Image preview - the first page of the document
![Panel_SAMSUNG_LTN141AT15-B_0_[DS]](/pics/5eb06ca0bc9eb.gif)
>> Download Panel_SAMSUNG_LTN141AT15-B_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
DATE : Feb. 9, 2011.
SAMSUNG TFT-LCD
MODEL NO. : LTN141AT15-B
NOTE : Extension code [ -B ]
LTN141AT15-B
Surface type [ Anti- Glare ]
Any modification of Spec is not allowed without SEC's permission
Application Engineer Part,
SAMSUNG ELECTRONICS CO., LTD.
Samsung Secret
Doc.No. LTN141AT15-B Rev.No 04-A00-G-110209 Page 1 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing
6.1 Timing Parameters - - - - - - - - - - - - - - - - - - - ( 19 )
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 21 )
8. Packing - - - - - - - - - - - - - - - - - - - ( 23 )
9. Markings & Others - - - - - - - - - - - - - - - - - - - ( 24 )
10. General Precaution - - - - - - - - - - - - - - - - - - - ( 26 )
Samsung Secret
Doc.No. LTN141AT15-B Rev.No 04-A00-G-110209 Page 2 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY Approval
Revision
Date Page Summary
No.
Feb. 9. 2011 A00 All The Preliminary specification of LTN141AT15-B was issued first.
Samsung Secret
Doc.No. LTN141AT15-B Rev.No 04-A00-G-110209 Page 3 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN141AT15-B is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight system. The resolution of a 14.1" contains
1280 x 800 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
FEATURES
