Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTM215HT04_2_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center           www.panelook.com



                                                                    PRODUCT INFORMATION




           ISSUED DATE : 2011-3-4

             SAMSUNG TFT-LCD PRODUCT INFORMATION

             MODEL : LTM215HT04




           Note : This is Product Information is subject to change after 3 months of issuing date.




                            Application Engineering Group
            LCD Business, Samsung Electronics Co . , LTD.


  MODEL                                   LTM215HT04                                    Page          1/33


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center               www.panelook.com



                                                                          PRODUCT INFORMATION
     Contents

    General Description --------------------------------------------------------------------------------- (3)

    1. Absolute Maximum Ratings ------------------------------------------------------------------- (4)

    2. Optical Characteristics -------------------------------------------------------------------------- (6)

    3. Electrical Characteristics ------------------------------------------------------------------------(11)
       3.1 TFT LCD Module
       3.2 Back Light Unit

    4. Block Diagram ----------------------------------------------------------------------------------- (15)
       4.1 TFT LCD Module
       4.2 Back Light Unit

    5. Input Terminal Pin Assignment -------------------------------------------------------------- (16)
       5.1 Input Signal & Power
       5.2 LVDS Interface
       5.3 Back Light Unit
       5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color

    6. Interface Timing --------------------------------------------------------------------------------- (25)
       6.1 Timing Parameters (DE only mode)
       6.2 Timing Diagrams of interface Signal (DE only mode)
       6.3 Power ON/OFF Sequence
       6.4 VDD Power Dip Condition

    7. Outline Dimension ------------------------------------------------------------------------------- (29)

    8. General Precaution ------------------------------------------------------------------------------ (31)
       8.1 Handling
       8.2 Storage
       8.3 Operation
       8.4 Operation Condition Guide
       8.5 Others




  MODEL                                      LTM215HT04                                          Page            2/33


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




 General Description                                                 PRODUCT INFORMATION

    Description
       LTM215HT04 is a color active matrix liquid crystal display (LCD) that uses amorphous
      silicon TFT (Thin Film Transistor) as switching components. This model is composed of
      a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 21.5" is 1920
      x 1080 and this model can display up to 16.7 millions colors.

   Features
        High contrast ratio, high aperture structure
        High speed response
        FHD (1920 x 1080 pixels) resolution
        Low power consumption
        LVDS interface (2pixel/clock), DE(Data Enable) Mode
        White LED Edge slim Backlight (1-side bar)
        RoHS compliance
        TCO5.0 compliance
           ( Except for 2.2 response time; this product does not have over driving function.
             It is recommended to support in system level )

    Applications
       Workstation & desktop monitors
       Display terminals for AV application products
      Monitor for HDTV
       * If the module is used to other applications besides the above, please contact SEC
          in advance.

 General Information
                  Items                              Specification                    Unit      Note
                Pixel Pitch                     248.25(H) x 248.25(W)                  um
           Active Display Area                  476.64(H) x 268.11(V)                 mm
            Surface Treatment               Haze 25%, Hard
