Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTM215HT04_1_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center              www.panelook.com




                                                                        PRODUCT INFORMATION




               ISSUED DATE : 2011-3-1

                 SAMSUNG TFT-LCD PRODUCT INFORMATION
                         TFT-

                 MODEL : LTM215HT04




               Note : This is Product Information is subject to change after 3 months of issuing date.




                                Application Engineering Group
                LCD Business, Samsung Electronics Co . , LTD.


       MODEL                                 LTM215HT04                                     Page         1/33




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                   www.panelook.com




                                                                               PRODUCT INFORMATION
          Contents

         General Description --------------------------------------------------------------------------------- (3)

         1. Absolute Maximum Ratings ------------------------------------------------------------------- (4)

         2. Optical Characteristics -------------------------------------------------------------------------- (6)

         3. Electrical Characteristics ------------------------------------------------------------------------(11)
            3.1 TFT LCD Module
            3.2
            3 2 Back Light Unit

         4. Block Diagram ----------------------------------------------------------------------------------- (15)
            4.1 TFT LCD Module
            4.2 Back Light Unit

         5. Input Terminal Pin Assignment -------------------------------------------------------------- (16)
            5.1
            5 1 Input Signal & Power
            5.2 LVDS Interface
            5.3 Back Light Unit
            5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color

         6. Interface Timing --------------------------------------------------------------------------------- (25)
            6.1 Timing Parameters (DE only mode)
            6.2 Timing Diagrams of interface Signal (
                      g    g                         g     (DE only mode)
                                                                     y         )
            6.3 Power ON/OFF Sequence
            6.4 VDD Power Dip Condition

         7. Outline Dimension ------------------------------------------------------------------------------- (29)

         8. General Precaution ------------------------------------------------------------------------------ (31)
            8.1 Handling
            8.2 Storage
            8.3 Operation
            8.4 Operation Condition Guide
            8.5 Others




       MODEL                                      LTM215HT04                                          Page            2/33




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center              www.panelook.com




      General Description                                                PRODUCT INFORMATION

        Description
           LTM215HT04 is a color active matrix liquid crystal display (LCD) that uses amorphous
          silicon TFT (Thin Film Transistor) as switching components. This model is composed of
                                                          components
          a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 21.5" is 1920
          x 1080 and this model can display up to 16.7 millions colors.

        Features
            High contrast ratio, high aperture structure
            High speed response
            FHD (1920 x 1080 pixels) resolution
                                  i l )     l ti
            Low power consumption
            LVDS interface (2pixel/clock), DE(Data Enable) Mode
            White LED Edge slim Backlight (1-side bar)
            RoHS compliance
            TCO5.0 compliance
               ( Except for 2.2 response time; this product does not have over driving function.
                 It is recommended to support in system level )

         Applications
            Workstation & desktop monitors
            Display terminals for AV application products
           Monitor for HDTV
            * If the module is used to other applications besides the above, please contact SEC
               in advance.
                  advance

      General Information
                      Items                              Specification                   Unit      Note
                    Pixel Pitch                    248.25(H) x 248.25(W)                  um
               Active Display Area                  476.64(H) 268.11(V)
                                                    476 64(H) x 268 11(V)                 mm
                Surface Treatment               Haze 25%, Hard
