Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTM240CL01_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center           www.panelook.com



                                                                    PRODUCT INFORMATION




           ISSUED DATE : 2011-2-21

             SAMSUNG TFT-LCD PRODUCT INFORMATION

             MODEL : LTM240CL01




           Note : This is Product Information is subject to change after 3 months of issuing date.




  Application Engineering Group, LCD Sales & Marketing Team

            LCD Business, Samsung Electronics Co . , LTD.


  MODEL                                   LTM240CL01                                    Page         1/31


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center               www.panelook.com



                                                                          PRODUCT INFORMATION
     Contents

    General Description --------------------------------------------------------------------------------- (3)

    1. Absolute Maximum Ratings -------------------------------------------------------------------- (4)

    2. Optical Characteristics --------------------------------------------------------------------------- (6)

    3. Electrical Characteristics ----------------------------------------------------------------------- (11)
       3.1 TFT LCD Module
       3.2 Back Light Unit

    4. Block Diagram ------------------------------------------------------------------------------------ (14)
       4.1 TFT LCD Module
       4.2 Back Light Unit

    5. Input Terminal Pin Assignment ---------------------------------------------------------------- (15)

       5.1 Input Signal & Power
       5.2 Input Power
       5.3 Back Light Unit
       5.4 LVDS Interface
       5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color

    6. Interface Timing ----------------------------------------------------------------------------------- (23)
       6.1 Timing Parameters (DE only mode)
       6.2 Timing Diagrams of interface Signal (DE only mode)
       6.3 Power ON/OFF Sequence
       6.4 VDD Power Dip Condition

    7. Outline Dimension -------------------------------------------------------------------------------- (27)

    8. General Precaution ------------------------------------------------------------------------------- (29)
       8.1 Handling
       8.2 Storage
       8.3 Operation
       8.4 Operation Condition Guide
       8.5 Others



  MODEL                                      LTM240CL01                                          Page        2/31


One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




 General Description                                                 PRODUCT INFORMATION

    Description
       LTM240CL01 is a color active matrix liquid crystal display (LCD) that uses amorphous
      silicon TFT (Thin Film Transistor) as switching components. This model is composed of
      a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 24.0" is 1920
      x 1200 and this model can display up to 16.7 millions colors.
   Features
      High Color Saturation, high aperture structure
      PLS mode
      Wide Viewing Angle
      WUXGA (1920 x 1200 pixels) resolution
      DE (Data Enable) only mode
     White LED Edge Backlight (1-side)
      RoHS, Halogen Free compliance
      TCO 5.0 compliances
           ( Except for 2.2 response time; this product does not have over driving function.
             It is recommended to support in system level )
    Applications
      Workstation & desktop monitors
      MFM & Graphic application
      Display terminals for AV application products
      Financial market
      Monitors for industrial machine
      Monitors for HDTV
      Monitors for Professional Medical machine
      * If the module is used to other applications besides the above, please contact SEC
         in advance.
 General Information
                  Items                              Specification                    Unit      Note
                Pixel Pitch                      0.270(H) x 0.270(W)                  mm
           Active Display Area                    518.4(H) x 324.0(V)                 mm
            Surface Treatment               (Haze 47%), Hard
