33)
9. Packing -------------------------------------------------------------------------------------------- (34)
10. Marking & Others -------------------------------------------------------------------------------(35)
11. General Precaution ---------------------------------------------------------------------------- (37)
11.1 Handling
11.2 Storage
11.3 Operation
11.4 Operation Condition Guide
11.5 Others
MODEL LTM215HT03 Doc. No 05-000-S-100715 Page 2/39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Configuration Approval Sheet Approval Specification
Description
Items Content
Date of Approval
Customer Dell / Qisda
Product Name LTM215HT03
Project Name E2211H
Customer System Configuration
Items Content
System Name E2211H
Purpose Standard MNT
Scaler TSUMU58NHJ ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
