Image preview - the first page of the document
![Panel_Toshiba_Matsushita_LTD121KM2M_0_[DS]](/pics/5eb08857dcd8a.gif)
>> Download Panel_Toshiba_Matsushita_LTD121KM2M_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
TOSHIBA MATSUSHITA DISPLAY TECHNOLOGY 31cm COLOUR TFT-LCD MODULE
(12.1 TYPE)
LTD121KM2M
PRODUCT INFORMATION (p-Si TFT)
FEATURES
(1) 12.1"SXGA+(1400x1050 pixels, 145ppi) optimal resolution for Tablet PC
(2) 2ch LVDS interface system (H-Sync, V-Sync) TENTATIVE
(3) Digitizer Easy Insertion & Assembly by "Kangaroo" Solution
(4) Anti-Color Inversion with TN(ACIT) for wide viewing angle
MECHANICAL SPECIFICATIONS
Item Specifications
Dimensional Outline (typ.) 269.0(W) x 199.0 (H) x 6.8max (D) mm
Number of Pixels 1400(W) x 1050(H) pixels
Active Area 245.8(W) x 184.3(H) mm
Pixel Pitch 0.1755(W) x 0.1755(H)
Weight (approximately) 305 g
Backlight Single CCFL, Sidelight type
ABSOLUTE MAXIMUM RATINGS
Item Min. Max. Unit
Supply Voltage (VDD) -0.3 4.0 V
(VFL) - 2.0 kV(rms)
FL Driving Frequency (fFL) - 100 kHz
Input Signal Voltage (VIN) -0.3 VDD+0.3 V
Operating Temperature 0 50 qC
Storage Temperature -20 60 qC
Storage Humidity 10 90 %(RH)
ELECTRICAL SPECIFICATION
Item Min. Typ. Max. Unit Remarks
Supply Voltage (VDD) 3.0 3.3 3.6 V
(VFL) --- (620) --- V(rms) IFL=6.0 mA(rms)
FL Start Voltage (Ta=0qC) 1550 --- --- V(rms)
Differential Input Voltage (VID) *1 0.1 --- 0.6 V
Differential Input Common Voltage (RxVCM) *1 0.5 1.2 1.5 V
Differential Input Common Potential -50 --- +50 mV
Difference (Rx'VCM) *1
Current Consumption *2 (IDD) --- (360) --- mA
*3 (IFL) --- 6.0 --- mA(rms)
*2 *3 Power Consumption --- (4.8) --- W IFL=6.0 mA(rms)
*1 : Refer to THC63LVDF84A-85 Specification by THine Electronics,Inc.
*2 : 8 color bars pattern
*3 : Excepting the efficiency FL inverter
OPTICAL SPECIFICATION (Ta=25qC)
Item Min. Typ. Max. Unit Remarks
Contrast Ratio (CR) 100 250 --- ---
Viewing Angle (Upper / Lower) --- (45 / 50) --- q
(CR t 10) (Left / Right) --- (50 / 50) --- q
Response Time (tON) --- --- 50 ms
(tOFF) --- --- 50 ms
Luminance (L) --- (160) --- cd/m2 IFL=6.0mA(rms)
*The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
Toshiba Matsushita Display Technology or other rights of the third parties which may result from its use. No license is granted by
implication or otherwise under any patent or patent rights of Toshiba Matsushita Display Technology or others.
*The information contained herein may be changed without prior notice. It is therefore advisable to contact Toshiba Matsushita
Display Technology before proceeding with the design of equipment incorporating this product.
(1/10) 2004-05-26 (Ver.tbd)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
TENTATIVE Unit : mm
Standard tolerance : +/-0.5
DIMENSIONAL OUTLINE
(Front Side)
( % * 4 8
5
%%(. ECDNG NGPIVJ
. 0 $5 5 , 6
/
6CR
+ ( ( $ 4 ( #
#
+ : 5 .* ,'
G V T
##%PG
$1
# #
# % P G
# G V T
# #
$1
60#+'
$1
'668
$1
/
6CR
/
6CR
UWTHCEG4GCT UKFG
&KIKVK\GT UWTHCEG
&KIKVK\GT UWTHCEG
C
O Z
r
/QWPVKPI
Important : Recommendable mating digitizer is Wacom SU-012/021 Series.
Digitizer should be assembled by Set maker side.
Digitizer sensor board thickness should be 0.5mm/0.75mm max..
(2/10) 2004-05-26 (Ver.tbd)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
BLOCK DIAGRAM
X-driver
DC/DC
converter
Y-driver
Liquid Crystal Panel
Gray scale 1400 x 1050 pixels
Manipulation
Voltage
Generation
Circuit
CN1
Connector
Panel
CN2
Controller Backlight
LVDS
1400 pixels
1, 1 2, 1 X, 1 1400, 1
1, 2
1, Y X, Y
1050 pixels
1, 1050 1400,1050
(3/10) 2004-05-26 (Ver.tbd)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
TIMING CHART
(4/10) 2004-05-26 (Ver.tbd)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
TIMING SPECIFICATION 1) 2) 3) 4) 5) 6) 7)
Item Symbol min. typ. max. unit
Horizontal Scanning Term t4=th 836 x t7 844 x t7 850 x t7 -
H-sync Pulse Width thw 8 x t7 - - -
Horizontal Front Porch thfp 8 x t7 - - -
Horizontal Blanking Period t6 136 x t7 144 x t7 150 x t7 -
Horizontal Display Term t5 700 x t7 700 x t7 700 x t7 -
Horizontal Data Sync term thds t6 - thfp t6 - thfp t6 - thfp
Frame Period t1 1060 x t4 1066 x t4 1070 x t4
16.66 17.69 ms
V-sync Period tv 1060 x t4 1066 x t4 1070 x t4
V-sync Pulse Width tvw 2 x t4 - - -
V-sync Set Up Time (to H-sync) tvsu 8 x t7 - - -
V-sync Hold Time tvhd 8 x t7 - - -
Vertical Front Porch tvfp 0 - - -
Vertical Data Sync Term tvds 8 x t4 - - -
Vertical Display Term t2 1050 x t4 1050 x t4 1050 x t4 -
Vertical Blanking Term t3 8 x t4 16 x t4 16 x t4 -
Clock Period t7 17.544 18.519 19.597 ns
Clock Frequency 1/t7 51 54 57 MHz
DE Pulse Width tdew 700 x t7 700 x t7 700 x t7 -
Note 1) Refer to "Timing Chart" and LVDS (THC63LVDF84A-85) specifications by THine Electronics,Inc.
Note 2) If DE is fixed to "H" or "L" level for certain period while NCLK is supplied, the panel displays black with some flicker.
Note 3) If NCLK is fixed to "H" or "L" level for certain period while DE is supplied, the panel may be damaged.
Note 4) Please adjust LCD operating signal timing and FL driving frequency, to optimize the display quality.
There is a possibility that flicker is observed by the interference of LCD operating signal timing and FL driving
condition (especially driving frequency), even if the condition satisfies above timing specifications and
recommended operating conditions shown in Electrical Specification.
Note5 ) Do not make tv, tvhd and tvds fluctuate.
If tv, tvhd, and tvds are fluctuate, the panel displays black.
Note6) In case of using the long frame period, the deterioration of display quality, noise etc. may be occurred.
Note7) NCLK count of each Horizontal Scanning Time should be always the same.
V-Blanking period should be "n" X "Horizontal Scanning Time". (n: integer)
Frame period should be always the same.
(5/10) 2004-05-26 (Ver.tbd)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
CONNECTOR PIN ASSIGNMENT FOR INTERFACE
CN1 INPUT SIGNAL
Connector : FI-XB30SRL-HF11 / JAE
Mating Connector : FI-X30M, FI-X30MR) / JAE
Terminal No. Symbol Function
Assistant Terminal GND
1 GND
2 VDD Power Supply: +3.3V
3 VDD Power Supply: +3.3V
4 NC
5 NC
6 NC
7 NC
8 OR0- ODD Transmission Data of Pixels 0(Negative: -)
9 OR0+ ODD Transmission Data of Pixels 0(Positive: +)
10 GND
11 OR1- ODD Transmission Data of Pixels 1(Negative: -)
12 OR1+ ODD Transmission Data of Pixels 1(Positive: +)
13 GND
14 OR2- ODD Transmission Data of Pixels 2(Negative:-)
15 OR2+ ODD Transmission Data of Pixels 2(Positive: +)
16 GND
17 OCK- ODD Sample Clock (Negative: -)
18 OCK+ ODD Sample Clock (Positive: +)
19 GND
20 ER0- EVEN Transmission Data of Pixels 0(Negative: -)
21 ER0+ EVEN Transmission Data of Pixels 0(Positive: +)
22 GND
23 ER1- EVEN Transmission Data of Pixels 1(Negative: -)
24 ER1+ EVEN Transmission Data of Pixels 1(Positive: +)
25 GND
26 ER2- EVEN Transmission Data of Pixels 2(Negative: -)
27 ER2+ EVEN Transmission Data of Pixels 2(Positive: +)
28 GND
29 ECK- EVEN Sample Clock (Negative: -)
30 ECK+ EVEN Sample Clock (Positive: +)
Assistant Terminal GND
Note 1) Please connect GND pin to ground. Don't use it as no-connect nor connection with high impedance.
Note 2) Please connect NC pin to nothing. Don't connect it to ground nor to other signal input.
CN2 CCFL POWER SOURCE
Connector : BHSR-02VS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Mating Connector : SM02B-BHS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Terminal No. Symbol Function
1 VFLH CCFL Power Supply ( high voltage)
2 VFLL CCFL Power Supply (low voltage)
(6/10) 2004-05-26 (Ver.TBD)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTM121KM2M
RECOMMENDED TRANSMITTER(THC63LVDM63A,THC63LVDM63A-85) TO LTD121KM2M INTERFACE
ASSIGNMENT
Case1: 6bit Transmitter
ODD DATA
Input Signal To LTD121KM2M
Input Terminal No. Output Signal
(Graphics controller output signal) Interface(CN1)
Symbol
Symbol Symbol Function Terminal Symbol
TA0 44 R0 Red Pixels Display Data (LSB)
TA1 45 R1 Red Pixels Display Data
TA2 47 R2 Red Pixels Display Data
TA- No.8 OR0-
TA3 48 R3 Red Pixels Display Data
TA+ No.9 OR0+
TA4 1 R4 Red Pixels Display Data
TA5 3 R5 Red Pixels Display Data (MSB)
TA6 4 G0 Green Pixels Display Data (LSB)
TB0 6 G1 Green Pixels Display Data
TB1 7 G2 Green Pixels Display Data
TB2 9 G3 Green Pixels Display Data
TB- No.11 OR1-
TB3 10 G4 Green Pixels Display Data
TB+ No.12 OR1+
TB4 12 G5 Green Pixels Display Data (MSB)
TB5 13 B0 Blue Pixels Display Data (LSB)
TB6 15 B1 Blue Pixels Display Data
TC0 16 B2 Blue Pixels Display Data
TC1 18 B3 Blue Pixels Display Data
TC2 19 B4 Blue Pixels Display Data
TC- No.14 OR2-
TC3 20 B5 Blue Pixels Display Data (MSB)
TC+ No.15 OR2+
TC4 22 HSYNC H-SYNC
TC5 23 VSYNC V-SYNC
TC6 25 DE Compound Synchronization Signal
TCLK- No.17 OCK-
CLK IN 26 NCLK Data Sampling Clock
TCLK+ No.18 OCK+
14 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
&' 8U[PE *U[PE 1$ 1$ 1$ 1$
14 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
1$ 1$ 1) 1) 1) 1) 1)
14 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
1) 14 14 14 14 14 14
*1 : Receiver signal
*2 : Input signal
(7/10) 2004-05-26 (Ver.TBD)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
EVEN DATA
Input Signal To LTD121KM2S
Input Terminal No. Output Signal
(Graphics controller output signal) Interface(CN1)
Symbol
Symbol Symbol Function Terminal Symbol
TA0 44 R0 Red Pixels Display Data (LSB)
TA1 45 R1 Red Pixels Display Data
TA2 47 R2 Red Pixels Display Data
TA- No.20 ER0-
TA3 48 R3 Red Pixels Display Data
TA+ No.21 ER0+
TA4 1 R4 Red Pixels Display Data
TA5 3 R5 Red Pixels Display Data (MSB)
TA6 4 G0 Green Pixels Display Data (LSB)
TB0 6 G1 Green Pixels Display Data
TB1 7 G2 Green Pixels Display Data
TB2 9 G3 Green Pixels Display Data
TB- No.23 ER1-
TB3 10 G4 Green Pixels Display Data
TB+ No.24 ER1+
TB4 12 G5 Green Pixels Display Data (MSB)
TB5 13 B0 Blue Pixels Display Data (LSB)
TB6 15 B1 Blue Pixels Display Data
TC0 16 B2 Blue Pixels Display Data
TC1 18 B3 Blue Pixels Display Data
TC2 19 B4 Blue Pixels Display Data
TC- No.26 ER2-
TC3 20 B5 Blue Pixels Display Data (MSB)
TC+ No.27 ER2+
TC4 22 NC Non Connection (open)
TC5 23 NC Non Connection (open)
TC6 25 NC Non Connection (open)
CLK IN 26 NCLK Data Sampling Clock TCLK- No.29 ECK-
TCLK+ No.30 ECK+
'4 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
0% 0% 0% '$ '$ '$ '$
'4 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
'$ '$ ') ') ') ') ')
'4 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176 4Z176
') '4 '4 '4 '4 '4 '4
*1 : Receiver signal
*2 : Input signal
*3 : Do not use this signal
(8/10) 2004-05-26 (Ver.TBD)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
256k (k=1024) COLORS COMBINATION TABLE
Gray Scale
Display R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Level
Black L L L L L L L L L L L L L L L L L L -
Blue L L L L L L L L L L L L H H H H H H -
Green L L L L L L H H H H H H L L L L L L -
Basic Light Blue L L L L L L H H H H H H H H H H H H -
Color Red H H H H H H L L L L L L L L L L L L -
Purple H H H H H H L L L L L L H H H H H H -
Yellow H H H H H H H H H H H H L L L L L L -
White H H H H H H H H H H H H H H H H H H -
Black L L L L L L L L L L L L L L L L L L L0
L L L L L H L L L L L L L L L L L L L1
Dark L L L L H L L L L L L L L L L L L L L2
Gray
n : : : L3}
Scale of
Red p : : : L60
Light H H H H L H L L L L L L L L L L L L L61
H H H H H L L L L L L L L L L L L L L62
Red H H H H H H L L L L L L L L L L L L Red L63
Black L L L L L L L L L L L L L L L L L L L0
L L L L L L L L L L L H L L L L L L L1
Dark L L L L L L L L L L H L L L L L L L L2
Gray
n : : : L3}
Scale of
Green p : : : L60
Light L L L L L L H H H H L H L L L L L L L61
L L L L L L H H H H H L L L L L L L L62
Green L L L L L L H H H H H H L L L L L L Green L63
Black L L L L L L L L L L L L L L L L L L L0
L L L L L L L L L L L L L L L L L H L1
Dark L L L L L L L L L L L L L L L L H L L2
Gray
n : : : L3}
Scale of
Blue p : : : L60
Light L L L L L L L L L L L L H H H H L H L61
L L L L L L L L L L L L H H H H H L L62
Blue L L L L L L L L L L L L H H H H H H Blue L63
Black L L L L L L L L L L L L L L L L L L L0
L L L L L H L L L L L H L L L L L H L1
Gray Dark L L L L H L L L L L H L L L L L H L L2
Scale of n : : : L3}
White & p : : : L60
Black Light H H H H L H H H H H L H H H H H L H L61
H H H H H L H H H H H L H H H H H L L62
White H H H H H H H H H H H H H H H H H H White L63
(9/10) 2004-05-26 (Ver.TBD)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD121KM2M
! FOR SAFETY
LCD module is generally designed with precise parts to achieve light weighted thin mechanical dimensions.
In using our Modules, make certain that you fully understand and put into practice the warnings and safety precautions
detailed in Engineering Information No.EE-N001,"CAUTIONS AND INSTRUCTIONS FOR TOSHIBA LCD MODULES".
Refer to individual specifications and TECHNICAL DATA sheets (hereinafter called "TD") for more detailed technical
information.
1) SPECIAL PURPOSES
A) Toshiba Matsushita Display Technology's Standard LCD Modules have not been customized for operation in extreme
environments or for use in applications where performance failures could be life-threatening or otherwise catastrophic.
B) Since Toshiba Matsushita Display Technology's Standard LCD Modules have not been designed for operation in extreme
environments, they must never be used in devices that will be exposed to abnormally high levels of vibration or shock which
exceed Toshiba Matsushita Display Technology's published specification limits.
C) In addition, since Toshiba Matsushita Display Technology Standard LCD Modules have not been designed for use in
applications where performance failures could be life-threatening or catastrophic, they must never be installed in aircraft
navigation control systems (such as, but not limited to Traffic Collision Avoidance System and Air Traffic Indicator), in military
defense or weapons systems, in critical industrial process-control systems (e.g., those involved in the production of nuclear
energy), or in critical medical device or patient life-support systems.
2) DISASSEMBLING OR MODIFICATION
DO NOT DISASSEMBLE OR MODIFY the module. It may damage sensitive parts inside LCD module, and may cause
scratches or dust on the display.
Toshiba Matsushita Display Technology doses not warrant the module, if customer disassembled or modified it.
3) BREAKAGE OF LCD PANEL
DO NOT INGEST liquid crystal material, DO NOT INHALE this material, and DO NOT CONTACT the material with skin, if
LCD panel is broken and liquid crystal material spills out.
If liquid crystal material comes into mouth or eyes, rinse mouth or eyes out with water immediately.
If this material contact with skin or cloths, wash it off immediately with alcohol and rinse thoroughly with water.
4) GLASS OF LCD PANEL
BE CAREFUL WITH CHIPS OF GLASS that may cause injuring fingers or skin, when the glass is broken.
5) ELECTRIC SHOCK
DISCONNECT POWER SUPPLY before handling LCD module.
DO NOT TOUCH the parts inside LCD module and the fluorescent lamp's connector or cables in order to prevent electric
shock, because high voltage is supplied to these parts from the inverter unit while power supply is turned on.
6) ABSOLUTE MAXIMUM RATINGS AND POWER PROTECTION CIRCUIT
DO NOT EXCEED the absolute maximum rating values under the worst probable conditions caused by the supply voltage
variation, input voltage variation, variation in parts' constants, environmental temperature, etc., otherwise LCD module may
be damaged.
Employ protection circuit for power supply, whenever the specification or TD specifies it.
Suitable protection circuit should be applied for each system design.
7) DISPOSAL
When dispose LCD module, obey to the applicable environmental regulations.
(10/10) 2004-05-26 (Ver.TBD)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
