Image preview - the first page of the document
![Panel_Toshiba_Matsushita_LTD133ECYF_0_[DS]](/pics/5eb088790e8c0.gif)
>> Download Panel_Toshiba_Matsushita_LTD133ECYF_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
36cm COLOUR TFT-LCD MODULE
TOSHIBA MOBILE DISPLAY TECHNOLOGY (13.3 TYPE)
LTD133ECYF
PRODUCT INFORMATION (p-Si TFT)
All information is subject to change without notice. Please read bottom notes.
FEATURES
(1) 13.3XGA(1024x768 pixels) display size for notebook PC
(2) LVDS interface system (H-Sync, V-Sync) TENTATIVE
(3) Glare surface with wide viewing angle(Virtical:85/Horizontal:100)typ
(4) RoHS directive conformance
MECHANICAL SPECIFICATIONS
Item Specifications
Dimensional Outline (typ.) 284.0(W) x 214.5 (H) x 5.5max(D) mm
Number of Pixels 1024(W) x 768(H) pixels
Active Area 270.336(W) x 202.752(H) mm
Pixel Pitch 0.264(W) x 0.264(H)
Weight (approximately) 310g(typ)
Backlight Single CCFL, Sidelight type
ABSOLUTE MAXIMUM RATINGS
Item Min. Max. Unit
Supply Voltage (VDD) -0.3 4.0 V
(VFL) 0 2.0 kV(rms)
FL Driving Frequency (fFL) - 100 kHz
Input Signal Voltage (VIN) -0.3 VDD+0.3 V
Operating Temperature 0 50 qC
Storage Temperature -20 60 qC
Storage Humidity 10 90 %(RH)
ELECTRICAL SPECIFICATION
Item Min. Typ. Max. Unit Remarks
Supply Voltage (VDD) 3.0 3.3 3.6 V
(VFL) --- (650) --- V(rms) IFL=6.0 mA(rms)
FL Start Voltage (Ta=0qC) 1500 --- --- V(rms)
Differential Input Voltage (VID) 100 --- 600 mV
Comon Mode Input Voltage (VCM) 1.0 --- 2.4-VID /2 V
Current Consumption *2 (IDD) --- (240) --- mA
*3 (IFL) --- 6.0 --- mA(rms)
*2 *3 Power Consumption --- (4.7) --- W IFL=6.0 mA(rms)
*1 : Refer to THC63LVDF84A-85 Specification by THine Electronics,Inc.
*2 : 8 color bars pattern
*3 : Excepting the efficiency FL inverter
*4 : VOS : Offset Mode Voltage
OPTICAL SPECIFICATION (Ta=25qC)
Item Min. Typ. Max. Unit Remarks
Contrast Ratio (CR) 150 250 --- ---
Response Time (tON)+(tOFF) --- --- 100 ms
2
Luminance (L) (240) 300 --- cd/m IFL=6.0mA(rms)
*The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
Toshiba or other rights of the third parties which may result from its use. No license is granted by implication or otherwise under any
patent or patent rights of Toshiba or others.
*The information contained herein may be changed without prior notice. It is therefore advisable to contact Toshiba before proceeding
with the design of equipment incorporating this product.
(1/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
Unit : mm
DIMENSIONAL OUTLINE TENTATIVE Standard tolerance : r0.5
(Front side)
(2/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
DIMENSIONAL OUTLINE
Unit : mm
(Rear side)
TENTATIVE Standard tolerance : r0.5
(3/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
BLOCK DIAGRAM
X- dri ver
D C/DC
co nve rter
Y-d rive r
Y -dr ive r
L iqu id Cry sta l P ane l
Gray scale 10 24 x 7 68 pix els
Manipulation
Voltage
Generation
Circuit
CN1
Con nec tor
P ane l
CN2
Cont rol ler Ba ckl ight
LVD S
1024 pixels
1, 1 2, 1 X2n-1, 1 X2n, 1 1024, 1
1, 2
1, Y X2n-1, Y X2n, Y
768 pixels
1, 768 1024,768
(4/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
TIMING CHART
VSYNC
tvsu tvhd th
HSYNC
tv p tvbp tvd
tvds
DE 767 768 1 2
th
thw
HSYNC thbp
thfp thds thd
DE
1024
pixel 1 2 3 4
CLK
(5/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
TIMING SPECIFICATION 1) 2) 3) 4) 5) 6) 7)
Item Symbol min. typ. max. unit
Horizontal Scanning Term th 1334 x tc 1344 x tc - clock
H-sync Pulse Width thw 4 x tc 136 x tc - clock
Horizontal Front Porch thfp 4 x tc 24 x tc - clock
Horizontal Back Porch thbp 24 x tc 160 x tc - clock
Horizontal Data Sync Period thds 32 x tc 296 x tc - clock
Horizontal Display Term thd 1024 x tc 1024 x tc 1024 x tc clock
Frame Period tv 778 x th 806 x th 860 x th line
V-sync Pulse Width tvw 2 x th 6 x th - line
V-sync Set Up Time (to H-sync) tvsu 8 x tc - - clock
V-sync Hold Time tvhd (thbp+16) x tc - - clock
Vertical Front Porch tvfp 1 x th 3 x th - line
Vertical Back Porch tvbp 2 x th 29 x th - line
Vertical Data Sync Period tvds 8 x th 35 x th - line
Vertical Display Term tvd 768 x th 768 x th 768 x th line
Clock Period tc 15.0 15.38 - ns
Note 1) Refer to "Timing Chart" and LVDS (THC63LVDF84A-85) specifications by THine Electronics,Inc.
Note 2) If DE is fixed to "H" or "L" level for certain period while NCLK is supplied, the panel displays black with some flicker.
Note 3) If NCLK is fixed to "H" or "L" level for certain period while DE is supplied, the panel may be damaged.
Note 4) Please adjust LCD operating signal timing and FL driving frequency, to optimize the display quality.
There is a possibility that flicker is observed by the interference of LCD operating signal timing and FL driving condition
(especially driving frequency), even if the condition satisfies above timing specifications and recommended operating
conditions shown in 3.
Note5 ) Do not make tv, tvhd and tvds fluctuate.
If tv, tvhd, and tvds are fluctuate, the panel displays black.
Note6) In case of using the long frame period, the deterioration of display quality, noise etc. may be occurred.
Note7) NCLK count of each Horizontal Scanning Time should be always the same.
V-Blanking period should be "n" X "Horizontal Scanning Time". (n: integer)
Frame period should be always the same.
(6/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
CONNECTOR PIN ASSIGNMENT FOR INTERFACE
CN1 INPUT SIGNAL
CN1 INPUT SIGNAL (DF19L-20P-1H / HIROSE ELECTRIC CO., LTD.)
Mating Connector : DF19G-20S-1F (FPC), DF19G-20S-1C (Cable)
Terminal No. Symbol Function
1 VDD Power Supply : +3.3V
2 VDD Power Supply : +3.3V
3 VSS GND
4 VSS GND
5 RxIN0- Negative LVDS differential data input (R0-R5,G0)
6 RxIN0+ Positive LVDS differential data input (R0-R5,G0)
7 VSS GND
8 RxIN1- Negative LVDS differential data input (G1-G5, B0-B1)
9 RxIN1+ Positive LVDS differential data input (G1-G5, B0-B1)
10 VSS GND
11 RxIN2- Negative LVDS differential data input (B2-B5, HS, VS, DE)
12 RxIN2+ Positive LVDS differential data input (B2-B5, HS, VS, DE)
13 VSS GND
14 CLK- Clock Signal(-)
15 CLK+ Clock Signal(+)
16 VSS GND
17 NC NC
18 NC NC
19 VSS GND
20 VSS GND
Note 1) Please connect GND pin to ground. Don't use it as no-connect nor connection with high impedance.
CN2 CCFL POWER SOURCE
Connector : BHSR-02VS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Mating Connector : SM02B-BHS-1 / JAPAN SOLDERLESS TERMINAL MFG CO., LTD.
Terminal No. Symbol Function
1 VFLH CCFL Power Supply ( high voltage)
2 VFLL CCFL Power Supply (low voltage)
(7/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
RECOMMENDED TRANSMITTER (DS90CF363) TO LTD133ECYF INTERFACE ASSIGNMENT
Case1: 6bit Transmitter
DS90CF363 LTD133ECYF
Input Terminal No. Input Signal Output Interface
(Graphics controller output signal) Signal (CN1)
Symbol Terminal Symbol Function Symbol Terminal Symbol
TIN0 44 R0 Red Pixels Display Data (LSB)
TIN1 45 R1 Red Pixels Display Data
TIN2 47 R2 Red Pixels Display Data TOUT0- No.5 IN0-
TIN3 48 R3 Red Pixels Display Data TOUT0+ No.6 IN0+
TIN4 1 R4 Red Pixels Display Data
TIN5 3 R5 Red Pixels Display Data (MSB)
TIN6 4 G0 Green Pixels Display Data (LSB)
TIN7 6 G1 Green Pixels Display Data
TIN8 7 G2 Green Pixels Display Data
TIN9 9 G3 Green Pixels Display Data TOUT1- No.8 IN1-
TIN10 10 G4 Green Pixels Display Data TOUT1+ No.9 IN1+
TIN11 12 G5 Green Pixels Display Data (MSB)
TIN12 13 B0 Blue Pixels Display Data (LSB)
TIN13 15 B1 Blue Pixels Display Data
TIN14 16 B2 Blue Pixels Display Data
TIN15 18 B3 Blue Pixels Display Data
TIN16 19 B4 Blue Pixels Display Data TOUT2- No.11 IN2-
TIN17 20 B5 Blue Pixels Display Data (MSB) TOUT2+ No.12 IN2+
TIN18 22 HSYNC H-Sync
TIN19 23 VSYNC V-Sync
TIN20 25 DE Compound Synchronization Signal
CLK IN 26 CLK Data Sampling Clock TCLK OUT- No.14 CLK-
TCLK OUT+ No.15 CLK+
Note 1) Please connect NC pin to nothing. Don't connect it to ground nor to other signal input.
IN 0 T IN6 T IN5 T IN4 T IN3 T IN2 T IN1 T IN0
G0 R5 R4 R3 R2 R1 R0
IN 1 T IN13 T IN12 T IN11 T IN10 T IN9 T IN8 T IN7
B1 B0 G5 G4 G3 G2 G1
IN 2 T IN20 T IN19 T IN18 T IN17 T IN16 T IN15 T IN14
DE VSYNC HSYNC B5 B4 B3 B2
(8/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
256k (k=1024) COLORS COMBINATION TABLE
Gray Scale
Display R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0 Level
Black L L L L L L L L L L L L L L L L L L -
Blue L L L L L L L L L L L L H H H H H H -
Green L L L L L L H H H H H H L L L L L L -
Basic Light Blue L L L L L L H H H H H H H H H H H H -
Color Red H H H H H H L L L L L L L L L L L L -
Purple H H H H H H L L L L L L H H H H H H -
Yellow H H H H H H H H H H H H L L L L L L -
White H H H H H H H H H H H H H H H H H H -
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L H L L L L L L L L L L L L L 1
Gray Dark L L L L H L L L L L L L L L L L L L L 2
Scale of n : : : L3}
: : : L60
Red p
Light H H H H L H L L L L L L L L L L L L L61
H H H H H L L L L L L L L L L L L L L62
Red H H H H H H L L L L L L L L L L L L Red L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L H L L L L L L L 1
Gray Dark L L L L L L L L L L H L L L L L L L L 2
Scale of n : : : L3}
: : : L60
Green p
Light L L L L L L H H H H L H L L L L L L L61
L L L L L L H H H H H L L L L L L L L62
Green L L L L L L H H H H H H L L L L L L Green L63
Black L L L L L L L L L L L L L L L L L L L 0
L L L L L L L L L L L L L L L L L H L 1
Gray Dark L L L L L L L L L L L L L L L L H L L 2
Scale of n : : : L3}
: : : L60
Blue p
Light L L L L L L L L L L L L H H H H L H L61
L L L L L L L L L L L L H H H H H L L62
Blue L L L L L L L L L L L L H H H H H H Blue L63
Black L L L L L L L L L L L L L L L L L L L 0
Gray L L L L L H L L L L L H L L L L L H L 1
Scale of Dark L L L L H L L L L L H L L L L L H L L 2
White & n : : : L3}
: : : L60
Black p
Light H H H H L H H H H H L H H H H H L H L61
H H H H H L H H H H H L H H H H H L L62
White H H H H H H H H H H H H H H H H H H White L63
(9/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LTD133ECYF
! FOR SAFETY
LCD module is generally designed with precise parts to achieve light weighted thin mechanical dimensions.
In using our Modules, make certain that you fully understand and put into practice the warnings and safety precautions detailed
in Engineering Information No.EE-D-001A,"CAUTIONS AND INSTRUCTIONS FOR TOSHIBA LCD MODULES".
Refer to individual specifications and TECHNICAL DATA sheets (hereinafter called "TD") for more detailed technical
information.
1) SPECIAL PURPOSES
A) Toshiba Mobile Display Technology's Standard LCD Modules have not been customized for operation in extreme
environments or for use in applications where performance failures could be life-threatening or otherwise catastrophic.
B) Since Toshiba Mobile Display Technology 's Standard LCD Modules have not been designed for operation in extreme
environments, they must never be used in devices that will be exposed to abnormally high levels of vibration or shock which
exceed Toshiba Mobile Display Technology's published specification limits.
C) In addition, since Toshiba Mobile Display Technology Standard LCD Modules have not been designed for use in
applications where performance failures could be life-threatening or catastrophic, they must never be installed in aircraft
navigation control systems (such as, but not limited to Traffic Collision Avoidance System and Air Traffic Indicator), in military
defense or weapons systems, in critical industrial process-control systems (e.g., those involved in the production of nuclear
energy), or in critical medical device or patient life-support systems.
2) DISASSEMBLING OR MODIFICATION
DO NOT DISASSEMBLE OR MODIFY the module. It may damage sensitive parts inside LCD module, and may cause
scratches or dust on the display.
Toshiba Mobile Display Technology does not warrant the module, if customer disassembled or modified it.
3) BREAKAGE OF LCD PANEL
DO NOT INGEST liquid crystal material, DO NOT INHALE this material, and DO NOT CONTACT the material with skin, if LCD
panel is broken and liquid crystal material spills out.
If liquid crystal material comes into mouth or eyes, rinse mouth or eyes out with water immediately.
If this material contact with skin or cloths, wash it off immediately with alcohol and rinse thoroughly with water.
4) GLASS OF LCD PANEL
BE CAREFUL WITH CHIPS OF GLASS that may cause injuring fingers or skin, when the glass is broken.
5) ELECTRIC SHOCK
DISCONNECT POWER SUPPLY before handling LCD module.
DO NOT TOUCH the parts inside LCD module and the fluorescent lamp's connector or cables in order to prevent electric
shock, because high voltage is supplied to these parts from the inverter unit while power supply is turned on.
6) ABSOLUTE MAXIMUM RATINGS AND POWER PROTECTION CIRCUIT
DO NOT EXCEED the absolute maximum rating values under the worst probable conditions caused by the supply voltage
variation, input voltage variation, variation in parts' constants, environmental temperature, etc., otherwise LCD module may be
damaged.
Employ protection circuit for power supply, whenever the specification or TD specifies it.
Suitable protection circuit should be applied for each system design.
7) DISPOSAL
When dispose LCD module, obey to the applicable environmental regulations.
(10/10) 2010-2-18 (Ver.0.1)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
