Image preview - the first page of the document
![Panel_SAMSUNG_LTN121AP02-001_0_[DS]](/pics/5eb069eb5fd8a.gif)
>> Download Panel_SAMSUNG_LTN121AP02-001_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
TO : Lenovo / Wistron
DATE : July 9. 2008
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO.:LTN121AP02-001
MODEL NO.:LTN121AP02-001
127( Green product (Complied with RoHS requirement)
PVA mode (Normally Black)
Surface type [Anti-Glare]
Any Modification of Spec is not allowed without SEC' permission
APPROVED BY :
PREPARED BY : Mobile LCD, Application Engineering Part
SAMSUNG ELECTRONICS CO., LTD.
6DPVXQJ 6HFUHW
Doc.No. LTN121AP02-001 Rev.No 04-A00-S-080709 Page 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 2 )
General Description -------------------( 3 )
1. Absolute Maximum Ratings -------------------( 4 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------(6)
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13)
4.1 TFT LCD Module
4.2 Backlight Unit
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Backlight Unit
5.4 Timing Diagrams of LVDS For Transmitting
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.6 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 20 )
6.1 Timing Parameters(DE Mode)
6.2 Timing Diagrams of interface Signal (DE Mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -- - - - - - - - - - - - - - - - - - -( 22 )
8. Packing -- - - - - - - - - - - - - - - - - -- ( 24)
9. Product Marking & Others -- - - - - - - - - - - - - - - - - -- ( 26 )
10.General Precautions -- - - - - - - - - - - - - - - - - -- ( 27 )
11. EDID -- - - - - - - - - - - - - - - - - -- ( 29 )
6DPVXQJ 6HFUHW
Doc.No. LTN121AP02-001 Rev.No 04-A00-S-080709 Page 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Revision No. Page Summary
Mar 3, 2008 P00 All LTN121AP02-001 Model spec was issued first.
P28- EDID was revised.
