Image preview - the first page of the document
![Panel_Toshiba_Mobile_Display_LT121EE16000_0_[DS]](/pics/5eb08964142a0.gif)
>> Download Panel_Toshiba_Mobile_Display_LT121EE16000_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Toshiba Mobile Display Co., Ltd. 31cm COLOUR TFT-LCD MODULE
(12.1 TYPE)
PRODUCT INFORMATION LT121EE16000
(p-Si TFT)
All information is subject to change without notice. Please read bottom notes.
FEATURES
(1) 12.1"XGA-WIDE(1280x800 pixels) display size for notebook PC
(2) Light weight design TENTATIVE
(3) LVDS interface system (H-Sync, V-Sync)
(4) Wide Viewing Angle
MECHANICAL SPECIFICATIONS
Item Specifications
Dimensional Outline (typ.) 288.8(W) x 182.0 (H) x 5.9(D) mm
Number of Pixels 1280 (W) x 800(H) pixels
Active Area 261.12(W) x 163.2(H) mm
Pixel Pitch 0.204(W) x 0.204(H)
Weight (approximately) 222 g(Typ)
Backlight LED backlight, Sidelight type
ABSOLUTE MAXIMUM RATINGS
Item Min. Max. Unit
Supply Voltage (VDD) -0.3 3.0 V
LED Reverse Voltage (VRLED) - 5 V
LED Forward Current (IFLED) - 30 mA
Input Signal Voltage (VIN) -0.3 VDD+0.3 V
Operating Temperature 0 50 qC
Storage Temperature -20 60 qC
Storage Humidity 10 90 %(RH)
ELECTRICAL SPECIFICATION
Item Min. Typ. Max. Unit Remarks
Supply Voltage VDD 2.35 2.5 2.7 V
Common Mode Input Voltage VCM 0.7 1.2 1.75 V
Differential Input amplitude VID 0.1 - 0.6 V
*1 : 8 color bars pattern
*2 : Excepting the efficiency FL inverter
OPTICAL SPECIFICATION (Ta=25qC)
Item Min. Typ. Max. Unit Remarks
Contrast Ratio (CR) 550 800 --- ---
Viewing Angle(U/D/R/L) 140 160 - deg
Response Time(tON)+ (tOFF) --- 40 60 ms
2
Luminance (L) 200 280 --- cd/m ILED=18mA
*The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
Toshiba Mobile Display or other rights of the third parties which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Toshiba Mobile Display technology or others.
*The information contained herein may be changed without prior notice. It is therefore advisable to contact Toshiba Mobile
Display before proceeding with the design of equipment incorporating this product.
(1/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
Unit : mm
DIMENSIONAL OUTLINE Standard tolerance : r0.5
r
r
4
r
r r
r
r
r
r
r
'
)
'
)
r
r
r
r
,
,
#%6+8' #4'#
#%6+8' #4'#
(
$
#
(
$
r
#
r
r
r
r
:
r
r
r r
r
<
,
;
r
(2/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
Unit : mm
DIMENSIONAL OUTLINE
Standard tolerance : r0.5
;
r r
r
r
r
r
r
:
r
r
r
r
r
&
&
r
*
%
%
r
*
r
r
r
4
r r
r
(3/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
BLOCK DIAGRAM
DC / D C
co n v er t e r
Y -d r i ve r
Y -d r i ve r
Gray scale L i qu i d C r y st a l Pa n e l
Manipulation
Voltage
1 2 8 0 x 80 0 pi x e ls
Generation
Circuit
CN1
P a ne l
C o n tr o l le r
LVDS i nclude
Co n n e ct o r
X - dr i v e r
LE D LED L ED LED LED
1280 pixels
1, 1 2, 1 X2n-1, 1 X2n, 1 1280, 1
1, 2
1, Y X2n-1, Y X2n, Y
800 pixels
1, 800 1280,800
(4/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
TIMING CHART
tvp
tvspw
VSYNC
thp
HSYNC
tv p tvbp tva
DE 767 768 1 2
thp
thspw
HSYNC thbp
thfp tha
DE
1280
pixel 1 2 3 4
CLK
(5/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
TIMING SPECIFICATION 1) 2) 3) 4) 5) 6) 7)
Item Symbol min. typ. max. unit
Horizontal Scanning Term thp 1408 x tc 1440 x tc 1680 clock
H-sync Pulse Width thspw 4 x tc 32 x tc - clock
Horizontal Front Porch thfp 4 x tc 48 x tc - clock
Horizontal Back Porch thbp 4 x tc 80 x tc - clock
Horizontal Display Term tha 1280 x tc 1280 x tc 1280 x tc clock
Frame Period tv 805 x th 823 x th 831 x th line
V-sync Pulse Width tvspw 1 x th 6 x th - line
Vertical Front Porch tvfp 1 x th 3 x th - line
Vertical Back Porch tvbp 2 x th 14 x th - line
Vertical Display Term tvd 800 x th 800 x th 800 x th line
Clock Period tc 14.71 14.08 11.98 ns
Note 1) Refer to "Timing Chart" and LVDS (THC63LVDF84A-85) specifications by THine Electronics, Inc.
corporation.
Note 2) If DE is fixed to "H" or "L" level for certain period while NCLK is supplied, the panel displays black with some flicker.
Note 3) If NCLK is fixed to "H" or "L" level for certain period while DE is supplied, the panel may be damaged.
Note 4) Please adjust LCD operating signal timing and FL driving frequency, to optimize the display quality.
There is a possibility that flicker is observed by the interference of LCD operating signal timing and FL driving
condition (especially driving frequency), even if the condition satisfies above timing specifications and
recommended operating conditions shown in 3.
Note5 ) Do not make tv, tvhd and tvds fluctuate.
If tv, tvhd, and tvds are fluctuate, the panel displays black.
Note6) In case of using the long frame period, the deterioration of display quality, noise etc. may be occurred.
Note7) NCLK count of each Horizontal Scanning Time should be always the same.
V-Blanking period should be "n" X "Horizontal Scanning Time". (n: integer)
Frame period should be always the same.
Note8) thb= thw + thfp + thbp
Note9) tvb= tvw + tvfp + tvbp
(6/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
CONNECTOR PIN ASSIGNMENT FOR INTERFACE
CN1 INPUT SIGNAL
Connector : DF19KR-20P-1H / HIROSE
Mating Connector : DF19G-20S-1F (Cable), DF19G-20S-1C (FPC)
Terminal No. Symbol Function
1 VSS GND
2 VSS GND
3 VSS GND
4 VSS GND
5 VSS(or NC) GND (or Not Connection)
6 VDD Power Supply : +2.5V
7 VDD Power Supply : +2.5V
8 VDD Power Supply : +2.5V
9 VDD Power Supply : +2.5V
10 NC Do Not Connect
11 VEDID DDC 2.5V
12 CLKEDID DDC Clock
13 DATAEDID DDC Data
14 VSS GND
15 RxIN0- Negative LVDS differential data input (R0-R5,G0)
16 RxIN0+ Positive LVDS differential data input (R0-R5,G0)
17 VSS GND
18 RxIN1- Negative LVDS differential data input (G1-G5, B0-B1)
19 RxIN1+ Positive LVDS differential data input (G1-G5, B0-B1)
20 VSS GND
21 RxIN2- Negative LVDS differential data input (B2-B5, HS, VS, DE)
22 RxIN2+ Positive LVDS differential data input (B2-B5, HS, VS, DE)
23 NC Do Not Connect
24 CLK- Clock Signal(-)
25 CLK+ Clock Signal(+)
26 VSS GND
27 NC Do Not Connect
28 VCD11 LED Power Supply
29 VCD12 LED Power Supply
30 VCD21 LED Power Supply
31 VCD22 LED Power Supply
32 VCD31 LED Power Supply
33 VCD32 LED Power Supply
34 NC Do Not Connect
35 VAD11 LED Power Supply
36 VAD12 LED Power Supply
37 VAD21 LED Power Supply
38 VAD22 LED Power Supply
39 VAD31 LED Power Supply
40 VAD32 LED Power Supply
Note 1) Please connect GND pin to ground. Don't use it as no-connect nor connection with high impedance.
Note 2) Please connect NC to nothing. Don't connect it to ground nor to other signal input.
(7/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
RECOMMENDED TRANSMITTER (THC63LVDM63B) TO LT121EE16000 INTERFACE ASSIGNMENT
Case1: 6bit Transmitter
THC63LVDM63B LT121EE16000
Input Signal Output Interface
Input Terminal No. (CN1)
(Graphics controller output signal) Signal
Symbol Terminal Symbol Function Symbol Terminal Symbol
TIN0 44 R0 Red Pixels Display Data (LSB)
TIN1 45 R1 Red Pixels Display Data
TIN2 47 R2 Red Pixels Display Data
TOUT0- No.15 IN0-
TIN3 48 R3 Red Pixels Display Data TOUT0+ No.16 IN0+
TIN4 1 R4 Red Pixels Display Data
TIN5 3 R5 Red Pixels Display Data (MSB)
TIN6 4 G0 Green Pixels Display Data (LSB)
TIN7 6 G1 Green Pixels Display Data
TIN8 7 G2 Green Pixels Display Data
TIN9 9 G3 Green Pixels Display Data
TOUT1- No.18 IN1-
TIN10 10 G4 Green Pixels Display Data
TOUT1+ No.19 IN1+
TIN11 12 G5 Green Pixels Display Data (MSB)
TIN12 13 B0 Blue Pixels Display Data (LSB)
TIN13 15 B1 Blue Pixels Display Data
TIN14 16 B2 Blue Pixels Display Data
TIN15 18 B3 Blue Pixels Display Data
TIN16 19 B4 Blue Pixels Display Data
TOUT2- No.21 IN2-
TIN17 20 B5 Blue Pixels Display Data (MSB)
TOUT2+ No.22 IN2+
TIN18 22 HSYNC H-Sync
TIN19 23 VSYNC V-Sync
TIN20 25 DE Compound Synchronization Signal
TCLK OUT- No.24 CLK-
CLK IN 26 CLK Data Sampling Clock
TCLK OUT+ No.25 CLK+
Note 1) Please connect NC pin to nothing. Don't connect it to ground nor to other signal input.
IN 0 T IN6 T IN5 T IN4 T IN3 T IN2 T IN1 T IN0
G0 R5 R4 R3 R2 R1 R0
IN 1 T IN13 T IN12 T IN11 T IN10 T IN9 T IN8 T IN7
B1 B0 G5 G4 G3 G2 G1
IN 2 T IN20 T IN19 T IN18 T IN17 T IN16 T IN15 T IN14
DE VSYNC HSYNC B5 B4 B3 B2
(8/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
RECOMMENDED TRANSMITTER (THC63LVDM83R) TO LT121EE16000 INTERFACE ASSIGNMENT
Case2: 8bit Transmitter
THC63LVDM83R LT121EE16000
Input Signal Output Interface
Input Terminal No. (CN1)
(Graphics controller output signal) Signal
Symbol Terminal Symbol Function Symbol Terminal Symbol
TIN0 51 R0 Red Pixels Display Data (LSB)
TIN1 52 R1 Red Pixels Display Data
TIN2 54 R2 Red Pixels Display Data
TOUT0- No.15 IN0-
TIN3 55 R3 Red Pixels Display Data TOUT0+ No.16 IN0+
TIN4 56 R4 Red Pixels Display Data
TIN6 3 R5 Red Pixels Display Data (MSB)
TIN7 4 G0 Green Pixels Display Data(LSB)
TIN8 6 G1 Green Pixels Display Data
TIN9 7 G2 Green Pixels Display Data
TIN12 11 G3 Green Pixels Display Data
TOUT1- No.18 IN1-
TIN13 12 G4 Green Pixels Display Data
TOUT1+ No.19 IN1+
TIN14 14 G5 Green Pixels Display Data(MSB)
TIN15 15 B0 Blue Pixels Display Data (LSB)
TIN18 19 B1 Blue Pixels Display Data
TIN19 20 B2 Blue Pixels Display Data
TIN20 22 B3 Blue Pixels Display Data
TIN21 23 B4 Blue Pixels Display Data
TOUT2- No.21 IN2-
TIN22 24 B5 Blue Pixels Display Data (MSB)
TOUT2+ No.22 IN2+
TIN24 27 HSYNC H-Sync
TIN25 28 VSYNC V-Sync
TIN26 30 DE Compound Synchronization Signal
TIN27 50 NC Non Connection (open)
TIN5 2 NC Non Connection (open)
TIN10 8 NC Non Connection (open)
TOUT3-
TIN11 10 NC Non Connection (open)
TOUT3+
TIN16 16 NC Non Connection (open)
TIN17 18 NC Non Connection (open)
TIN23 25 NC Non Connection (open)
TCLK OUT- No.24 CLK-
CLK IN 31 CLK Data Sampling Clock
TCLK OUT+ No.25 CLK+
Note 1) Please connect NC pin to nothing. Don't connect it to ground nor to other signal input.
IN 0 T IN 7 T IN 6 T IN 4 T IN 3 T IN 2 T IN 1 T IN 0
G0 R5 R4 R3 R2 R1 R0
IN 1 T IN 1 8 T IN 1 5 T IN 1 4 T IN 1 3 T IN 1 2 T IN 9 T IN 8
B1 B0 G5 G4 G3 G2 G1
IN 2 T IN 2 6 T IN 2 5 T IN 2 4 T IN 2 2 T IN 2 1 T IN 2 0 T IN 1 9
DE VSYNC HSYNC B5 B4 B3 B2
IN 3 T IN 2 3 T IN 1 7 T IN 1 6 T IN 1 1 T IN 1 0 T IN 5 T IN 2 7
NC NC NC NC NC NC NC
(9/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
256k (k=1024) COLORS COMBINATION TABLE
Gray Scale
Display R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Level
Black L L L L L L L L L L L L L L L L L L -
Blue L L L L L L L L L L L L H H H H H H -
Green L L L L L L H H H H H H L L L L L L -
Basic Light Blue L L L L L L H H H H H H H H H H H H -
Color Red H H H H H H L L L L L L L L L L L L -
Purple H H H H H H L L L L L L H H H H H H -
Yellow H H H H H H H H H H H H L L L L L L -
White H H H H H H H H H H H H H H H H H H -
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L H L L L L L L L L L L L L L 1
Dark L L L L H L L L L L L L L L L L L L L 2
Gray
n : : : L3}
Scale of : : : L60
Red p
Light H H H H L H L L L L L L L L L L L L L61
H H H H H L L L L L L L L L L L L L L62
Red H H H H H H L L L L L L L L L L L L Red L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L H L L L L L L L 1
Dark L L L L L L L L L L H L L L L L L L L 2
Gray
n : : : L3}
Scale of : : : L60
Green p
Light L L L L L L H H H H L H L L L L L L L61
L L L L L L H H H H H L L L L L L L L62
Green L L L L L L H H H H H H L L L L L L Green L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L L L L L L L H L 1
Dark L L L L L L L L L L L L L L L L H L L 2
Gray
n : : : L3}
Scale of : : : L60
Blue p
Light L L L L L L L L L L L L H H H H L H L61
L L L L L L L L L L L L H H H H H L L62
Blue L L L L L L L L L L L L H H H H H H Blue L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L H L L L L L H L L L L L H L 1
Gray Dark L L L L H L L L L L H L L L L L H L L 2
Scale of n : : : L3}
White & p : : : L60
Black Light H H H H L H H H H H L H H H H H L H L61
H H H H H L H H H H H L H H H H H L L62
White H H H H H H H H H H H H H H H H H H White L63
(10/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LT121EE16000
! FOR SAFETY
LCD module is generally designed with precise parts to achieve light weighted thin mechanical dimensions.
In using our Modules, make certain that you fully understand and put into practice the warnings and safety precautions
detailed in Engineering Information No.EE-D-001A,"CAUTIONS AND INSTRUCTIONS FOR TOSHIBA MOBILE DISPLAY
CO., LTD LCD MODULES".
Refer to individual specifications and TECHNICAL DATA sheets (hereinafter called "TD") for more detailed technical
information.
1) SPECIAL PURPOSES
A) Toshiba Mobile Display's Standard LCD Modules have not been customized for operation in extreme environments or for
use in applications where performance failures could be life-threatening or otherwise catastrophic.
B) Since Toshiba Mobile Display's Standard LCD Modules have not been designed for operation in extreme environments,
they must never be used in devices that will be exposed to abnormally high levels of vibration or shock which exceed
Toshiba Mobile Display technology's published specification limits.
C) In addition, since Toshiba Mobile Display technology Standard LCD Modules have not been designed for use in
applications where performance failures could be life-threatening or catastrophic, they must never be installed in aircraft
navigation control systems (such as, but not limited to Traffic Collision Avoidance System and Air Traffic Indicator), in military
defense or weapons systems, in critical industrial process-control systems (e.g., those involved in the production of nuclear
energy), or in critical medical device or patient life-support systems.
2) DISASSEMBLING OR MODIFICATION
DO NOT DISASSEMBLE OR MODIFY the module. It may damage sensitive parts inside LCD module, and may cause
scratches or dust on the display.
Toshiba Mobile Display doses not warrant the module, if customer disassembled or modified it.
3) BREAKAGE OF LCD PANEL
DO NOT INGEST liquid crystal material, DO NOT INHALE this material, and DO NOT CONTACT the material with skin, if
LCD panel is broken and liquid crystal material spills out.
If liquid crystal material comes into mouth or eyes, rinse mouth or eyes out with water immediately.
If this material contact with skin or cloths, wash it off immediately with alcohol and rinse thoroughly with water.
4) GLASS OF LCD PANEL
BE CAREFUL WITH CHIPS OF GLASS that may cause injuring fingers or skin, when the glass is broken.
5) ELECTRIC SHOCK
DISCONNECT POWER SUPPLY before handling LCD module.
DO NOT TOUCH the parts inside LCD module and the fluorescent lamp's connector or cables in order to prevent electric
shock, because high voltage is supplied to these parts from the inverter unit while power supply is turned on.
6) ABSOLUTE MAXIMUM RATINGS AND POWER PROTECTION CIRCUIT
DO NOT EXCEED the absolute maximum rating values under the worst probable conditions caused by the supply voltage
variation, input voltage variation, variation in parts' constants, environmental temperature, etc., otherwise LCD module may
be damaged.
Employ protection circuit for power supply, whenever the specification or TD specifies it.
Suitable protection circuit should be applied for each system design.
7) DISPOSAL
When dispose LCD module, obey to the applicable environmental regulations.
(11/11) 2010-02-16 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
