Image preview - the first page of the document
![Panel_SAMSUNG_LTN141AT12-M01_0_[DS]](/pics/5eb06c8c837db.gif)
>> Download Panel_SAMSUNG_LTN141AT12-M01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
TO : LENOVO
DATE : April, 24, 2009
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO. :: LTN141AT12-M01
MODEL NO. LTN141AT12-M01
NOTE :
- Extension code [M01]
- Surface type [ Anti-Glare ]
Any Modification of Specification is not allowed without SEC's Permission.
APPROVED BY :
PREPARED BY : Mobile division, Application Engineering Part
SAMSUNG ELECTRONICS CO., LTD.
6DPVXQJ 6HFUHW
Doc.No. LTN141AT12-M01 Rev.No 04-A03-S-090424 Page 1 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS Approval
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Back-Light Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
4.2 LED connection and placement
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 19 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 21 )
8. Product Markings and Others -- - - - - - - - - - - - - - - - - - ( 23 )
9. General Precautions -- - - - - - - - - - - - - - - - - - ( 24 )
10. EDID -- - - - - - - - - - - - - - -- - - - ( 26)
6DPVXQJ 6HFUHW
Doc.No. LTN141AT12-M01 Rev.No 04-A03-S-090424 Page 2 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Rev. No. Page Summary
April. 3, 2009 A00 All - LTN141AT12-M01 approval specification was issued first.
April.15.2009 A01 - - EDID was updated.
April.18.2009 A02 P4 -With LED driver ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
