Image preview - the first page of the document
Panel_Toshiba_Matsushita_LTD133EWMZ_1_[DS]


>> Download Panel_Toshiba_Matsushita_LTD133EWMZ_1_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center                                 www.panelook.com



                                                                                                    33.7cm COLOUR TFT-LCD MODULE
         Toshiba Matsushita Display Technology Co., Ltd                                                     (13.3 WIDE TYPE)
                                                                                                            LTD133EWMZ
            PRODUCT INFORMATION                                                                               (p-Si TFT)
            All information is subject to change without notice. Please read bottom notes.

         FEATURES
                    (1) 13.3WIDE-XGA(1280x800 pixels) display size for notebook PC
                    (2) LVDS interface system (H-Sync, V-Sync)                                              TENTATIVE
                    (3) Glare surface

         MECHANICAL SPECIFICATIONS
                                      Item                                                     Specifications
                Dimensional Outline (typ.)                                   299(W) x 195 (H) x 5.5max(D) mm
                Number of Pixels                                             1280(W) x 800(H) pixels
                Active Area                                                  286.08(W) x 178.8(H) mm
                Pixel Pitch                                                  0.2235(W) x 0.2235(H)
                Weight (approximately)                                       (340) g(typ)
                Backlight                                                    Single CCFL, Sidelight type

         ABSOLUTE MAXIMUM RATINGS
                Item                                                      Symbol       Min.            Max.            Unit   Checked Terminal
                Supply Voltage                                              VDD        -0.3            +4.0             V     VDD
