Image preview - the first page of the document
![Panel_ZHIXUAN_ZXXS470-L02_0_[DS]](/pics/5eb08c358a161.gif)
>> Download Panel_ZHIXUAN_ZXXS470-L02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
ZXXS470-L02
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 47.0" WUXGA TFT LCD
BUYER SUPPLIER Zhixuan Display
. .,
MODEL *MODEL ZXXS470-L02
SUFFIX SAA1 (RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ J.H. Yoon /Senior Manager
REVIEWED BY
/ P.Y. Kim / Manager
PREPARED BY
/ Y.N. Lee / Engineer
Please return 1 copy for your confirmation with TV Product Development Dept.
your signature and comments. Zhixuan Display
Ver. 1.0 1 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS470-L02
Product Specification
CONTENTS
Number ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 6
3-2 INTERFACE CONNECTIONS 8
3-3 SIGNAL TIMING SPECIFICATIONS 10
3-4 SIGNAL TIMING WAVEFORMS 11
3-5 COLOR DATA REFERENCE 12
3-6 POWER SEQUENCE 13
4 OPTICAL SPECIFICATIONS 15
5 MECHANICAL CHARACTERISTICS 19
6 RELIABILITY 22
7 INTERNATIONAL STANDARDS 23
7-1 SAFETY 23
7-2 EMC 23
8 PACKING 24
8-1 DESIGNATION OF LOT MARK 24
8-2 PACKING FORM 24
9 PRECAUTIONS 25
9-1 MOUNTING PRECAUTIONS 25
9-2 OPERATING PRECAUTIONS 25
9-3 ELECTROSTATIC DISCHARGE CONTROL 26
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 26
9-5 STORAGE 26
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 26
Ver. 1.0 2 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS470-L02
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
1.0 Jan, 02, 2008 - Final Specification
Ver. 1.0 3 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS470-L02
Product Specification
1. General Description
The ZXXS470 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(LED ) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive display type which is operating in the normally black mode. It has a 46.96 inch diagonally
measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.07 Billion colors.
It has been designed to apply the 10-bit 2-port LVDS interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
Mini-LVDS(RGB)
EEPROM
Source Driver Circuit
SCL SDA S1 S1920
+12.0V
G1
Gate Driver Circuit
LVDS Timing Controller
CN1 [LVDS Rx + ODC
2Port (51pin)
integrated]
DCR
Enable TFT - LCD Panel
VBR_OUT (1920 RGB 1080 pixels)
Bit Selection
Power Circuit G1080
LVDS Selection
Block
+24.0V, GND, VBR-A,VBR-B
Status Inverter(Master) 3PinX1CN(High)
Back light Assembly
+24.0V, GND Inverter(Slave) 3PinX1CN(High)
General Features
Active Screen Size 46.96 inch (1192.87mm) diagonal
Outline Dimension 1096.0(H) x 640.0 (V) x 51 mm(D) (Typ.)
Pixel Pitch 0.5415 mm x 0.5415 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement
Color Depth 10Bit (D), 1.07 Billion colors
Luminance, White 1000 nit (Center 1point ,Typ.)
Viewing Angle (CR>10) Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.))
Power Consumption Total 237.08 W (Typ.) [Logic=7.08W, Backlight=230W (VBR-A=1.65V)]
Weight 14.5 Kg (Typ.)
Display Mode Transmissive mode, Normally black
Surface Treatment Hard coating(3H), Anti-glare treatment of the front polarizer (Haze 13%)
Ver. 1.0 4 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ZXXS470-L02
Product Specification
2. Absolute Maximum Ratings
The following items are maximum values which, if exceeded, may cause faulty operation or damage to the
LCD module.
Table 1. ABSOLUTE MAXIMUM RATINGS
Value
Parameter Symbol Unit Remark
Min Max
