Image preview - the first page of the document



>> Download Panel_SAMSUNG_LTN121X1-L01_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center           www.panelook.com




            Product Information

            SAMSUNG TFT-LCD
             SAMSUNG TFT-LCD
            MODEL NO. :: LTN121X1-L01
            MODEL NO. LTN121X1-L01




                        SAMSUNG ELECTRONICS CO. LTD.


     Doc.No.        LTN121X1-L01         Rev.No           04-003-G-001208              Page     1   /6




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




      GENERAL DESCRIPTION



      DESCRIPTION
      LTN121X1-L01 is a color active matrix TFT (Thin Film Transistor) liquid crystal
      display (LCD) that uses amorphous silicon TFT as a switching devices. This
      model is composed of a TFT LCD panel, a driver circuit and a backlight
      system. The resolution of a 12.1" contains 1,024 x 768 pixels and can display
      up to 262,144 colors. 6 O'clock direction is the Optimum viewing angle.




      FEATURES
