Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTM213U3-L07_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center           www.panelook.com




            Product Information

             SAMSUNG TFT-LCD
              SAMSUNG TFT-LCD
             MODEL NO. :: LTM213U3-L07
             MODEL NO. LTM213U3-L07




                        SAMSUNG ELECTRONICS CO. LTD.


          Doc.No.                            PI003                           Page           1   /8




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




      GENERAL DESCRIPTION



      DESCRIPTION
        LTM213U3-L07 is a color active matrix TFT (Thin Film Transistor) liquid
        crystal display (LCD) that uses amorphous silicon TFT as a switching devices.
        This model is composed of a TFT LCD panel, a driver circuit and a back-light
        system. The resolution of a 21.3" contains 1600 x 1200 pixels and can
        display up to 16.7 million colors with wide viewing angle of 80 degrees or
        higher in all directions. 6 O'clock direction is the Optimum viewing angle.



      FEATURES


◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
