Image preview - the first page of the document
![Panel_ZHIXUAN_ZXXS150-L02_0_[DS]](/pics/5eb08a019ca29.gif)
>> Download Panel_ZHIXUAN_ZXXS150-L02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
ZHIXUAN Display Co., Ltd.
TETLE:ZXXS150-L02
Product Specification
Rev.B
ZHIXUAN Display Co., Ltd.
SPEC. NUMBER PRODUCT GROUP REV. ISSUE DATE PAGE
S864-5003 TFT-LCD B 2007. 05. 31 OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT B 2007.05.31
REVISION HISTORY
REV. ECN No. DESCRIPTION OF CHANGES DATE PREPARED
O - Initial Release 06.06.12. B.C.Lim
A - . Shock test condition change 06.10.12 J.K.KIM
- Gravity : 150G 70G
- Pulse width : 6msec, sine wave
11msec, half sine wave
. B/L Lamp current change
- Max. : 8 9
. B/L Interface connection change
- Hot : Blue Pink
- Cold : Black Black/White
B - . Start Voltage (Typ): 07.05.31 C.Y
850V (0 C), 1100V (25 C)--->
1100V (0 C), 850V (25 C)
. Start Voltage (Max):
none--->1300V (0 C), 1100V (25 C)
. Life Time(Min):
30,000h ( IBL=9.0mA)--->
40,000h ( IBL=9.0mA)
SPEC. NUMBER SPEC. TITLE PAGE
S864-5003 ZXXS150-L02 Product Specification OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT B 2007.05.31
Contents
No. Item Page
1.0 General Description 4
2.0 Absolute Maximum Ratings 6
3.0 Electrical specifications 7
4.0 Optical specifications 8
5.0 Interface Connection 10
6.0 Signal Timing Specifications 13
7.0 Signal Timing waveforms of Interface Signal 15
8.0 Input Signals, Display Colors & Gray Scale of Colors 17
9.0 Power Sequence 18
10.0 Mechanical Characteristics 19
11.0 Reliability Test 20
12.0 Handling & Cautions 21
13.0 Product Serial Number 22
14.0 Packing 23
15.0 Appendix 25
SPEC. NUMBER SPEC. TITLE PAGE
S864-5003 ZXXS150-L02 Product Specification OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT B 2007.05.31
1.0 GENERAL DESCRIPTION
1.1 Introduction
ZXXS150-L02 is a color active matrix TFT LC D module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 15.0 inch
diagonally measured active area with XGA resolutions (1024 horizontal by 768 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 16,194,227 colors. The TFT-LCD panel used for
this module is adapted for a low reflection and higher color type.
CN21
LVDS LVDS Rx Source Driver
Input +
Signal T/CON
+
Connector (CN
Gate Driver
mini-LVDS Tx
TFT LCD Panel
1024 768
VDD DC/DC
1 Gamma
)
Vcom
CN22
1.2 Features
z LVDS Interface with 1 pixel / clock
z High-speed response
z Low power consumption
z 6-bit (FRC) color depth, display 16,194,227 colors
z Incorporated edge type back-light (Two lamps)
z High luminance and contrast ratio, low reflection and wide viewing angle
z DE (Data Enable) & H-Sync & V-Sync mode
z RoHS Compliant
SPEC. NUMBER SPEC. TITLE PAGE
S864-5003 ZXXS150-L02 Product Specification OF 28
A4(210 X 297)
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PRODUCT GROUP REV ISSUE DATE
TFT- LCD PRODUCT B 2007.05.31
1.3 Application
z Desktop Type of PC & Workstation Use
z Slim-Size Display for Stand-alone Monitor
z Display Terminals for Control System
z Monitors for Process Controller
1.4 General Specification
The followings are general specifications at the model HT150X02-100.
