Image preview - the first page of the document
Panel_Toshiba_Mobile_Display_LT133EE09500_1_[DS]


>> Download Panel_Toshiba_Mobile_Display_LT133EE09500_1_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center                           www.panelook.com



        Toshiba Mobile Display Co., Ltd.                                                     33.8cm COLOUR TFT-LCD MODULE
                                                                                                       (13.3 TYPE)
                                                                                                     LT133EE09500
                    PRODUCT INFORMATION                                                                (p-Si TFT)
            All information is subject to change without notice. Please read bottom notes.

         FEATURES
                    (1)   13.3" HD(1366x768 pixels) display size for notebook PC
                    (2)   LED Backlight (with LED Driver)                                            TENTATIVE
                    (3)   Anti-Glare
                    (4)   Bezel less structure
                    (5)   LVDS interface
                    (6)   EDID

         MECHANICAL SPECIFICATIONS
                                  Item                                                         Specifications
               Dimensional Outline (typ.)                          306.5 (W) x 177.7 (H) x 3.5(D) Max. mm (without PCB, mounting tab)
               Number of Pixels                                    1366 (W) x 768 (H) pixels
               Active Area                                         293.42 (W) x 164.97 (H) mm
               Pixel Pitch                                         0.2148 (W) x 0.2148 (H) mm
               Weight (approximately)                              180 g (Typ)
               Backlight                                           LED type, with LED Driver

         ABSOLUTE MAXIMUM RATINGS

               Item                                                            Min.         Max.      Unit      Checked Terminal
               Supply Voltage                                      VDD             -0.3     +4.0       V        VDD
