Image preview - the first page of the document
![Panel_SAMSUNG_LTN141BT06-102_0_[DS]](/pics/5eb06cb533a80.gif)
>> Download Panel_SAMSUNG_LTN141BT06-102_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
To : FSC
Date : Jan, 7. 2009
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO. :: LTN141BT06
MODEL NO. LTN141BT06
NOTE : Extension code [ -102 ]
LTN141BT06-102
Surface type [ Anti-glare ]
Any Modification of Spec is not allowed without SEC' permission
APPROVED BY :
PREPARED BY : 6 < /HH
LCD Development G1. Mobile Division
Samsung Electronics Co., Ltd.
6DPVXQJ 6HFUHW
Doc.No. LTN141BT06-102 Rev.No 04-A02-AG-090107 Page 1 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
4.2 Backlight Unit
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Backlight Unit
5.4 Timing Diagrams of LVDS For Transmitting
5.5 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.6 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 20 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 22 )
8. Packing -- - - - - - - - - - - - - - - - - - ( 24 )
9. Markings & Others -- - - - - - - - - - - - - - - - - - ( 25 )
10. General Precaution -- - - - - - - - - - - - - - - - - - ( 27 )
11. EDID -- - - - - - - - - - - - - - - - - - ( 29 )
6DPVXQJ 6HFUHW
Doc.No. LTN141BT06-102 Rev.No 04-A02-AG-090107 Page 2 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Revision No. Page Summary
May.19. 20008 A00 All LTN141BT06-001 Model spec is issued first.
Jun.12. 20008 A01 All Model code has been changed to LTN141BT06-101.
Model code has been changed to LTN141BT06-102.
Jan.7. 20009 A02 All
(Module Assembly site transfer from Cheonan to SESL)
6DPVXQJ 6HFUHW
Doc.No. LTN141BT06-102 Rev.No 04-A02-AG-090107 Page 3 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN141BT06-102 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 14.1" contains
1,440 x 900 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
FEATURES
