Image preview - the first page of the document
![Panel_ZHIXUAN_ZXXS260-L04_0_[DS]](/pics/5eb08ace9f913.gif)
>> Download Panel_ZHIXUAN_ZXXS260-L04_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
ZXXS260-L04
Product Information
DATE : 7. Oct. 2010
ZHIXUAN TFT-LCD
MODEL : ZXXS260-L04
The Information Described in this Specification is Preliminary and can be changed without
prior notice
LCD Business
ZHIXUAN Display Co.,Ltd
DATE DATE
Kwang-soo Lee 07.Oct.2010 Dong-Hyun Kim 07.Oct.2010
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS260-L04
Contents
General Description --------------------------------------------------------------------------------------- (3)
General Information --------------------------------------------------------------------------------------- (3)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (4)
2. Optical Characteristics --------------------------------------------------------------------------------- (5)
3. Electrical Characteristics ------------------------------------------------------------------------------- (8)
3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Inverter Input & Specification
4. Input Terminal Pin Assignment --------------------------------------------------------------------- (11)
4.1 Input Signal & Power
4.2 Inverter Input Pin Configuration
4.3 Inverter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
5. Interface Timing ---------------------------------------------------------------------------------------- (16)
5.1 Timing Parameters (DE only mode)
5.2 Spread Spectrum
5.3 LVDS Input Data Position
5.4 Timing diagrams of interface signal
5.5 Power ON/OFF Sequence
6. Outline Dimension -------------------------------------------------------------------------------------- (19)
7. Packing --------------------------------------------------------------------------------------------------- (21)
8. Marking & Others --------------------------------------------------------------------------------------- (22)
9. General Precaution ------------------------------------------------------------------------------------- (23)
9.1 Handling
9.2 Storage
9.3 Operation
9.4 Operation Condition Guide
9.5 Others
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS260-L04
General Description
Description
ZXXS260-L04 is a color active matrix liquid crystal display (LCD) that uses amorphous silicon
TFT(Thin Film Transistor) as switching components. This model is composed of a TFT LCD
panel, a driver circuit and a back light unit. The resolution of a 26.0" is
1366 x 768 and this model can display up to 16.7 million colors with wide viewing angle of
89 or higher in all directions. This panel is intended to support applications to provide a
excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV
and High Definition TV.
Features
