Image preview - the first page of the document
![Panel_SAMSUNG_LTN133AT08-001_0_[DS]](/pics/5eb06a87ef669.gif)
>> Download Panel_SAMSUNG_LTN133AT08-001_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
TO : Lenovo / Quanta
DATE : Mar. 14th , 2007.
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO. :: LTN133AT08-001
MODEL NO. LTN133AT08-001
NOTE : - Surface type [ Glare ]
Green product (Complied with RoHS requirement)
Any Modification of Spec is not allowed without SEC' permission
APPROVED BY :
W. B . Youn
PREPARED BY : LCD Development Team3
SAMSUNG ELECTRONICS CO., LTD.
Samsung Secret
Doc.No. LTN133AT08-001 Rev.No 04-A00-G-070314 Page 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 Inverter
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
4.2 Backlight Unit
4.3 Inverter Unit
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Backlight Unit
5.4 Timing Diagrams of LVDS For Transmitting
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.6 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 20 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 21 )
8. Packing -- - - - - - - - - - - - - - - - - - ( 23 )
9. Markings & Others -- - - - - - - - - - - - - - - - - - ( 24 )
10. General Precaution -- - - - - - - - - - - - - - - - - - ( 26 )
11. EDID -- - - - - - - - - - - - - - - - - - ( 28 )
Samsung Secret
Doc.No. LTN133AT08-001 Rev.No 04-A00-G-070314 Page 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Revision No. Page Summary
Mar.14th. 2007 A00 All LTN133AT08-001 Model spec was issue first.
Samsung Secret
Doc.No. LTN133AT08-001 Rev.No 04-A00-G-070314 Page 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN133AT08-001 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as a switching devices. This model is composed of
a TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 13.3" contains
1,280 x 800 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
