Image preview - the first page of the document
![Panel_SAMSUNG_SDI_S42SD-YB03_1_[DS]](/pics/5eb073dcb7bca.gif)
>> Download Panel_SAMSUNG_SDI_S42SD-YB03_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
FOR MESSRS: DATE: .Mar 26th.2004
CUSTOMER
CUSTOMER'S SPECIFICATION
(42"SD V3.1 )
107cm (42 Inch) Wide Plasma Display Module
MODEL : S42SD-YB03
(NTSC/PAL)
* This specification will be approved by both CUSTOMER and Samsung SDI Co.,Ltd.
* Please return one of this specification with your signature for approval.
Proposed by: Approved by:
Signature Signature .
General Manager. Yeonyong Choo
Quality Innovation Team,
PDP ) Division,
Module Version : 42"SD(V3) TCP CONFIDENTIAL Spec. Rev. : Version 6
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung SDI Co. Ltd. Specification Plasma Display Module
Revision History
Revision Date Description Of Changes Approval
AUGUST. 09.
1 Newly established
2003
OCT. 16.
2 Non-supply items(38p)
2003
Nov. 12th - Display Performance(7p)
3
2003 - Gamma Chracteristic(14p)
4 Feb. 18 - Power spec Update(25-26p)
2004
5 Feb. 23 - Absolute MaximumRatings(16p)
2004
Samsung SDI Confidential -2 / 2- Spec rev.: V6, Mar/26/2004
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung SDI Co. Ltd. Specification Plasma Display Module
TABLE OF CONTENTS
1. DESCRIPTION .................................................................................... .5
2. FEATURES .........................................................................................5
3. PRODUCT NAME AND MODEL NUMBER ...............................................5
4. FUNCTION OUTLINE ............................................................................5
5. BLOCK DIAGRAM ...............................................................................6
6. DISPLAY CHARACTERISTICS ...............................................................7
6.1 Display Performance ......................................................................................................7
6.2 Display Cell Arrangement ..............................................................................................8
6.3 Brightness Measurement Condition ....................................................................................9
6.4 Contrast Measurement Condition .....................................................................................10
6.5 Display Cell Defect Specification ....................................................................................11
6.6 Brightness Variation Specification .....................................................................................12
6.7 Power Consumption...................................................................................................13
6.8 Gamma Characteristics ...................................................................................................14
7. SOUND PRESSURE LEVEL SPECIFICATION .........................................14
7.1 Measurement Condition ..............................................................................................14
7.2 Sound Pressure Level ......................................................................................................14
8. MECHANICAL CHARACTERISTICS ......................................................15
8.1 Mechanical Specification.....................................................................................................15
8.2 Mechanical Characteristics..................................................................................................15
9. ENVIRONMENTAL CONDITION ...........................................................16
9.1 Recomended Environment Condition ....................................................................................16
9.2 Absoluted Environment Condition........................................................................................16
10. INTERFACE SIGNAL SPECIFICATION .................................................17
10.1 Configuration Context .....................................................................................................17
10.2 Interface function Specifications .........................................................................................18
10.3 Input Signal Definition ...................................................................................................18
10.4 LVDS Signal Definition and Function ....................................................................................18
10.5 Video Signal Definition and Function...................................................................................19
10.6 Electrical Condition of Interface Signals ................................................................................20
10.7 Video Signal Interface Timing Conditions .......................................................................21~22
10.8 LVDS Interface Timing Conditions .....................................................................................23
10.9 LVDS Connection Specifications..........................................................................................23
10.10 Connector Specifications .................................................................................................24
Samsung SDI Confidential -3 / 3- Spec rev.: V6, Mar/26/2004
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung SDI Co. Ltd. Specification Plasma Display Module
11. SMPS SPECIFICATION .....................................................................25
11.1 Connector Location .............................................................................................................25
11.2 Detail Power Specification of SMPS ....................................................................................26
11.3 Pin Assignment of connectors for Power Supply .........................................................................26
11.4 Power Applying Sequence .................................................................................................27
12. OTHERS ........................................................................................28
12.1 Mechanical Dimensions Drawing .........................................................................................28
12.2 Label ......................................................................................................................... .29
12.3 Serial No ...................................................................................................................29
13. PACKING ...........................................................................................30
13.1 Packing Dimension and Parts List ......................................................................................30
13.2 Packing Assay drawing ................................................................................................... 30
14. RELIABILITY ..................................................................................31
14.1 MTBF ..........................................................................................................................31
14.2 Expected Service Life .....................................................................................................31
14.3 Disclaimer ................................................................................................................31
15. WARNINGS/ CAUTIONS / NOTICE.......................................................32
15.1 Warnings .................................................................................................................32 ~ 33
15.2 Cautions ........................................................................................................................34
15.3 Notice .................................................................................................................35 ~ 38
16. APPENDIX .......................................................... ..............................39
16.1 Module stand supply specification.................................................................................39
Samsung SDI Confidential -4 / 4- Spec rev.: V6, Mar/26/2004
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Samsung SDI Co. Ltd. Specification Plasma Display Module
1. DESCRIPTION
The S42SD-YB03 is a 42-inch wide full color plasma display module with a resolution
of 852(H) 480(V) pixels. The display module includes Display Panel, Panel driving
electronics, Logic controller and Power supply .
2. FEATURES
