Image preview - the first page of the document
Panel_Toshiba_Matsushita_LTD133KX2S_0_[DS]


>> Download Panel_Toshiba_Matsushita_LTD133KX2S_0_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center                                 www.panelook.com



                                                                                                   33.7cm COLOUR TFT-LCD MODULE
         Toshiba Matsushita Display Technology Co., Ltd                                                    (13.3 WIDE TYPE)
                                                                                                            LTD133KX2S
            PRODUCT INFORMATION                                                                              (p-Si TFT)
            All information is subject to change without notice. Please read bottom notes.

         FEATURES
                    (1)   13.3WIDE-XGA(1280x800 pixels) display size for tablet PC
                    (2)   LVDS interface system (H-Sync, V-Sync)                                           TENTATIVE
                    (3)   Wide viewing Angle(U/D/R/L : 50/60/60/60 typ)
                    (4)   Low reflection / Glare

         MECHANICAL SPECIFICATIONS
                                     Item                                                       Specifications
               Dimensional Outline (typ.)                                     300(W) x 195 (H) x 8.0max(D) mm
               Number of Pixels                                               1280(W) x 800(H) pixels
               Active Area                                                    286.08(W) x 178.8(H) mm
               Pixel Pitch                                                    0.2235(W) x 0.2235(H)
               Weight (approximately)                                         TBD g(typ)
               Backlight                                                      Single CCFL, Sidelight type

         ABSOLUTE MAXIMUM RATINGS
               Item                                                       Symbol       Min.           Max.            Unit       Checked Terminal
               Supply Voltage                                               VDD        -0.3           +4.0             V         VDD
