Image preview - the first page of the document
![Panel_SAMSUNG_LTN160AT03-001_0_[DS]](/pics/5ea5c94144bf7.gif)
>> Download Panel_SAMSUNG_LTN160AT03-001_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Approval
TO :
DATE : Dec. 01. 2009
SAMSUNG TFT-LCD
SAMSUNG TFT-LCD
MODEL NO :: LTN160AT03-0
MODEL NO LTN160AT03-0
NOTE : Extension code [ -0 ]
LTN160AT03-0
Surface type [ Anti-Glare ]
Any modification is not allowed without SEC's permission
APPROVED BY :
PREPARED BY : Mia So
Application engineering part, DS Solution
Samsung Electronics Co., Ltd.
6DPVXQJ 6HFUHW
Doc.No. LTN160AT03-0 Rev.No 04-A00-G-091201 Page 1 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
CONTENTS
Revision History -------------------( 3 )
General Description -------------------( 4 )
1. Absolute Maximum Ratings -------------------( 5 )
1.1 Absolute Ratings of environment
1.2 Electrical Absolute Ratings
2. Optical Characteristics -------------------( 7 )
3. Electrical Characteristics - - - - - - - - - - - - - - - - - - - ( 10 )
3.1 TFT LCD Module
3.2 Backlight Unit
3.3 LED Driver
4. Block Diagram - - - - - - - - - - - - - - - - - - - ( 13 )
4.1 TFT LCD Module
5. Input Terminal Pin Assignment - - - - - - - - - - - - - - - - - - - ( 14 )
5.1 Input Signal & Power
5.2 LVDS Interface
5.3 Timing Diagrams of LVDS For Transmitting
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color.
5.5 Pixel format
6. Interface Timing - - - - - - - - - - - - - - - - - - - ( 19 )
6.1 Timing Parameters
6.2 Timing Diagrams of interface Signal
6.3 Power ON/OFF Sequence
7. Outline Dimension - - - - - - - - - - - - - - - - - - - ( 21 )
8. Packing -- - - - - - - - - - - - - - - - - - ( 22 )
9. Markings & Others -- - - - - - - - - - - - - - - - - - ( 24 )
10. General Precautions - - - - - - - - - - - - - - - - - - - ( 26 )
11. EDID - - - - - - - - - - - - - - - - - - - ( 28 )
6DPVXQJ 6HFUHW
Doc.No. LTN160AT03-0 Rev.No 04-A00-G-091201 Page 2 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
REVISION HISTORY
REVISION HISTORY Approval
Date Revision No. Page Summary
Dec. 01. 2009 A00 All The approval specification of LT160AT03-0 was issued first.
6DPVXQJ 6HFUHW
Doc.No. LTN160AT03-0 Rev.No 04-A00-G-091201 Page 3 / 31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Approval
GENERAL DESCRIPTION
DESCRIPTION
LTN160AT03-0 is a color active matrix TFT (Thin Film Transistor) liquid crystal display
(LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a
TFT LCD panel, a driver circuit and a backlight system. The resolution of a 16.0" contains
1366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum
viewing angle.
FEATURES
