Image preview - the first page of the document
![Panel_SAMSUNG_LTM230HU02_0_[DS]](/pics/5eb06854be15a.gif)
>> Download Panel_SAMSUNG_LTM230HU02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PRODUCT INFORMATION
ISSUED DATE : 2009-11-30
SAMSUNG TFT-LCD PRODUCT INFORMATION
SAMSUNG TFT-
TFT-LCD PRODUCT INFORMATION
MODEL : LTM230HU02
MODEL : LTM230HU02
Note : This is Product Information is subject to change after 3 months of issuing date.
Application Engineering Part 1, TCS team
LCD Division, Samsung Electronics Co . , LTD.
MODEL LTM230HU02 Page 1/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents PRODUCT INFORMATION
General Description --------------------------------------------------------------------------------- (3)
1. Absolute Maximum Ratings ------------------------------------------------------------------- (4)
2. Optical Characteristics --------------------------------------------------------------------------- (6)
3. Electrical Characteristics ---------------------------------------------------------------------- (11)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ----------------------------------------------------------------------------------- (16)
4.1 TFT LCD Module
4.2 Back Light Unit
5. Input Terminal Pin Assignment -------------------------------------------------------------- (17)
5.1 Input Signal & Power
5.2 LVDS Interface Front
5.3 LVDS Interface Back
5.4 Back Light Unit
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing --------------------------------------------------------------------------------- (28)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
6.4 VDD Power Dip Condition
7. Outline Dimension ------------------------------------------------------------------------------- (32)
8. General Precaution ------------------------------------------------------------------------------ (34)
8.1 Handling
8.2 Storage
8.3 Operation
8.4 Operation Condition Guide
8.5 Others
MODEL LTM230HU02 Page 2/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description PRODUCT INFORMATION
Description
LTM230HU01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT (Thin Film Transistor) as switching components. This model is composed of
a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 23" is 1920 x
1080 and this model can display up to 16.7 millions colors.
Features
High contrast ratio, high aperture structure
TN (Twisted Nematic) mode
Wide Viewing Angle
High speed response
FHD (1920 x 1080 pixels) resolution
Low power consumption
DE (Data Enable) only mode
LVDS (Low Voltage Differential Signaling) interface (4pixel/clock)
RoHS compliance
Applications
Workstation & desktop monitors
Display terminals for AV application products
Monitors for Entertainment
Monitors for industrial machine
* If the module is used to other applications besides the above, please contact SEC
in advance.
General Information
Items Specification Unit Note
Pixel Pitch 0.2655(H) x 0.2655(W) mm
Active Display Area 509.76(H) x 286.74(V) mm
Surface Treatment Reflection Ratio 4%, Glare
Display Colors 16.7M (Hi-FRC) colors
Number of Pixels 1,920 x 1,080 pixel
Pixel Arrangement RGB vertical stripe
Display Mode Normally White
Luminance of White 300(Typ.) cd/
MODEL LTM230HU02 Page 3/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT INFORMATION
Mechanical Information
Item Min. Typ. Max. Unit Note
Horizontal (H) 533.5 534.0 534.5 mm
Module
Vertical (V) 311.2 311.7 312.2 mm w/o inverter ass'y
size
Depth (D) - - 19.5 mm
Weight - - 3,000 g LCD module only
