Image preview - the first page of the document
![Panel_SAMSUNG_LTM220M1-L01_0_[DS]](/pics/5eb066ef43c57.gif)
>> Download Panel_SAMSUNG_LTM220M1-L01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval Specification
Customer : GreatWall DATE : 18/Oct/2006
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL : LTM220M1-L01
MODEL : LTM220M1-L01
Any Modification of Specification is not allowed without SEC's Permission.
NOTE :
PREPARED BY DATE
Customer's Approval 18/Oct/'06
SIGNATURE DATE APPROVAED BY DATE
18/Oct/'06
Product Planning Group 2, LCD Business
Samsung Electronics Co . , LTD.
MODEL LTM220M1-L01 Doc. No 06-000-G-061018 Page 1/40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents Approval Specification
Revision History -------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings ------------------------------------------------------------------- (5)
2. Optical Characteristics -------------------------------------------------------------------------- (7)
3. Electrical Characteristics ------------------------------------------------------------------------(12)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ----------------------------------------------------------------------------------- (17)
4.1 TFT LCD Module
4.2 Back Light Unit
5. Input Terminal Pin Assignment -------------------------------------------------------------- (18)
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing --------------------------------------------------------------------------------- (26)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
6.4 VDD Power Dip Condition
7. Outline Dimension ------------------------------------------------------------------------------- (31)
8. Reliability Test ------------------------------------------------------------------------------------ (34)
9. Packing -------------------------------------------------------------------------------------------- (35)
10. Marking & Others ------------------------------------------------------------------------------- (36)
11. General Precaution ---------------------------------------------------------------------------- (38)
11.1 Handling
11.2 Storage
11.3 Operation
11.4 Others
MODEL LTM220M1-L01 Doc. No 06-000-G-061018 Page 2/40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
* Revision History Approval Specification
Rev.
Date Page Summary
No
Oct. 18, 000 all Approval specification of LTM220M1-L01 model was issued first.
2006
MODEL LTM220M1-L01 Doc. No 06-000-G-061018 Page 3/40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description Approval Specification
Description
LTM220M1-L01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of
a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 22" is 1680 x
1050 and this model can display up to 16.7 millions colors.
Features
High contrast ratio, high aperture structure
TN (Twisted Nematic) mode
Wide Viewing Angle
High speed response
WSXGA+ (1680 x 1050 pixels) resolution
Low power consumption
DE (Data Enable) only mode
LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
Compact Size Design
RoHS, TCO 03' compliance
Applications
Workstation & desktop monitors
Display terminals for AV application products
Monitors for industrial machine
* If the module is used to other applications besides the above, please contact SEC
in advance.
General Information
Items Specification Unit Note
Pixel Pitch 0.282(H) x 0.282(W) mm
Active Display Area 473.76(H) x 296.1(V) mm
Surface Treatment Haze 25% Hard coating (3H)
Display Colors 16.7M (Hi-FRC) colors
Number of Pixels 1,680 x 1,050 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally White
Power Consumption 28.3 Watt (Typ)
Luminance of White 300(Typ.) cd/◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
