Image preview - the first page of the document
![Panel_SAMSUNG_LTN140AT07-B01_0_[DS]](/pics/5eb06b4ecac7a.gif)
>> Download Panel_SAMSUNG_LTN140AT07-B01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
DATE : Mar. 24, 2010
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO. :: LTN140AT07-B/W01
MODEL NO. LTN140AT07-B/W01
NOTE : Extension code [ -B/W ]
LTN140AT07
Surface type [ Glare ]
Any Modification of Spec is not allowed without SEC' permission.
APPROVED BY :
PREPARED BY : Thomas Oh
Technical Customer Support Team, LCD Division
Samsung Electronics Co., Ltd.
6DPVXQJ 6HFUHW
Doc.No. LTN140AT07-B/W01 Rev.No 04-A00-G-100324 Page 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
Approval
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
5.6 LED Driver Connector & Pin Assignment
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 19 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 21 )
8. Packing -- - - - - - - - - - - - - - - - - - ( 23 )
9. Markings & Others -- - - - - - - - - - - - - - - - - - ( 24 )
10. General Precautions - - - - - - - - - - - - - - - - - - - ( 26 )
11. EDID - - - - - - - - - - - - - - - - - - - ( 28 )
6DPVXQJ 6HFUHW
Doc.No. LTN140AT07-B/W01 Rev.No 04-A00-G-100324 Page 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Revision No. Page Summary
Feb. 24, 2010 A00 All The approval specification was issued first.
6DPVXQJ 6HFUHW
Doc.No. LTN140AT07-B/W01 Rev.No 04-A00-G-100324 Page 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN140AT07 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 14.0" contains
1366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the optimum
viewing angle.
FEATURES
