Image preview - the first page of the document
![Panel_SAMSUNG_LTN156AT27-H02_0_[DS]](/pics/5eb0704119c74.gif)
>> Download Panel_SAMSUNG_LTN156AT27-H02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Information
DATE : March 29, 2012.
SAMSUNG TFT-LCD
MODEL NO : LTN156AT27-H02
NOTE : Extension code [ -H02 ]
LTN156AT27-H
Surface type [ Glare ]
The information described in this SPEC can not be changed without SEC's permission.
The information described in this SPEC is preliminary and can be changed without prior notice
Application Engineer Group
pp g p
SAMSUNG ELECTRONICS CO., LTD.
Samsung Secret
Doc.No. LTN156AT27-H02 Rev.No 04-PI-G-120329 Page 1 / 24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Information
CONTENTS
General Description -------------------( 3 )
1. Absolute Maximum Ratings -------------------( 4 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2.
2 Optical Characteristics -------------------( 6 )
3. Electrical Characteristics -------------------( 9 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 12 )
4.1 TFT LCD Module
4.2 Back-Light Unit
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 13 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 18 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 20 )
8. General Precautions -- - - - - - - - - - - - - - - - - - ( 22 )
Samsung Secret
Doc.No. LTN156AT27-H02 Rev.No 04-PI-G-120329 Page 2 / 24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Information
GENERAL DESCRIPTION
DESCRIPTION
LTN156AT27 H02
LTN156AT27-H02 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight system. The resolution of a 15.6" contains
1366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
FEATURES
