Image preview - the first page of the document
![Panel_TOSHIBA_LTM12C263_0_[DS]](/pics/5eb086dc5902d.gif)
>> Download Panel_TOSHIBA_LTM12C263_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
31cm COLOUR TFT-LCD MODULE
(12.1 TYPE)
LIQUID CRYSTAL DISPLAY DIVISION LTM12C263
PRODUCT INFORMATION (a-Si TFT)
FEATURES
(1) 12.1 SVGA for A4 size notebook PC use
(2) High Quality and Clear 262,144-colors TENTATIVE
(3) Full compatible with LTM12C025S(XGA type)
MECHANICAL SPECIFICATIONS
Item Specifications
Dimensional Outline (typ.) 275.0 (W) x 203.0 (H) x 9.7max (D) mm
Number of Pixels 800 (W) x 600 (H) pixels
Active Area 246.0 (W) x 184.5 (H) mm
Pixel Pitch 0.3075 (W) x 0.3075 (H)
Weight (approximately) 590g
Backlight Single CCFL, Sidelight type
ABSOLUTE MAXIMUM RATINGS
Item Min. Max. Unit
Supply Voltage (VDD) -0.3 7.0 V
(VFL) 0 2.0 kV(rms)
FL Driving Frequency (fFL) 0 100 KHz
Input Signal Voltage (VIN) -0.3 VDD+0.3 V
Operating Ambient Temperature *1 0 50 qC
*2
Operating Temperature for Panel 0 60 qC
Storage Temperature -20 60 qC
Storage Humidity 10 90 %(RH)
(Max. wet bulb temperature = 39qC)
*1: Wet bulb temperature should be 39qC Max., and no condensation of water.
*2: The surface temperature caused by self heat radiation of cell itself is specified on this item.
ELECTRICAL SPECIFICATION (Ta=25qC)
Item Min. Typ. Max. Unit Remarks
Supply Voltage (VDD) 4.75 5.0 5.25 V
(VFL) - 600 - V(rms) IFL=4.0 mA(rms)
FL Start Voltage 1200 --- 1700 V(rms) Ta=0qC
High Level Input Voltage (VIH) 2.2 --- VDD
Low Level Input Voltage (VIL) 0 --- 0.8 V
Current Consumption (IDD) *1 --- 195 300 mA
(IFL) *2 - 4.0 - mA(rms)
*1 *2
Power Consumption --- 3.4 --- W IFL =4.0mA(rms)
*1: 8 color bars pattern
*2: Except the efficiency of FL inverter
OPTICAL SPECIFICATION (Ta=25qC)
Item Min. Typ. Max. Unit Remarks
Contrast Ratio (CR) 100 --- --- ---
Response Time (tON) --- --- 50 ms
(tOFF) --- --- 50 ms
Luminance (L) --- 70 --- cd/m2 IFL=4.0mA(rms)
*The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
Toshiba or other rights of the third parties which may result from its use. No license is granted by implication or otherwise under any
patent or patent rights of Toshiba or others.
*The information contained herein may be changed without prior notice. It is therefore advisable to contact Toshiba before
proceeding with the design of equipment incorporating this product.
(1/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
4GHGTGPEG .KPG:
(. %QPPGEVQT
r ,5 6 $*485
/#:
2KP 0Q
*KIJ 8QNVCIG
r
$G\GN 1RGPKPI 2KP 0Q
)0&
r r
#EVKXG #TGC %GPVGT r
DIMENSIONAL OUTLINE
,56
Global LCD Panel Exchange Center
$'<'.
4
%'..
r
r
#EVKXG #TGC
r
8KGYKPI #TGC
$G\GN 1RGPKPI
#EVKXG #TGC
r
8KGYKPI #TGC 4GHGTGPEG .KPG;
(2/9)
#EVKXG #TGC %GPVGT
www.panelook.com
r
TENTATIVE
r
Unit : mm
=016'?
6#2'
(TQPV VQ 4GCT $'<'.
6#2'
8QNWOG %QXGT
Standard tolerance : 0.5
LTM12C263
2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
r
4
5VCPFCTF 6QNGTCPEGOO
4
7PKVOO
DIMENSIONAL OUTLINE
4GCT 5KFG &GVCKNU QH C
(TQPV 5KFG
Global LCD Panel Exchange Center
4
%
+( %QPPGEVQT
4
*+415'
&(2*
2KP 0Q
r
4GCT 5KFG &GVCKNU QH D
(TQPV 5KFG
(3/9)
4 r
r
OKP
www.panelook.com
TENTATIVE
4
r
OKP
OKP
4GHGTGPEG .KPG;
r
r
(TQPV 5KFG &GVCKNU QH E
4GCT 5KFG
=016'?
6#2'
(TQPV VQ 4GCT $'<'.
6#2'
8QNWOG %QXGT 4GHGTGPEG .KPG;
4
Unit : mm
/1&7.' 6*+%-0'55 /#:
r
OKP
OKP
r
Standard tolerance : 0.5
4
(TQPV 5KFG &GVCKNU QH F
4GCT 5KFG
LTM12C263
2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM12C263
BLOCK DIAGRAM
CN2
Backlight
DC/DC
Converter
Liquid Crystal Panel
Y-driver IC
Gray scale 800 x 600 pixels
Manipulation
Voltage
Generation
CN1 Circuit
Connector
Panel X-driver IC
Controller
(4/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
(1) Vertical Timing
t1
t 2
TIMING CHART
NCLK
t 3
t 3
ENAB
Global LCD Panel Exchange Center
R5-R0
G5-G0 X,1 X,2 X,3 X,4 X,Y
B5-B0 X,598 X,599 X,600
(2) Horizontal Timing
t3
(5/9)
t4
t 5
www.panelook.com
NCLK
ENAB 797,Y 799,Y
R5-R0
G5-G0 1,Y 2,Y 3,Y 4,Y 5,Y 6,Y 7,Y X,Y
B5-B0 798,Y 800,Y
t5
t6 t7
a b
VIH =(MIN):2.2 (V)
VIL =(MAX):0.8 (V)
0.5V DD
t8 t9 Input Signal Center Level : 0.5V DD
Duty(a,b):50 + 10%
-
VIH =(MIN):2.2 (V)
VIL =(MAX):0.8 (V)
LTM12C263
2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM12C263
TIMING SPECIFICATION 1) 2) 3) 4) 5) 6) 7) 8) 9)
Item Symbol Min. Typ. Max. Unit
Frame Period t1 604 x t3 625 x t3 628 x t3 ---
- 17.78 17.86 ms
Vertical t2 600 x t3 600 x t3 600 x t3 ---
Display Term
One Line t3 844 x t5 1024 x t5 1056 x t5 ---
Scanning Time 26.4 28.44 --- Ps
Horizontal t4 800 x t5 800 x t5 800 x t5 ---
Display Term
Clock Period t5 25.0 27.78 --- ns
Clock "L" Time t6 5.0 --- --- ns
Clock "H" Time t7 8.0 --- --- ns
Set Up Time t8 3.0 --- --- ns
Hold Time t9 7.0 --- --- ns
Note 1) If ENAB is fixed to "H" level or "L" level for certain period while NCLK is supplied, the panel display black with
some flicker.
Note 2) Don't fix NCLK to "H" or "L" level while the VDD(+5V) is supplied.
If NCLK is fixed to "H" or "L" level for certain period while ENAB is supplied, the panel may be damaged.
Note 3) The following conditions should be met.
a. NCLK count of each Horizontal Scanning Time should be always the same.
b. V-Blanking perod should be "n" x "Horizontal Scanning Time". (n=integer)
c. Frame period should be always the same.
Note 4) Display area address is as follows.
800 Pixels
1,1 2,1 800,1
1,2 2,2 800,2
600 lines
1,599 2,599 800,599
1,600 2,600 800,600
Note 5) Please adjust LCD operating signal timing and FL driving frequency, to optimize the display quality.
There is a possibility that flicker is observed by the interference of LCD operating signal timing and FL driving
condition (especially driving frequency).
(6/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM12C263
CONNECTOR PIN ASSIGNMENT FOR INTERFACE
CN1 INPUT SIGNAL
Connector : DF14A-30P-1.25H / HIROSE ELECTRIC CO.,LTD
Mating Connector : DF14-30S-1.25C, Contact Pin : DF14-2628SCF, DF14-3032SCF
Terminal No. Symbol Function
1 GND
2 NCLK SAMPLING CLOCK
3 NC1)
4 NC1)
5 GND
2)
6 R0 RED DISPLAY DATA (LSB)
7 R12) RED DISPLAY DATA
8 R22) RED DISPLAY DATA
9 R32) RED DISPLAY DATA
10 R42) RED DISPLAY DATA
11 R52) RED DISPLAY DATA (MSB)
12 GND
13 G02) GREEN DISPLAY DATA (LSB)
14 G12) GREEN DISPLAY DATA
15 G22) GREEN DISPLAY DATA
16 G32) GREEN DISPLAY DATA
17 G42) GREEN DISPLAY DATA
18 G52) GREEN DISPLAY DATA (MSB)
19 GND
20 B02) BLUE DISPLAY DATA (LSB)
21 B12) BLUE DISPLAY DATA
22 B22) BLUE DISPLAY DATA
23 B32) BLUE DISPLAY DATA
24 B42) BLUE DISPLAY DATA
25 B52) BLUE DISPLAY DATA (MSB)
26 ENAB COMPOUND SYNCHRONIZATION SIGNAL
27 GND
28 VDD +5.0V POWER SUPPLY
29 VDD +5.0V POWER SUPPLY
30 GND
CN2, CN3 CCFL POWER SOURCE
Connector : BHR-03VS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Mating Connector : SM02(8.0)B-BHS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Terminal No. Symbol Function
1 VFLH CCFL Power Supply ( high voltage)
2 NC 1) Non Connection (open)
3 VFLL CCFL Power Supply (low voltage)
Note 1) NC terminal should be open.
Note 2) See next page.
(7/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM12C263
256k (k=1024) COLORS COMBINATION TABLE
Gray Scale
Display R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0 Level
Black L L L L L L L L L L L L L L L L L L -
Blue L L L L L L L L L L L L H H H H H H -
Green L L L L L L H H H H H H L L L L L L -
Basic Light Blue L L L L L L H H H H H H H H H H H H -
Color Red H H H H H H L L L L L L L L L L L L -
Purple H H H H H H L L L L L L H H H H H H -
Yellow H H H H H H H H H H H H L L L L L L -
White H H H H H H H H H H H H H H H H H H -
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L H L L L L L L L L L L L L L 1
Gray Dark L L L L H L L L L L L L L L L L L L L 2
Scale of n : : : L3}
: : : L60
Red p
Light H H H H L H L L L L L L L L L L L L L61
H H H H H L L L L L L L L L L L L L L62
Red H H H H H H L L L L L L L L L L L L Red L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L H L L L L L L L 1
Gray Dark L L L L L L L L L L H L L L L L L L L 2
Scale of n : : : L3}
: : : L60
Green p
Light L L L L L L H H H H L H L L L L L L L61
L L L L L L H H H H H L L L L L L L L62
Green L L L L L L H H H H H H L L L L L L Green L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L L L L L L L H L 1
Gray Dark L L L L L L L L L L L L L L L L H L L 2
Scale of n : : : L3}
: : : L60
Blue p
Light L L L L L L L L L L L L H H H H L H L61
L L L L L L L L L L L L H H H H H L L62
Blue L L L L L L L L L L L L H H H H H H Blue L63
Black L L L L L L L L L L L L L L L L L L L 0
Gray L L L L L H L L L L L H L L L L L H L 1
Scale of Dark L L L L H L L L L L H L L L L L H L L 2
White & n : : : L3}
: : : L60
Black p
Light H H H H L H H H H H L H H H H H L H L61
H H H H H L H H H H H L H H H H H L L62
White H H H H H H H H H H H H H H H H H H White L63
(8/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM12C263
! FOR SAFETY
LCD module is generally designed with precise parts to achieve light weighted thin mechanical dimensions.
In using our Modules, make certain that you fully understand and put into practice the warnings and safety precautions
detailed in Engineering Information No.EE-N001,"CAUTIONS AND INSTRUCTIONS FOR TOSHIBA LCD MODULES".
Refer to individual specifications and TECHNICAL DATA sheets (hereinafter called "TD") for more detailed technical
information.
1) SPECIAL PURPOSES
A) Toshiba's Standard LCD Modules have not been customized for operation in extreme environments or for use in
applications where performance failures could be life-threatening or otherwise catastrophic.
B) Since Toshiba's Standard LCD Modules have not been designed for operation in extreme environments, they must never
be used in devices that will be exposed to abnormally high levels of vibration or shock which exceed Toshiba's published
specification limits.
C) In addition, since Toshiba Standard LCD Modules have not been designed for use in applications where performance
failures could be life-threatening or catastrophic, they must never be installed in aircraft navigation control systems (such as,
but not limited to Traffic Collision Avoidance System and Air Traffic Indicator), in military defense or weapons systems, in
critical industrial process-control systems (e.g., those involved in the production of nuclear energy), or in critical medical
device or patient life-support systems.
2) DISASSEMBLING OR MODIFICATION
DO NOT DISASSEMBLE OR MODIFY the module. It may damage sensitive parts inside LCD module, and may cause
scratches or dust on the display.
Toshiba doses not warrant the module, if customer disassembled or modified it.
3) BREAKAGE OF LCD PANEL
DO NOT INGEST liquid crystal material, DO NOT INHALE this material, and DO NOT CONTACT the material with skin, if
LCD panel is broken and liquid crystal material spills out.
If liquid crystal material comes into mouth or eyes, rinse mouth or eyes out with water immediately.
If this material contact with skin or cloths, wash it off immediately with alcohol and rinse thoroughly with water.
4) GLASS OF LCD PANEL
BE CAREFUL WITH CHIPS OF GLASS that may cause injuring fingers or skin, when the glass is broken.
5) ELECTRIC SHOCK
DISCONNECT POWER SUPPLY before handling LCD module.
DO NOT TOUCH the parts inside LCD module and the fluorescent lamp's connector or cables in order to prevent electric
shock, because high voltage is supplied to these parts from the inverter unit while power supply is turned on.
6) ABSOLUTE MAXIMUM RATINGS AND POWER PROTECTION CIRCUIT
DO NOT EXCEED the absolute maximum rating values under the worst probable conditions caused by the supply voltage
variation, input voltage variation, variation in parts' constants, environmental temperature, etc., otherwise LCD module may
be damaged.
Employ protection circuit for power supply, whenever the specification or TD specifies it.
Suitable protection circuit should be applied for each system design.
7) DISPOSAL
When dispose LCD module, obey to the applicable environmental regulations.
(9/9) 2000-10-18 (Ver.4.3)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
