Image preview - the first page of the document
![Panel_SAMSUNG_LTN156AT22-001_0_[DS]](/pics/5eb06fa868641.gif)
>> Download Panel_SAMSUNG_LTN156AT22-001_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
TO : NEC
DATE : Apr. 6. 2011
SAMSUNG TFT-LCD
MODEL NO : LTN156AT22-001
NOTE : Extension code [ 001 ]
LTN156AT22-001
Surface type [ Anti-Glare ]
The information described in this SPEC is approved and can not be changed without prior notice.
APPROVED BY : S. K. Lee
PREPARED BY : LCD Application Engineering, Sales & Marketing Team
SAMSUNG ELECTRONICS CO., LTD.
Samsung Secret
Doc.No. LTN156AT22-001 Rev.No 04-A03-S-110406 Page 1 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 5 )
1. Absolute Maximum Ratings -------------------( 6 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 8 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 11 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 14 )
4.1 TFT LCD Module
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 15 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 LVDS characteristics
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 21 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 23 )
8. Packing -- - - - - - - - - - - - - - - - - - ( 26 )
9. Markings & Others -- - - - - - - - - - - - - - - - - - ( 28)
10. General Precautions -- - - - - - - - - - - - - - - - - - ( 30 )
11. EDID - - - - - - - - - - - - - - - - - - - ( 32 )
Samsung Secret
Doc.No. LTN156AT22-001 Rev.No 04-A03-S-110406 Page 2 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY Approval
Revision
Date Page Summary
No.
Oct. 12. 2010 P00 All LTN156AT22-001 model spec was issued first.
p. 8 R,G,B color chromaticity was updated.
p. 9 Figure of note 4 was changed from 5points to 1point.
Oct. 29. 2010 P01 p. 11 Current of power supply was updated.
p. 13 LED driver characteristic was updated as RT8510 LED driver.
p. 15 Pin 5 (WPN) was updated with on, off levels.
Pin5 (WPN) was updated as NC.
p. 15
Nov. 12. 2010 P02 Thickness on the outline dimension was corrected from 5.65mm
p. 24
max to 5.5mm max.
p. 11, 12 Max pattern was updated as 1 dot inversion.
p. 14 No.8 LED was updated as clean.
p. 24 Bigger 8-M2 direction
Dec. 14. 2010 P03
Weight was changed from 490g max to 450g max.
p. 26 Packing was updated as paper box.
p. 27 Pallet was updated as paper box.
p. 28 To classify use, Characteristic changing on Model Label
Jan. 17. 2011 P04
(From C to D / The Mean of `D' is DID )
p. 10 LED current was changed from 26.5mA to 25.5mA.
p. 11 Note4 was updated.
p. 12 Max pattern was changed from black to 1 dot inversion .
Feb. 15. 2011 P05
p. 14 LED connection and placement was updated as 36ea LEDs.
p. 25 The name of Interface connector was updated.
p. 26 EPS was removed.
p. 8 Typ. uniformity was updated.
p. 11 Max. 450mA is fixed with the margin from the maximum current in
Mar. 24. 2011 P06
the SEC's test by even.
p. 14 The numbering of LED placement was updated.
All Approval specification of LTN156AT22-001 was issued.
Mar. 25. 2011 A00
p. 25 PCB cover was updated on the outline drawing.
p.1 The information described in this SPEC is approved and can not
be changed without prior notice.
Mar. 28. 2011 A01
p. 6 Operating temp. was updated from 0 to 40 degrees.
Altitude ( operation ) was changed from 10,000feet to 15,000feet.
Samsung Secret
Doc.No. LTN156AT22-001 Rev.No 04-A03-S-110406 Page 3 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY Approval
Revision
Date Page Summary
No.
p. 1, 4, Model name of outline dimension was updated as LTN156AT22-
Mar. 28. 2011 A01 001.
23, 24
Mar. 30. 2011 A02 ALL Revision code of Doc.No was updated as -001.
Apr. 6. 2011 A03 p. 6 Typ. of weight was changed from 430g to 405g.
Samsung Secret
Doc.No. LTN156AT22-001 Rev.No 04-A03-S-110406 Page 4 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN156AT22-001 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight system. The resolution of a 15.6" contains
1366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
FEATURES
