Image preview - the first page of the document
![Panel_SAMSUNG_LTN133AT21-C01_0_[DS]](/pics/5eaf8abfa3b75.gif)
>> Download Panel_SAMSUNG_LTN133AT21-C01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
DATE : Feb, 22, 2011
SAMSUNG TFT-LCD
MODEL NO. : LTN133AT21-C01
NOTE : Extension code [ -C01 ]
LTN133AT21-C01
Surface type [ Glare ]
Any modification of Spec is not allowed without SEC's permission
Application engineering part, Mobile Division
Samsung Electronics Co., Ltd.
Samsung Secret
Doc.No. LTN133AT21-C01 Rev.No 04-A01-G-110222 Page 1 / 33
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
4.2 LED Placement Structure
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 21 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 24 )
8. Packing - - - - - - - - - - - - - - - - - - - ( 26 )
9. Markings & Others - - - - - - - - - - - - - - - - - - - ( 27 )
10. General Precautions -- - - - - - - - - - - - - - - - - - ( 29 )
11. EDID -- - - - - - - - - - - - - - - - - - ( 31 )
Samsung Secret
Doc.No. LTN133AT21-C01 Rev.No 04-A01-G-110222 Page 2 / 33
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY Approval
Revision
Date Page Summary
No.
July.19 P00 All The preliminary specification of LTN133AT21-C01 was issued first.
Aug.30 A00 All The Approval specification of LTN133AT21-C01 was issued first.
Feb. 18. 2011 A01 P31~33 The approval spec was updated by the change of EDID.
Samsung Secret
Doc.No. LTN133AT21-C01 Rev.No 04-A01-G-110222 Page 3 / 33
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN133AT21 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 13.3" contains
1366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the optimum
viewing angle.
FEATURES
